2-WAY RADIO MODEL
PR 3100 DX
Nothing comes close to a Cobra
®
Owner's Manual
Printed in Philippines
Part No. 480-129-P
English

Making Life Easier And Safer

Introduction
Staying in touch with your family and friends is
convenient and easy when using your microTALK
radio. Some of the many uses you will discover include:
Communicating with others while hiking, biking, and working; keeping
track of family and friends at a crowded public event; checking with
travel companions in another car; talking with neighbors; arranging
meeting spots with others while shopping at the mall.
Secure your microTALK
Belt Clip
radio while on the go.
Carrying your microTALK
easy when using the belt clip or wrist strap.
The belt clip easily attaches to your belt, purse,
Wrist Strap
or backpack. Simply squeeze the clip and place
it where you prefer.
Customer Assistance
For Assistance In Canada or the U.S.A.
In this user's manual, you should find all the information you need
to operate your microTALK
®
radio. If you require further assistance
after reading this manual, Cobra
customer assistance services:
Automated Help Desk
English only. 24 hours a day, 7 days a week 773-889-3087 (phone).
Customer Assistance Operators
English and Spanish. 8:00 a.m. to 6:00 p.m. CT,
Monday through Friday (except holidays) 773-889-3087 (phone).
Questions
English and Spanish. Faxes can be received at 773-622-2269 (fax).
Technical Assistance
English only. www.cobra.com (on-line: Frequently Asked Questions).
English and Spanish. productinfo
For Assistance Outside Canada, the U.S.A. or in French
Contact Your Local Dealer
For more information or to order any of our products,
please visit our website: www.cobra.com
A1 English
®
®
®
radio with you is
®
Electronics offers the following
cobra.com (e-mail).
@
©2003 Cobra
Electronics Corporation
®
6500 West Cortland Street
Chicago, Illinois 60707 USA
www.cobra.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the pmnPR3100DX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cobra pmnPR3100DX

  • Page 1: Making Life Easier And Safer

    2-WAY RADIO MODEL PR 3100 DX Nothing comes close to a Cobra ® Introduction Staying in touch with your family and friends is convenient and easy when using your microTALK radio. Some of the many uses you will discover include: Communicating with others while hiking, biking, and working;...
  • Page 2: Product Features

    Product Features Introduction Wrist Strap Connector Belt Clip Compartment Battery Door Antenna External Speaker/ Microphone Jack Talk Button Light/ Max Range Button A2 English Introduction Features • 2-Way Radio With up to a 13 km range • 22 Channels Seven (7) shared with Battery FRS/GMRS,...
  • Page 3: Caring For Your Microtalk

    Introduction Operation Caring For Your microTALK Your microTALK ® radio will give you years of trouble-free service if cared for properly. Handle the radio gently. Keep the radio away from dust. Never put the radio in water or in a damp place. Avoid exposure to extreme temperatures.
  • Page 4: Using Your Radio

    Using Your Radio Operation Turning On Your microTALK On/Off Power To Turn On Your Radio: 1. Rotate the On/Off Volume knob clockwise to turn On your radio and adjust the volume. A series of tones will indicate the radio is On. Your microTALK ®...
  • Page 5 Using Your Radio Operation Volume Volume Knob To Adjust The Volume: 1. Rotate the On/Off Volume knob. Call Button Call Button To Alert Another Person That You Are Calling: 1. Press and release the Call button. The other person will hear a two (2) second call tone.
  • Page 6 Using Your Radio Operation Speaker/Microphone Jack Your microTALK ® radio can be fitted with an external Speaker/ Microphone, freeing your hands for other tasks. Contact your local Cobra ® dealer or Cobra ® directly for optional charger accessories. Only Cobra ®...
  • Page 7 Mode Functions Operation CTCSS Privacy Codes CTCSS (Continuous Tone Coded Squelch System) is an advanced tone coding system allowing you to select one (1) of 38 privacy codes to reduce interference from other users on the channel. If you are using a privacy code, both radios must be tuned to the same channel and privacy code to communicate.
  • Page 8 Mode Functions Operation Ten (10) Memory Locations Your microTALK ® radio has Ten (10) Memory Locations for storing your most frequently used channels and channel/privacy codes. These Memory Locations can be selected individually or can be scanned. (See page 16 for memory location scan.) To Program A Memory Location: Mode Button 1.
  • Page 9 Mode Functions Operation To De-Program A Memory Location: Mode Button 1. Press the Mode button until the Memory icon and the memory location flash on the display. 2. Press the Channel Up or Channel Down Memory Icon button to select the memory location (0 through 9).
  • Page 10 Mode Functions Operation During Channel Scan (while not receiving a transmission), You Can Choose From The Following: a. Press and hold the Talk button to communicate on the channel or channel/privacy code that was displayed before you entered mode functions or the channel on which, during scanning, you last received a transmission.
  • Page 11 Mode Functions Operation Memory Location Scan Your microTALK ® radio can automatically scan up to ten (10) programmed Memory Locations. If there are one (1) or fewer memory locations programmed in your radio, the scan memory locations option will not be available. To program at least two (2) memory locations, see program memory locations on page 10.
  • Page 12 Mode Functions Operation VibrAlert ® And Call Tones Your microTALK ® radio can alert you to incoming signals by sounding an audible call tone, by vibrating silently, or both. To Change Call Settings: Mode Button 1. Press the Mode button until the Call Setting icon flashes on the display.
  • Page 13: General Specifications

    General Specifications Operation General Specifications A. FRS/GMRS B. Receiver Frequency Allocation and 1. Sensitivity Compatibility For 12 dB SINAD ..dBm For Call Signal Detection ..dBm Important: Please note that Cobra ®...
  • Page 14: Product Service

    Licensing and Product Service Customer Assistance Important: FCC RF Exposure Requirements: For body-worn operation, this radio has been tested and meets the FCC RF exposure guidelines when used with Cobra ® accessories supplied or designated for this product. Use of other accessories may not ensure compliance with FCC RF exposure guidelines.
  • Page 15: Warranty

    Warranty Warranty Limited 1-Year Warranty For Products Purchased in Canada Your new Cobra ® GMRS is covered by a one (1) year replacement warranty. If any manufacturing defect becomes apparent in this product within one (1) year from the original date of purchase, it will be replaced. Please return the GMRS radio to your dealer with original or copy of dated proof of purchase.
