- Page 1 Operator Manual CHARIOT ® ASL-700 02-03-2022 P/N 700-O www.bruno.com BRUNO Independent Living Aids SRE-2010G OPERATOR 12/30/21...
-
Page 2: Table Of Contents
• Compete the enclosed Product Registration card and return via mail Serial Number: Please note a serial number is found on your Bruno lift. The serial and model number will be needed for your dealer to file a warranty claim, request parts or service the unit. -
Page 3: Safety
MAY cause loss o vehicle data, damage vehicle wiring system or even cause airbags to deploy. This information can be found in the VEHICLE OWNER’S MANUAL or the VEHICLE REPAIR GUIDE. Bruno Independent Living Aids ASL-700 OPERATOR 02-03-2022... - Page 4 ◊ Remove the mobility device from the ASL-700 and leave it at the exit. ◊ Fold the platform to the upright and stowed position. ◊ Drive the vehicle through the TOUCHLESS car wash. ◊ Retrieve the mobility device at the car wash exit. ASL-700 OPERATOR 02-03-2022 Bruno Independent Living Aids...
-
Page 5: Maximum Weight Rating And Vin/Serial No. Location
350 lb (159 kg) Patent Pending Tire Specifications Rim Specifications Tire Size: 4.80/4.00-8 Rim Dimensions: 8” diameter Load Range: C Bolt Pattern: 5 on 4-1/2” Ply Rating: 6 VIN and serial no. found here Bruno Independent Living Aids ASL-700 OPERATOR 02-03-2022... -
Page 6: Operation
• Insert the key and turn it to the ON Retractable belt hooks position. attach to this docking • Make sure an authorized Bruno dealer plate. has installed the docking plate shown • Have an authorized Bruno dealer earlier in this manual. -
Page 7: Platform Belts
• Close the keyswitch cover. NOTE: When travelling with no mobility device on the platform, See note to right. Bruno recommends folding up the platform and securing it using the outermost retractable belt to prevent damage from bouncing (see left). However, for increased fuel efficiency during highway driving, you may travel with the platform folded down. -
Page 8: Emergency Operation
EMERGENCY OPERATION NOTE: Emergency operation is to be performed by an able-bodied person. raise emergency operation tool platform lower platform OFF! ASL-700 OPERATOR 02-03-2022 Bruno Independent Living Aids... -
Page 9: Maintenance
MAINTENANCE Bruno recommends having a qualified Bruno dealer clean, inspect and perform any necessary repairs and adjustments at least every twelve (12) months. Maintenance is recommended more often if the lift is used (a) many times per day and/ or (b) in harsh environments. Failure to follow the recommended maintenance schedule will void the warranty. - Page 10 30 ft lb (41 Nm) • chassis-to-cross member bolts: 35 to 40 ft lb (47-54 Nm) • swivel plates-to-cross member bolts: 35 to 40 ft lb (47-54 Nm) • double nuts (require special process: see Hitch Clamp) ASL-700 OPERATOR 02-03-2022 Bruno Independent Living Aids...
- Page 11 CAUTION! Be sure to use the correct wheel hardware. Use of incorrect hardware and/or improper tightening could cause the wheel to become loose and even come off, leading to equipment damage and/or personal injury. Bruno Independent Living Aids ASL-700 OPERATOR 02-03-2022...
-
Page 12: Troubleshooting
• keep platform in the down to lower the platform and position (i.e., “flat”) so unbind the actuator. that it touches the rubber stops. Failure to do this allows the platform to pull in too far. ASL-700 OPERATOR 02-03-2022 Bruno Independent Living Aids... -
Page 13: Nhtsa Dot Hs 809 October 2001
• With radial tires, it is usually not possible to determine underinflation by visual inspection. For convenience, purchase a tire pressure gauge to keep in your vehicle. Gauges can be purchased at tire dealerships, auto supply stores, and other retail outlets. Bruno Independent Living Aids ASL-700 OPERATOR 02-03-2022... - Page 14 Punctures through the tread can be repaired if they are not too large, but punctures to the sidewall should not be repaired. Tires must be removed from the rim to be properly inspected before being plugged and patched. ASL-700 OPERATOR 02-03-2022 Bruno Independent Living Aids...
- Page 15 Letter Rating Speed Rating Q 99 mph T 118 mph V 149 mph R 106 mph U 124 mph W 168* mph S 112 mph H 130 mph Y 186* mph Bruno Independent Living Aids ASL-700 OPERATOR 02-03-2022...
- Page 16 These tires should only be used in pairs or placed on all four wheels. Make sure you purchase snow tires that are the same size and construction type as the other tires on your vehicle. ASL-700 OPERATOR 02-03-2022 Bruno Independent Living Aids...
-
Page 17: Reporting Safety Defects
If you believe that your vehicle has a defect that could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Bruno Independent Living Aids, Inc. at 1-800-656-0552 and/or Parts.orders@bruno.com If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. -
Page 18: Warranty
“Industry Leading” warranty for your peace of mind. The quality of parts we use and the care our employees take allow Bruno to provide the original buyer of its Bruno Vehicle Lift with a 3-year warranty that all parts are free of defects in material and workmanship.
