- Page 1 Owner’s/Operator’s Manual KBC26-RS KBC26H-RS KBC30H-RS Completely read and understand this manual before using this product.
-
Page 2: Table Of Contents
It is essential that any operator of this Trimmer/Brushcutter reads and understands the contents this manual before using the Trimmer/ Brushcutter. For additional assistance, contact any local authorized KUBOTA dealer. Important Notice The benefits to the consumer given by this warranty are in addition to other rights and remedies of the con- sumer under a law in relation to the goods or services to which this warranty relates. -
Page 3: Product Description
ON SHAFT（Part No. 221502） ON SHAFT ON ENGINE （Part No. 231264） [ KBC26-RS, KBC26H-RS ] （Part No. 246211） [ KBC30H-RS ] （Part No. 246212） Safety Decals are easily visible to the operator and are located near any area of potential danger. -
Page 4: Safety Instructions
6. Make sure the cutting attachment blade is installed and positioned correctly before using the Trimmer/Brushcutter. 7. Never use a cutting attachment or replacement parts that are not approved by KUBOTA. 8. Maintain the Trimmer/Brushcutter according to the recommended maintenance intervals and proce- dures in the Maintenance section beginning on page 21. -
Page 5: Fuel Safety
Direction of Swing Swing CORRECT INCORRECT 10. Keep a firm footing and balance. Do not overreach. 11. Use the right tool for the job. Do not use the Trimmer/Brushcutter for any job that is not recommended by KUBOTA. ＿ 4 ＿... -
Page 6: Assembly
Assembly Assembling Engine and Drive Shaft Assembly Engine Attach the clutch drum housing to the engine using the four Screw（4） screws supplied with the unit. Clutch Drum Housing Loop Handle Installation Loop handle must be assembled gearcase side from the arrow (A). 1. -
Page 7: Stop Switch Wires
Connecting Throttle Cable and Stop Switch Wires Cable Adjuster Sleeve Throttle Cable 1. Insert the throttle cable through the carburetor bracket, then screw a cable adjuster sleeve into the carburetor bracket fully. 2. Position the slotted fitting on the carburetor so the recessed Carburetor hole for the cable lug is away from the cable adjuster sleeve. -
Page 8: Installing Guard
Installing Guard WARNING POTENTIAL HAZARD ・ F oreign objects can be thrown by Trimmer/Brushcutter. WHAT CAN HAPPEN ・Contact with thrown objects can cause personal injury. HOW TO AVOID THE HAZARD ・ N ever operate the Trimmer/Brushcutter without the guard in place. M6×30 Screw(2) Blade Guard Attach the blade guard to the gearcase with the two... -
Page 9: Installing Cutting Attachment
Installing Cutting Attachment Trimmer Head WARNING POTENTIAL HAZARD ・ If the trimmer head is not adequately tightened, it can come loose from the Trimmer/ Brushcutter during use. WHAT CAN HAPPEN ・ This may cause damage to property or personal injury. HOW TO AVOID THE HAZARD ・... - Page 10 Brushcutter Blade WARNING POTENTIAL HAZARD ・ If the Brushcutter blade is not adequately tightened, it can come loose from the Brushcutter during use. WHAT CAN HAPPEN ・ This may cause damage to property or personal injury. HOW TO AVOID THE HAZARD ・...
-
Page 11: Attaching Shoulder Strap/Harness
Snap the Hook into the ring on the drive shaft. To detach the shoulder strap/harness quickly from the Trimmer/Brushcutter, pull upward on the Red Band/Tab. Shoulder Strap Red Band Shoulder Harness Red Tab Pull Pull Hook Ring Hook Ring [KBC26-RS, KBC26H-RS] [KBC30H-RS] ＿ 10 ＿... -
Page 12: Before Operation
Before Operation Oil and Fuel 1. Mix and pour fuel outdoors and where there are no sparks or flames. 2. Always shut off the engine before refueling. Never remove the Trimmer/Brushcutter fuel tank cap while the engine is running or immediately after stopping the engine. WARNING POTENTIAL HAZARD ・... -
Page 13: Mixing Petrol And Oil
Recommended Oil Type Only use a two-stroke engine oil formulated for use in high-performance, air-cooled two-stroke engines. IMPORTANT: Do not use two-stroke oil intended for water cooled outboard motors. This type of two-stroke engine oil does not have the additives for air-cooled two-stroke engines and can cause engine damage. -
Page 14: Starting And Stopping
Starting and Stopping Before Starting the Engine 1. Fill the fuel tank as instructed in the Before Operation section of this manual. 2. Rest the Trimmer/Brushcutter on the ground. 3. Make sure the cutting attachment is clear of any broken glass, nails, wire, rocks or other debris. 4. -
Page 15: Idle Speed Adjustment
4. If the engine fails to start after three to four pulls, follow the instructions in the Cold Starting Procedure section above. If the engine fails to start after you follow the above procedures, contact an authorized KUBOTA dealer. To Stop the Engine 1. -
Page 16: Trimmer Operation
Trimmer, and the Trimmer should be on operator’s right side. Shoulder Strap [Model KBC26-RS] 2. The operator’s right hand should be holding the shaft grip, with his or her fingers on the throttle trigger. The right arm should be slightly bent. - Page 17 IMPORTANT: To detach the shoulder strap/harness quickly from the Trimmer, pull upward on the Red Band/Tab. Shoulder Strap Red Band Shoulder Harness Red Tab Pull Pull Hook Ring Hook Ring [KBC26-RS, KBC26H-RS] [KBC30H-RS] ＿ 16 ＿...
