- Page 1 TCS series Any Question, contact us! Email: sales@njbonitalab.com Whatsapp/Wechat: +8613951079382 Note: Please recharge the scale before first operation. Please warm-up the scale over 5 minutes.
-
Page 3: Disclaimer Notice
You have purchased a quality precision weighing instrument that requires handling with care. Read entire contents of this Operation Manual prior to operating your new instrument. Disclaimer Notice Calibrate your instrument using reference weights of the appropriate tolerance (class). An instrument can be no more accurate than the standard to which it has been compared. - Page 4 Introduction Thank you for choosing one of our instruments. Your instrument is designed and manufactured to the most rigorous standards in order to give you years of service. First, check the contents of the shipping carton. You should find the following: *Manual *Instrument *Power cable Next, follow the instructions for installing your instrument.
-
Page 5: Specification
Specification Model TCS 1505 TCS301 Max weigh 15kg 30kg scope Precision level value of scale 0.5g division Repeatable ± g ± g tolerance Linear ± g ± g tolerance Stable time ≈2s Pre-heat time 10-30 minutes Operation 0±40℃ temperature 285 x 240 mm Pan diameter Net weight ≈... - Page 6 Preparation This product is intended for indoor use. 1. Select a suitable work area. 2. Work area should be relatively free from drafts and vibrations. 3. Work surface should be level and rigid. 4. Do not locate near magnetic materials or equipment/instruments which use magnets in their design.
- Page 7 Function keys 1. 0 -9 Numeric keys：Used for setting numeric data . ：Used for set the decimal position of the tare weight, sample weight 3. SAMPLE：sample number, sample weight, or limit number of checking. Used for parts counting. 4. WT SET：Used for the alternation of changing normal counting and check operation.
-
Page 8: Operation
7. TARE: Reduce gross weight on pan as tare weight. 8. ZERO：Capture the zero of the scale 9. M+：Memory accumulate 10. M-：Memory clear 12. CE：Clear all settings Operation A. Getting Started Turn the instrument on by pressing the power switch on. The display will down count from 999999…... - Page 9 If sample come with receptacle, but you just need to know weight of sample. Please use TARE key. For reducing the tare weight from the scale, there are two methods, one is press button tare and the other is keyboard tare. 1.
- Page 10 put on the pan.(sample size can be changeable) b. Input the quantity of samples and Press the SMPL key c. The averaged piece weight will be calculated automatically. Now you can count bulks. 2. PIECE WEIGHT setting (In case of piece weight is already known.) a.
- Page 11 D. Accumulation function 1.Press M+ key can be accumulating the sub-total piece counts one time. The next accumulation must be return to zero and got new piece counts. 2. Press M+ key can be used for alternation of changing normal counting and memory data recalling 3.
- Page 12 On: when value is stable, then alarm Off: scale will alarm even if the value is Stable not stable “ ON" : The red and yellow backlight for alarm mode are turned on . "OFF": Alarm backlight are turned off. 2.
- Page 13 Program settings Password “4 1 5” to enter, The key “CHECK SET” to enter and confirm; The key “SAMPLE” to choose or to next step. Display Option Parameter diu-Fun_01 Division 1 2 5 10 20 50 Pnt-Fun_02 Decimal point 0 0.0 0.00 0.000 0.0000 CAP-Fun_03 Capacity If cap is 30kg, 30.000...
- Page 14 Calibration Enter the Program settings, use SMPL key to chose the item (CAL-Fun-04), then press CHECK SET key to enter, use SMPL key to make the number to 1, then press CHECK SET key, the LCD display inPut, use Numeric keys(0-9) to set the calibration weight.
-
Page 15: Maintenance
is time to recharge. If it need to use, it may continue about ten hours. When the message “LoBAt” appears in the window of piece weight, which indicate the power of battery is exhausted. Please turn off the power switch immediately and begin to recharge the battery to prolong its life.
