HOGA-C0554-0
note:
1. Please do not exceed the rated load, otherwise it will cause damage
to the monitor or personal injury.
2. Be sure to follow the instructions in the manual. Improper installation
may result in damage to the product or personal injury.
3. Please use our tools and accessories to install, otherwise it will
cause damage to the product.
4. Make sure that the support surface can safely support the weight of
the support equipment and all accessories.
5. This product contains small parts that can cause serious personal
injury if swallowed. Keep out of reach of children.
6. This product is for indoor use only. Outdoors can cause damage to
the product.
important:
Make sure you have received all the parts based on the list provided
before installation. If any parts are missing or damaged, please contact
your supplier.
maintain:
Please check the workbench at regular intervals (at least every three
months) to see if the workbench is stable and there are any screws
that fall off due to long-term use. If there is a safety hazard, please re-
place the accessories or harden the installation in time.