-
Page 18: Cutting With Trimmer Head
Cutting with Trimmer Head ・ The tip of the line does the cutting. The line should stay extended while cutting. ・ Do not force the line into the material. Forcing the line will cause it to slap against the material, increasing line usage and causing poor cutting results. -
Page 19: Brushcutter Operation
Brushcutter, and the Brushcutter must be on the operator’s right side. [Model KBC26-RS] 2. The operator’s right hand should be holding the shaft grip, with his or her fingers on the throttle trigger. The right arm should be slightly bent. - Page 20 ・Never use a Brushcutter that has chipped, cracked or broken cutting attachment or guard. IMPORTANT: To detach the shoulder strap/harness quickly from the Brushcutter, pull upward on the Red Band/Tab. Shoulder Strap Red Band Shoulder Harness Red Tab Pull Pull Hook Ring Hook Ring [KBC26-RS, KBC26H-RS] [KBC30H-RS] ＿ 19 ＿...
-
Page 21: Cutting Direction Of Brushcutter Blade
INCORRECT Cutting Blades 1. Use only the correct blade (KUBOTA genuine part) approved for the application and model Brushcutter. 2. Carefully check the condition of the blades before and after operation. 3. Sharpen dull blades. Replace any blade that is worn, cracked or damaged. -
Page 22: Maintenance
Maintenance Air Filter Maintenance Interval ・The air filter should be cleaned daily, or more often when Knob working in extremely dusty conditions. ・Replace after every 100 hours of operation. Air Filter Cleaning 1. Remove the filter cover and foam element. 2. -
Page 23: Spark Plug
Spark Plug Maintenance Interval ・ The spark plug should be removed from the engine and checked after each 25 hours of operation. 0,6-0,7mm ・ Replace the spark plug after every 100 hours of operation. Spark Plug Maintenance 1. Twist the high tension lead boot on the spark plug back and forth a couple of times to loosen the boot, then pull the boot off of the spark plug. -
Page 24: Spark Arrester
Spark Arrester WARNING POTENTIAL HAZARD ・ Muffler surface becomes hot when Trimmer/Brushcutter is in operation and remains hot for sometime after the engine is shut off. WHAT CAN HAPPEN ・ Contact with hot muffler surface could cause a burn. HOW TO AVOID THE HAZARD ・... -
Page 25: General Cleaning And Tightening
・ Always turn off your Trimmer/ Brushcutter before you clean or perform any maintenance on it. The KUBOTA Trimmer/Brushcutter will provide maximum performance for many, many hours if it is main- tained properly. Good maintenance includes regular checking of all fasteners for correct tightness, and cleaning the entire machine. -
Page 26: Specifications
Specifications KBC26-RS KBC26H-RS KBC30H-RS Engine model CE260 CE260 CE300 Engine displacement, cm 25,4 30,1 Idling speed, min 2700 - 3300 Recommended maximum engine speed, min 11700 Speed of output axle, min 8000 Maximum engine power, according to ISO 8893, 0,83... - Page 28 This engine is certified US EPA. Regulatory authority : United States Environmental Protection Agency Emission standard : 40 CFR 1054 Certificate Number : KM4XS.026416-003 KM4XS.030415-005 Kubota Australia Pty Ltd Original Instruction 25 – 29 Permas Way Truganina Vic. 3029 Australia P/N.241776-00 GB 1903 IN...
