User Manual
ELECTRIC SCARIFIER
Original User Manual
Advertisement
Table of Contents
Related Manuals for FERREX GLS36K
Summary of Contents for FERREX GLS36K
- Page 1 ALDI STORES LTD. PO BOX 26, ATHERSTONE WARWICKSHIRE, CV9 2SH ALDI STORES (IRELAND) LTD. PO BOX 726, NAAS, CO. KILDARE Visit us at www.aldi.com AFTER SALES SUPPORT 812263 +44(0) 1904727501 +353(0) 19022605 support@coreservice.co.uk YEAR MODEL: WARRANTY GLS36K 03/2022 Original User Manual...
-
Page 3: Package Contents
Package contents Package contents Device Scarifier roller (installed in device) Handlebar Collecting bag Screw (x4) Strain relief Washer (x4) Mounting bracket Quick release (x4) Screw anchor (x3) Connecting tube Screw for mounting bracket (x3) Rod (x2) Toothed washer "R" + "L" Cable clamp (x2) Adjusting screw (x2) User manual and warranty card (not... -
Page 4: Table Of Contents
Table of content Table of content Overview........................2 Package contents....................3 General information....................5 Reading and storing the operating manual..............5 Proper use...........................5 Explanation of symbols...................6 Safety........................7 Safety notes........................8 Safe handling instructions....................9 Notes on the power cable....................9 Before first use....................... 13 Check the device and scope of delivery................ -
Page 5: General Information
General information General information Reading and storing the operating manual This user manual is part of the electric scarifier (hereinafter also called "device"). It contains important information on how to set up and use the device. Before using the device, read the operating manual carefully, in particular the safety instructions. -
Page 6: Explanation Of Symbols
Explanation of symbols Explanation of symbols The following symbols and signal words are used in this user manual, on the device or on the packaging. This symbol provides you with useful additional information on handling and use. Declaration of conformity (see chapter “Declaration of conformity”): Products marked with this symbol meet all the applicable Community regulations of the European Economic Area. -
Page 7: Safety
Explanation of symbols Keep the connecting cable away from the blades. The working width of the roller is approx. 360 mm. The symbol shows the maximum sound power level L Tines of the fan roller should not touch the ground, b t end about 3 +3 mm mm above the ground. -
Page 8: Safety Notes
Safety This signal word provides a warning NOTE! about potential material damage. Safety notes WARNING! Risk of electric shock! Improper handling of the device, faulty electric installation or excessively high mains voltage may result in an electric shock. - Only connect the device to a properly installed socket. The mains voltage must match the value indicated on the rating plate. -
Page 9: Safe Handling Instructions
Safety WARNING! Risk of explosion! The roller of the scarifier or ejected objects can cause sparks when hitting metal. These sparks can ignite flammable liquids, gases or dust. - Do not use the scarifier in environments with a risk of explosion through flammable liquids, gasses or dust. - Page 10 Safety WARNING! Risk of injury for persons with impaired mobility or lack of experience and expertise! Improper handling of the device can lead to severe injuries or damage to the device. - Do not leave the device unattended when in use. - Do not allow others to handle the device until you have read and understood this operating manual or until you have been instructed about its intended use and the associated risks.
- Page 11 Safety - Avoid working on wet grass. You might slip and lose control of the device. - Do not use the device during rain or a thunderstorm. - Do not work on areas with an inclination of more than 20% as you might slip and lose control of the device.
- Page 12 Safety - Never operate the device with faulty safety devices/covers or without safety devices.
-
Page 13: Before First Use
Before first use Before first use Check the device and scope of delivery NOTE! Risk of damage! If opening the packaging with a sharp knife or other pointed objects, careless handling can damage the device. - Therefore, be very careful when opening. 1. -
Page 14: Attaching The Handlebar
Before first use Attaching the handlebar... - Page 15 Before first use 1. Place the toothed washers on the fixtures Use the toothed washer with the letter "R" for the right side and the one with the letter "L" for the left side. Make sure that the triangular markings of the toothed washers are positioned in line with the three line markings on the fixtures.
