Summary of Contents for MuginUAV DLE60 EFI
- Page 1 MUGIN LIMITED DLE-60CC EFI UAV ENGINE DLE60 EFI Electronic Fuel Injected Engine User’ Manual WWW.MUGINUAV.COM...
-
Page 2: Table Of Contents
2 Un-Packing Your Engine ..........4 3 Engine Installation & Getting Started ......9 3.1 Hardware Installation ..........9 3.2 Throttle Setting ............10 3.3 Engine OilMix ............11 4 Starting the engine ............11 5 Maintenance ..............13 6 Technical Specification ..........14 WWW.MUGINUAV.COM... -
Page 3: General Safety
4. Observe precaution around the muffler. The exhaust system gets hot enough to ignite Some materials. 5. Keep flammable materials away from the engine. 6. Petrol is extremely flammable and is explosive under certain conditions. Do not smoke Or allow Flames or sparks where the engine is operating WWW.MUGINUAV.COM... -
Page 4: Un-Packing Your Engine
Package List： 1. Engine with Intake Assembly 2. Engine Control Unit（ECU） 3. Engine CDI 4. Fuel Pump 5. Fuel tubing 6. Main Wire Harness 7. Engine Assembly Hardware 8. Operation Manual WWW.MUGINUAV.COM... - Page 5 MUGIN LIMITED DLE-60CC EFI UAV ENGINE Components & Descriptions WWW.MUGINUAV.COM...
- Page 6 MUGIN LIMITED DLE-60CC EFI UAV ENGINE WWW.MUGINUAV.COM...
- Page 7 MUGIN LIMITED DLE-60CC EFI UAV ENGINE WWW.MUGINUAV.COM...
- Page 8 MUGIN LIMITED DLE-60CC EFI UAV ENGINE Caution: Strictly connect all the wires, wrong connection possibly can cause the engine damage WWW.MUGINUAV.COM...
-
Page 9: Engine Installation & Getting Started
2 continuous hours (5000 RPM/H). DLE60cc engine is the latest version with CDI voltage from 4.8V-14V. Gaskets for DLE engines (Since September 2021) are in the latest material without air pollution restricted by some countries. WWW.MUGINUAV.COM... -
Page 10: Throttle Setting
Suggest the user to set up the idle rate on your TX or flight controller for the first time to operate the engine. Properly adjust and set up the throttle curve and rate to avoid the damage of throttle servo by dead steering. WWW.MUGINUAV.COM... -
Page 11: Engine Oilmix
6. Allow the engine to run for a few minutes to warm up the engine 7. Hold at wide open throttle for 15 seconds to verify that the air in the fuel system has been purged. Reduce the engine speed to idle WWW.MUGINUAV.COM... - Page 12 Green light flashing in Sync while the engine is running in high speed 10. LED light Patterns on Fuel pump: Green light for fuel pump is in normal status, Red light for fuel pump pressure is lower (need to checked fuel line) WWW.MUGINUAV.COM...
-
Page 13: Maintenance
√ Spark Plug Check/Adjust √ √ Spark Plug Replacement √ √ √ Air filter Replacement √ √ Fuel filter Replacement √ LT OEM Maintenance √ Make sure to maintain the engine periodically and keep the service record for warranty！ WWW.MUGINUAV.COM... -
Page 14: Technical Specification
Propeller Range:22X10;23X8;23X10;23X12;24X10 • Spark Plug: CM-6 2. Parameter： • Displacement: 61cc • Compression Ratio: 7.6：1 • Lubrication Ratio: 40：1 • Weight of the Main Engnine: 1900G • ECU: 110G • Fuel Pump: 180G • CDI: 160G • Power Waste：12V/4W/2000RPM, 12V/12W/6000RPM WWW.MUGINUAV.COM...
