- Page 1 JZ20030 1028mm 2000mm 1550mm 830mm 226mm UNA BUNK BED ASSEMBLY INSTRUCTIONS...
- Page 2 WARNING! To avoid damage to the product please do not use powertools to assemble this item!!!
- Page 3 Tools Required CAUTION: Do not use tools other than those required, as this can damage your new item NOTE • Please check you have all hardware before assembling. • If you are missing any hardware, please contact the store of purchase. •...
- Page 4 Packing List CARTON NUMBER PART NUMBER QUANTITY Carton 1 Bed Leg HARDWARE INSTRUCTION BOOK Carton 2 Bed Frame...
- Page 5 HARDWARE M6x90mm Ø8x30mm 15mm M6x70mm 15mm Ø10x13mm Ø4x30mm Ø8mm M6x35mm 15mm Ø15mm M8x20mm 15mm M6x60mm 10mm Ø7x60mm 15mm Page 1 of 6...
- Page 6 Ø8x30mm Page 2 of 6...
- Page 7 M6x90mm 15mm Ø10x13mm M6x90mm 15mm Ø10x13mm Page 3 of 6...
- Page 8 M6x35mm 15mm 10mm Ø7x60mm Page 4 of 6...
- Page 9 M6x70mm 15mm Ø10x13mm M6x35mm 15mm M8x20mm 15mm M6x60mm 15mm WARNING: Press the middle of bed sides and tighten the screw first. Ø4x30mm Page 5 of 6...
- Page 10 Ø4x30mm Ø8mm Ø15mm Page 6 of 6...
- Page 11 IMPORTANT - READ CAREFULLY - RETAIN FOR FUTURE REFERENCE Safety Information All assembly fixings should be tightened properly and care should be taken that no fittings are loose. Regular tightening of the bolts is recommended to extend the lifespan of the product. Please follow all the instructions when assembling the product and do not use power tools when building.
