Atlantis HEALTHYBAND User Manual

Smartband
Hide thumbs
Table of Contents
  • Exemption Clause
  • Información Técnica
  • Guide de L'utilisateur
  • Technical Information
  • Technische Spezifikationen
  • Manuale Utente
  • Informazioni Tecniche
  • Manual de Utilizador
  • Especificações Técnicas

Advertisement

Available languages
  • EN

Available languages

  • ENGLISH, page 1

Quick Links

Download this manual
HEALTHYBAND
Smartband
User manual
BXSEASHR02
Technical information
Display: 0,96", 80x160 resolution
Bluetooth: 4.0
Battery: Polymer-lithium
Battery capacity: 90mAh
Battery life: 3 days (normal use) / 7 days (stand-by)
Charging time: 1.5-2 h
Charging type: clip charge
Waterproof rating: IP67
Sensor: G-Sensor 3 axis
Strap: Silicone
Strap size: 240 x 16 x 11,9 mm
Working temperature: -10°C - 45°C
Weight: 20 g
System requirements: Android 4.4 and following versions, iOS 8.0 and following versions
APP: Wearfit
Compatibility
• iOS 8.0 and above
• Android 4.4 and above
HOW TO CHARGE YOUR FITNESS BAND
Connect the fitness band to the included USB charging clip. Once connected, connect the
USB to a USB power source, such an 1A adapter, a laptop or a power bank for a minimum of
15 minutes. Then, the device will turn on automatically.
It takes 2 hours to charge the device completely. Once it has been charged fully, the device
can be on up to 7 days.
HOW TO TURN YOUR FITNESS BAND ON AND OFF
Long press the central button when your fitness band is off to turn it on. Once the device
has vibrated, short press the central button to start moving from one function to another.
Long press the central button when your fitness band is on to turn it off. An "ON/OFF" icon
will appear on screen. Short press and then long press until the device vibrates to turn it
off. Long press to escape the "ON/OFF" screen and go back to functions. Please note it is
not possible to turn the device off from the stopwatch/find phone/SMS/background func-
tion.
HOW TO PAIR YOUR FITNESS BAND WITH YOUR SMARTPHONE
1. Search "Wearfit App" on App Store or Google Play, or scan the
following QR code:
2. Open your device Bluetooth settings before pairing
3. Tap "Scan device" to select the fitness band you want to pair.
Note: Some Android phones cannot find the fitness band using
just Bluetooth at first. Please, enable the GPS function in your
phone if this happens. If your phone still cannot find the device,
enable and disable flight mode.
What to do if your smartphone cannot find the fitness band and, therefore, cannot
connect to it
Please, ensure your smartphone Bluetooth is on and that its operating system is Android
4.4 or above versions / iOS 8.4 or above versions. Also, make sure the fitness band is fully
charged.
If connection is not possible yet, enter the smartphone settings. Then, enter the app
management settings, allow all permits and turn the GPS location. Finally, restart the phone
and try to connect again.
What to do if the app does not recognize connection or shows the fitness band has a 0%
battery level

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HEALTHYBAND and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Atlantis HEALTHYBAND

  • Page 1 HEALTHYBAND Smartband User manual BXSEASHR02 Technical information Display: 0,96”, 80x160 resolution Bluetooth: 4.0 Battery: Polymer-lithium Battery capacity: 90mAh Battery life: 3 days (normal use) / 7 days (stand-by) Charging time: 1.5-2 h Charging type: clip charge Waterproof rating: IP67 Sensor: G-Sensor 3 axis...

  • Page 2: Exemption Clause

    The app has not been connected to the fitness band successfully. Please, try to connect again. What to do if the app cannot connect to the fitness band Please, scroll down and refresh the main page. Data should be synced and displayed on the app.
  • Page 3 Hereby, Atlantis Internacional S.L. declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EC. The features and functions described in this manual are based on tests made by Atlantis Internacional S.L. It is the user’s responsibility to examine and verify the product after its purchase.

  • Page 4: Información Técnica

    HEALTHYBAND Smartband Manual de usuario BXSEASHR02 Información técnica Pantalla: 0,96”, resolución 80x160 Bluetooth: 4.0 Batería: Polímero de litio Capacidad de la batería: 90mAh Autonomía: 3 días (uso normal) / 7 días (en reposo) Tiempo de carga: 1.5-5 h Tipo de carga: clip de carga...
  • Page 5 Qué hacer si su smartphone no encuentra la pulsera deportiva y no se conecta La conexión ha fallado. Inténtelo de nuevo. Qué hacer si la app no se conecta a la pulsera deportiva Deslice hacia abajo la página principal de la app para actualizarla. Los datos deberían sincronizarse y aparecer en la app.
  • Page 6 • No desmonte ni modifique el producto. Estas acciones invalidan la garantía. Nota Legal Por medio de la presente Atlantis Internacional, S.L, declara que este producto cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 2014/53/CE.

