Albatron K7I741CX User Manual page 7

Serial ATA Connector (Optional):
Two SATA connectors that support up to two SATA hard disk drives
Supports SATA 1.0 specification which provides 1.5 Gb/s transmit rate
Supports RAID 0/ 1 mode
I/O facility Connectors:
One multi-mode Parallel Port is capable of supporting the following specifications:
1. Standard & Bi-direction Parallel Port
2. Enhanced Parallel Port (EPP)
3. Extended Capabilities Port (ECP)
Support one serial port and one VGA port
Supports one PS/2 mouse port and one PS/2 keyboard port
Supports one IrDA header, two USB headers, and one COM header compatible with
external devices connected
Universal Serial Bus:
Two onboard USB 2.0/ 1.1 ports
Two front USB 2.0/ 1.1 headers come with this mainboard supporting four additional
USB 2.0/ 1.1 ports to be set
Supports a maximum of six USB 2.0/ 1.1 ports for compliant devices
Onboard LAN Chip:
Supports 10/100 Mbps Ethernet LAN
Supports Auto-negotiation (NWAY) function of full/half duplex operation for both 10
Mbps and 100 Mbps
BIOS:
Phoenix-Award™ BIOS
Supports APM 1.2
Supports ACPI 2.0 power management
Green Function:
Supports Phoenix-Award™ BIOS power management function
Supports system-wake-from-power-saving-mode by keyboard or mouse touching
K7I741CX Mainboard
3