-
Page 16: Operation
Operation Operation Controls... -
Page 17: Notes On Scarifying
Operation Safety bar Fixture (x2) Discharge flap Power cable Carry handle Mains connection Height adjustment Start button Notes on scarifying The following instructions help you use the device effectively and safely. Improper handling of the device can cause damage to it. - Check the ground on which you want to use the device. -
Page 18: Selecting/Exchanging A Roller
Operation Selecting/exchanging a roller Aerator roller: Use this roller if you want to remove moss or thatch and collect it in the collecting bag Scarifier roller: Use this roller for regenerating lawn care. 1. Place the device on a level and dry surface. 2. -
Page 19: Adjusting The Handlebar Height
Operation - Set the height adjustment position "+ 10" (parked position/ transport position) to transport or park the device. - Set the working depth to the desired position to carry out the following work with the device: • Scarifying (scarifier roller) When scarifying, the roller should cut 3 to 5 mm into the soil. -
Page 20: Attaching The Collecting Bag
Operation Attaching the collecting bag 1. Lift the discharge flap 2. Hang the collecting bag into the device The device is completely mounted. Alternatively, you can also use the device without the collecting bag. In this case, the plant scraps removed from the roller remain on the ground and can be removed or spread on the lawn as mulch, depending on their composition. -
Page 21: Switching The Motor On And Off
Operation 5. Secure the power supply cable on the strain relief 6. Connect the power supply cable to the mains connection 7. Plug the power supply cable plug into a properly installed socket. Switching the motor on and off The motor is activated with a safety switch. When you let go of the safety bar, the motor stops. -
Page 22: Cleaning
Operation 4. Hold on to the discharge flap and move it until the discharge chute is covered again. Do not simply let go; the discharge flap may get damaged due to the spring action. 5. Empty the collecting bag completely and make sure that it is not damaged. Clear the lawn thatch material off the fabric as best as possible so air can flow properly through the fabric. -
Page 23: Maintenance
Cleaning 2. Disconnect the device by unplugging the power cable and remove the power cable from the strain relief 3. Thoroughly empty the collecting bag (see "Emptying the collecting bag"). Do not reattach it to the device. 4. Remove thatch etc. from the device and the collecting bag with a hand broom and check the collecting bag for damage. -
Page 24: Storage
Spare parts Part description Part number Collecting bag Strain relief Front wheel assembly set Rear wheel assembly set Storage NOTE! Improper storage of the device can result in damage. - Let the device dry before storing it. Residual moisture and cuttings remaining in the device can lead to mould formation. -
Page 25: Troubleshooting
Storage Storage conditions - Thoroughly clean the device (see “Cleaning”). - Store the device in a clean, dry, frost-protected place out of the reach of children. - Store the device in a location away from sunlight and other heat sources. - Always store device parts and accessories together with the device. - Page 26 Troubleshooting Problem Possible cause Remedy The engine power is failing. The ground is too hard. Adjust the working depth. The device housing is clogged. Clean the housing. The roller is worn. Exchange the roller. The scarifying result is not The roller is worn. Exchange the roller.
-
Page 27: Technical Data
Technical data Technical data Model GLS36K Item number 812263 Rated voltage/frequency: 230–240 V~/50 Hz Rated power: 1500 W Protection class: IP rating: IPX4 Idle speed: 3500 min Weight (net): approx. 13.7 kg Working width: 360 mm Working depth (mm): -12, -9, -6, -3, +3, +10... -
Page 28: Declaration Of Conformity
Original EU Declaration of Conformity MEROTEC GmbH Otto-Brenner-Str. 8, D-47877 Willich, Germany herewith declare under our own, sole responsibility that our product Electric Scarifier Model no. GLS36K complies with the following directives: 2006/42/EC Machinery Directive 2014/30/EU EMC-Directive 2000/14/EC Outdoor Noise Directive, amended by 2005/88/EC... -
Page 29: Disposal
Disposal Disposal Disposing of packaging Dispose of packaging according to type. Sort the paperboard and cardboard as waste paper and the film as recyclable material. Dispose of old electrical device This symbol indicates that this product may not be disposed of together with domestic waste in compliance with the (2012/19/EU) Regulation pertaining to waste electrical and electronic devices (WEEE).