  • Page 7: Guide De L'utilisateur

    HEALTHYBAND Smartband GUIDE DE L'UTILISATEUR BXSEASHR02 Technical information Écran : 0,96", résolution 80x160 Bluetooth : 4.0 Batterie : Lithium polymère Capacité de la batterie : 90mAh Autonomie de la batterie : 3 jours (utilisation normale) / 7 jours (stand-by) Temps de charge : 1,5-5 h Type de chargement : clip de chargement Résistance à...
  • Page 8 Que faire si l’application ne reconnaît pas la connexion ou indique que le niveau de batterie du bracelet de fitness est de 0 % ? L’application n’est pas correctement connectée au bracelet de fitness. Veuillez réessayer de vous connecter. Que faire si l’application ne peut pas se connecter au bracelet de fitness ? Faites défiler vers le bas et actualiser la page principale.
  • Page 9 Mentions légales Atlantis Internacional, S.L., déclare que ce produit est conforme aux exigences essentielles et à tout autre règlement applicable ou réglementaire en vertu de la directive 2014/53/CE. Les fonctions et caractéristiques décrites dans ce manuel sont basées sur des tests effectués par Atlantis Internacional S.L.

  • Page 10: Technische Spezifikationen

    HEALTHYBAND Smartband BEDIENUNGSANLEITUNG BXSEASHR02 Technische Spezifikationen Display: 0,96", Auflösung 80 x 160 Bluetooth: 4.0 Batterie: Polymer-Lithium Batteriekapazität: 90 mAh Batterielebensdauer: 3 Tage (normale Nutzung)/7 Tage (Stand-by) Aufladezeit: 1,5 bis 2 Std. Aufladungsart: Clip-Ladung Wasserdicht: IP67 Sensor: 3-Achsen-G-Sensor Armband: Silikon Maße des Armbands: 240 x 16 x 11,9 mm Arbeitstemperatur: -10°C –...
  • Page 11 Wenn das oben genannte nicht funktioniert, gehen Sie in die App-Einstellungen und stellen Sie die Werkseinstellungen wieder her. Starten Sie dann das Fitnessband neu und verbinden Sie es erneut mit der App. SO VERWENDEN SIE DAS FITNESSBAND Funktionen Zeit-/Datumsanzeige: Zeigt die Uhrzeit, den Wochentag und das Datum an. Was ist zu tun, wenn die angezeigte Zeit nicht korrekt ist? Es ist möglich, dass die Zeit des Fitnessbands und die tatsächliche Zeit nicht übereinstimmen, wenn das Gerät keinen Strom mehr hat und aufgeladen wurde.
  • Page 12 Es liegt in der Verantwortung des Benutzers, das Produkt nach dem Kauf zu untersuchen und zu überprüfen. Technische Daten und Design können ohne vorherige Ankündigung geändert werden. Atlantis Internacional S.L. ist nicht verantwortlich und haftet nicht für persönliche Verluste oder Verletzungen, wirtschaftliche Verluste, materielle Verluste oder Schäden an Ihrem Gerät aufgrund von falscher Verwendung, Missbrauch oder unsachgemäßer Installation des Produkts.

  • Page 13: Manuale Utente

    HEALTHYBAND Smartband MANUALE UTENTE BXSEASHR02 Informazioni tecniche CPU: XW52832 Cortex ® Schermo: 0,96”, risoluzione 80 x 160 Bluetooth: 4.0 Batteria: polimeri di litio Capacità batteria: 90 mAh Durata della batteria: 3 giorni (uso normale)/7 giorni (modalità riposo) Tempo di ricarica: 1,5 - 2 ore Tipo di ricarica: clip di ricarica Impermeabilità: IP67...
  • Page 14 bracciale fitness sia completamente carico. Se la connessione non è ancora possibile, entrare nelle impostazioni dello smart- phone. Poi, entrare nelle impostazioni di gestione delle app, attivare tutti i permessi e la posizione GPS. Infine, riavviare il telefono e provare a connettersi di nuovo. Cosa fare se la app non riconosce la connessione o se mostra che il bracciale fitness ha la batteria al 0% L'app non è...
  • Page 15 Atlantis Internacional S.L. non è responsabile e non sarà mai da ritenersi responsabile per qualsiasi mancato funzionamento, comunicazione e connessione tra il prodotto e i dispositivi dotati di Bluetooth.

  • Page 16: Manual De Utilizador

    HEALTHYBAND Smartband MANUAL DE UTILIZADOR BXSEASHR02 Especificações Técnicas Ecrã: 0,96”, resolução 80x160 Bluetooth: 4.0 Bateria: Polímero de lítio Capacidade da bateria: 90mAh Duração da bateria: 3 dias (uso normal) / 7 dias (stand-by) Tempo de carregamento: 1,5-2 h Tipo de carregamento: carregamento por clip Classificação de impermeabilidade: IP67...
  • Page 17 GPS. Finalmente, reinicie o telefone e tente ligar novamente. O que fazer se a aplicação não reconhecer a ligação ou mostrar que a pulseira de fitness tem um nível de bateria de 0% A aplicação não foi associada com sucesso à pulseira de fitness. Por favor, tente ligar-se novamente.
  • Page 18 As especificações e o desenho do modelo podem ser alterados sem aviso prévio. A Atlantis International S.L. não é responsável nem poderá nunca ser responsabilizada por quaisquer perdas ou danos pessoais, perdas económicas, perdas materiais ou quaisquer danos devido a utilização indevida, abuso ou instalação inadequada do produto.
