- Page 1 User’s Manual – AREBOS Solar Shower with mist spray Solar shower with mist spray (20L) AR-HE-SD20LS Please follow all security measures in this user´s manual to ensure a secure use. Thank you for trusting in AREBOS.
- Page 2 User’s Manual – AREBOS Solar Shower with mist spray List of content 1. Safety instructions ........3 1.1 Explanation of the symbols ......................3 1.2 General instructions ........................3 2. Parts list ........... 4 3. Installation ..........5 4. Use ............6 4.1 First Use ............................
- Page 3 User’s Manual – AREBOS Solar Shower with mist spray Please read and save these instructions. Read through this user’s manual carefully before using product. Protect yourself and others by observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property.
- Page 4 User’s Manual – AREBOS Solar Shower with mist spray 2. Parts list...
- Page 5 User’s Manual – AREBOS Solar Shower with mist spray 3. Installation Set up your solar shower in a place that is exposed to direct sunlight for as long as possible. 1. Mount the shower base to a concrete slab or a wood base with four bolts, nuts and gaskets.
- Page 6 User’s Manual – AREBOS Solar Shower with mist spray 4. Use 4.1 First Use 1. Turn the shower handle to FULL ON HOT position. Note: Filling the tube with the valve in hot position ensures no air pockets are trapped in the shower.
- Page 7 User’s Manual – AREBOS Solar Shower with mist spray 5. Technical specifications Model AR-HE-20LS Volume of water tank 20 l Water temperature Max. 140° F (60° C) Material Plastic, chrome plated Size of the shower 48.43 in (123cm) Size mounting plate of the shower 7.1 x 5.7 in (18 x 14.5 cm)
- Page 8 User’s Manual – AREBOS Solar Shower with mist spray EU Declaration of Conformity Canbolat Vertriebs GmbH, Gneisenaustraße 10-11, 97074 Würzburg, Germany, Hereby declare that the product named below, seen its design and construction as well as according to our sales, has been complied with the relevant and basic health and safety EU-requirements.
