PL7
3D Printer User Manual
V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PL7 and is the answer not in the manual?

Questions and answers

Summary of Contents for Deprag PL7

  • Page 1 3D Printer User Manual V1.0...
  • Page 2 Dear Consumers: Thank you for choosing our products.For the best experience, please read the instructions before operating the Printer. Our teams will always be ready to render you the best services. Please contact us via the phone number or e-mail address provided at the end when you encounter any problem with the Printer.
  • Page 3: Table Of Contents

    Contents Introduction 01-01 Parameters 02-02 Parts List 03-03 Interface Information 04-04 05-08 Level Platform Load Resin 09-09 10-10 Release Film Instructions USB Disk Printing 11-14 15-16 WIFI Print Wiring Connection 17-17 Troubleshooting 18-19 After-Sales Service Card 20-22...
  • Page 4: Introduction

    1. Introduction Limit switch Air filter USB port Metal screw Power socket Metal screw Resin vat Leveling screw Touch screen Buliding platform...
  • Page 5: Parameters

    2. Equipment Parameters Basic Parameters Model Software language English Print method U disk / WIFI X/Y-axis resolution 0.05mm / 3840*2400 0.025mm-0.1mm(layer thickness) Z-axis resolution Print speed 1-4S/ layer Castable Wax Resin, Dental model resin, Common rigid photosensivie resin, Standard resin, Special resin Hight hardness, High toughness, Biocompatible Resin.
  • Page 6 3. Package Content Resin vat 3D printer Print platform Tool list U disk x 1 Screwdrivers x 1set Brush x 1 Plastic blade x 1 Resin filter x 4 Metal blade x 1 Disposable latex Power cord x 1 Calibration card x 1 gloves x 1 Calibration Card 校准卡片...
  • Page 7: Interface Information

    4. Interface Information Setting Note: The UI is only for reference only and shall be subject to the actual UI.
  • Page 8: Level Platform

    5. Level Platform Note: The printing platform has been leveled at the factory. If it needs leveling due to transportation or other reasons, please follow the steps below to adjust the printing platform. 1. First raise the platform, then loosen rubber screws on the left 2.
  • Page 9 5. Level Platform If the platform does not stick to the print screen, do as the following: 1. After unscrewing the leveling screws, place the calibration card on the printing platform 2. Gently press the platform and tighten 4 screws clockwise, press“Leveling"...
  • Page 10 5. Level Platform Note: The UI is only for reference only and shall be subject to the actual UI.
  • Page 11: Load Resin

    6. Load Resin Pour the UV photosensitive resin into the resin vat. The slot capacity is 500ml/1000ml. 1000ml 500ml Tips: How to change resin: Caution : Resin may cause skin irritation or an allergic Take out the resin vat slowly, pour out the remaining resin into the container, clean the resin skin reaction.
  • Page 12: Release Film Instructions

    7. Release Film Instructions Installation steps First, remove the 14 screws at the bottom of the vat and take down the old release film. Parameters Prepare the new release film, peel off the the protective films on both sides of the release film. Align the holes and fit the release film on the clamping ring.
  • Page 13: Usb Disk Printing

    8.USB Disk Printing DEPRAG 3D BOX DEPRAG 3D BOX ② ① ① 1. Slice ② 1. Open the Meride 3D BOX slice software, click “Add printer” 2. If the model needs to add support, click the upper left icon① DEPRAG 3D BOX DEPRAG 3D BOX select printer model and click “Add”...
  • Page 14 8.USB Disk Printing DEPRAG 3D BOX 2. Print USB port 2. Insert the U disk → press the print button. 1. Generate cxdlp file, and save the file to U disk. 1 00 3. Press "Start" button 2. Choose to use parameters;...
  • Page 15: Wifi Print

    9. WIFI Print DEPRAG 3D BOX DEPRAG 3D BOX ① ② ① Slice ② 1. Open the Meride 3D BOX slice software, click “Add printer” 2. If the model needs to add support, click the upper select printer model and click “Add” then click “open”...
  • Page 16: Wiring Connection

    10.Wiring Connection UL LED fan port Exhaust fan Power Supply port UV LED POWER EN port Z motor driver port Z ends top USB HOST port LCD resin panel USB OTG port RGB screen port...
  • Page 17: Troubleshooting

    10.Troubleshooting...
  • Page 18: After-Sales Service Card

    11.After-Sales Service Card DEPRAG Please read the user manual and warranty card carefully before the use. For any service, Please priorly contact local seller or contact us via Email: info@depragdental.com for support. See depragdental.com / for specific warranty information about your product and procedures to act on a warranty claim.
  • Page 19 Notes...
  • Page 22 DEPRAG (Zhengzhou) Dental Technology Co., Ltd. DEPRAG (Zhengzhou) Dental Technology Co., Ltd. Add: No.14, No.8 Floor, Building 7, No.289 West Third Ring Road, High-tech Industrial Development Zone, Zhengzhou City, Henan Province, China Web: depragdental.com E-mail: info@depragdental.com...
