Air impact wrench

Advertisement

Quick Links

Manual
Air impact wrench
Applies for:
Code
Model
11186
TPN-797-6-2
TPN-797-6-2
WARNING
CAUTION
Use oil continuously and
dosed to lubricate the tool.
Read this manual thoroughly
before using the tool.
1"

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPN-797-6-2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Truper TPN-797-6-2

  • Page 1 Manual Air impact wrench 1” Applies for: Code Model 11186 TPN-797-6-2 TPN-797-6-2 Use oil continuously and WARNING dosed to lubricate the tool. Read this manual thoroughly CAUTION before using the tool.
  • Page 2: Table Of Contents

    Parts Keep this manual for future references. Assembly The illustrations in this manual are for reference Start Up only. They might be different from the real tool. Maintenance Troubleshooting Notes Authorized Service Centers Warranty Policy TPN-797-6-2 ENGLISH...
  • Page 3: Technical Data

    Technical Data TPN-797-6-2 Code 11186 Description Air impact wrench Impact Mechanism Twin Hammer Box Impeller 1” Maximum Torque 1 800 lb-ft Air Ejection Bottom Free Speed 4 000 RPM Weight Without Accessories 24.2 lb Air Pressure 90 PSI Air Consumption 9.5 CFM...
  • Page 4: General Safety Warnings For Pneumatic Tools

    General Safety Warnings for Pneumatic Tools Keep your work area clean, tidy and well lit. Wear adequate protective safety accessories. CAUTION CAUTION Cluttered and dark areas may cause accidents. Wear eye protection, dust mask, non-skid safety shoes, helmet and ear plugs. In normal conditions, the risk of Never use the tool in explosive areas or in the presence injury is reduced.
  • Page 5: Risk Control When Using Pneumatic Tools

    Risk Control When Using Pneumatic Tools Risk of injury in head and eyes To prevent head and eyes injuries WARNING • Compressed air out of pneumatic • Always, when operating pneumatic equipment wear equipment may be dangerous. Objects like brackets, burrs, protection glasses in compliance with the AMSI Z887.1 splinters, dust and other residues may be impelled towards Standard.
  • Page 6 Risk Control When Using Pneumatic Tools Risk of injuries To prevent injuries WARNING • Damaged hoses may burst and cause • Do not abuse the hose or the connectors. serious injuries or deafness. • Keep the hose away from sharp or abrasive edges. •...
  • Page 7: Parts

    Parts Trigger Handle Box Impeller 8” Stem Auxiliary Air Exhaust Torque and Handle Rotation Inlet Selector Assembly Die Set Up • Disconnect the tool from the air outlet before replacing the die. Nut or • Select the die you need and set it in the box impeller. Lug Inlet •...
  • Page 8: Start Up

    Start Up Air Outlet Connection • Remove the plastic capo (A) covering the air inlet in the handle base. • Before each use add three to six drops of lubricant with no detergent (B) into the air inlet (C). • Screw the quick connector D (not included) to the air inlet.
  • Page 9: Maintenance

    1 to 2 seconds. The tool rotor turns • The “O-ring” in the inlet is broken. • Take the tool to a Truper Authorized Service Center, to without auctioning make the change of "O-ring" broken"...
  • Page 10: Notes

    Notes ENGLISH...
  • Page 11: Authorized Service Centers

    In the event of any problem contacting a Truper Authorized Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800 0187-8737 to get information about the nearest Service Center.
  • Page 12: Warranty Policy

    . Transportation costs resulting from compliance of this warranty will be covered by For questions or comments, call 800-690-6990. Made in China. Imported by Truper S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257 Stamp of the business.
