Wisenet TMS Console

User Manual

VER 1.0

When installing or using this product, visit the o cial website of Hanwha Techwin

(http://www.hanwha-security.com) to check for the latest software version and update.

Table of Contents

Need help?

Do you have a question about the TMS Console and is the answer not in the manual?

Questions and answers

Summary of Contents for Wisenet TMS Console

Page 1 Wisenet TMS Console User Manual VER 1.0 When installing or using this product, visit the o cial website of Hanwha Techwin (http://www.hanwha-security.com) to check for the latest software version and update.
Page 2: User Manual Guide
User Manual Guide This document is for the operator of the Wisenet TMS Console program. Please read this user manual rst to use the product correctly. y This user manual explains how to use the product based on the defaults and default screens of this product.
Page 3: Table Of Contents
Contents User Manual Guide ............................. 2 Target Audience ..............................2 How to Use the Product ............................ 2 Copyrights Information ............................. 2 System Overview ................6 Main Features ..................................6 System Con guration ..............................8 Getting Started ..................9 Running the Program ............................9 Signing into the Program ..........................
Page 4 Event Video Search ............................38 Video Screen Control ............................39 Recorded Video Capture ...............................39 Zoom in / out the recorded image ..........................40 About Shortcut Menu ..............................42 Recorded Video Export ............................ 43 Video Export ..................................43 4 ┃ Wisenet TMS Console User Manual...
Page 5 Connecting to an External Device ..........................58 Installing Paragon software ............................59 Opening the Menu Page ..........................61 Event Search and Export ..........................63 Con guring TMS Console Preferences ......65 Opening the Menu Page ..........................65 Con guring General Settings ........................66 Screen Setting ..............................68 Appendix ....................
Page 6: System Overview
System Overview Wisenet TMS is a solution for monitoring the route of trains and buses, managing events that occur during operation, and archiving recorded images in the vehicle. TMS Console GPS Satellite GPS Signal Wi-Fi TMS Server Main Features Vehicle Route Search The navigation of the vehicle is displayed on the map using GPS information, recorded image, and event information archived from the mobile NVR.
Page 7 Archive An automatic backup of GPS information and images stored in the mobile NVR uses Wi-Fi for the remote retrieval and archiving of data from NVR. Vehicle Base TMS Console Wi-Fi Camera-Recorded Video TMS Server GPS data Event information Export to External Storage A manual backup of GPS information and images stored in the mobile NVR takes data directly from the mobile NVR's disk and backs it up.
Page 8: System Con Guration
System Con guration Wisenet TMS (Transport Monitoring System) is con gured as follows: Network Camera Wisenet TMS ALARM NETWORK BACKUP POWER DV25 DIGITAL VIDEO RECORDER SRN-475S Mobile NVR TMS Server TMS Console TMS Console y You can search or play the videos recorded by the camera and a vehicle’s driving route, which are archived in TMS Server on the map.
Page 9: Getting Started
When you run the TMS Console program, the following login screen appears: Note y Before you can log in to the TMS Console program, however, all service statuses on TMS Server must be marked as Started. y The service status of TMS Server can be checked in the Service Status tab of TMS Service Manager.
Page 10 The Login restrictions setting can be changed in Con guration under the menu. Con guration > System > Maintenance > Domain > Login restrictions y Change your Password periodically for security purposes. 10 ┃ Wisenet TMS Console User Manual...
Page 11: About Screen Con Guration
TMS Console > Settings > Setup > Startup option Screen The screen of TMS Console is con gured as follows: Note The screen of TMS Console may be con gured di erently depending on the menu selected by the user. ┃ 11 Getting Started...
Page 12 • Video search: Time Line and Media Control Bar Search result screen You can check the search results such as route, image, and event. Added features You can use the add-ons provided by the program. 12 ┃ Wisenet TMS Console User Manual...
Page 13: About Menu Tab
Menu Description Note The menu of the TMS Console program consists of tabs. y You can freely move between the menu tabs and select a desired menu item. y You can also form a separate page to operate it like a separate program.
Page 14: Closing The Menu Page
To separate a menu page, drag and drop the menu tab. Note y You can freely move and insert separate menu pages between di erent menus. y You can use separate menu pages as separate programs. 14 ┃ Wisenet TMS Console User Manual...
Page 15: Add-Ons
Selecting Logout from the list box will log you out. You can see the ID of the logged-in user. You can check the performance of the PC where TMS Console is installed. • CPU usage: Displays the current CPU usage of the PC.
Page 16: Route Search
You can search the route of the vehicle stored in TMS Server by date and time and event. You can also play back and monitor the retrieved route. You can immediately check the events occurred as well. Opening the Menu Page Launch TMS Console. For more information, refer to Running the Program.
Page 17 In case of normal login, the following initial screen appears: Note The TMS Console screen may be con gured di erently depending on the menu selected by the user. If you cannot see the Route search tab upon program startup, click the [+] button on the upper left, and then select Route search in the Add tab dialog box.
Page 18: Moving Route Search
Select a device to search. Multiple devices can be selected and retrieved at once. Note You can select a desired device directly by entering the search target directly on the search window. Select the date and time to search. 18 ┃ Wisenet TMS Console User Manual...
Page 19 Click the SEARCH button. The saved route and the event that occurred are then displayed on the search results window. y The search results list displays events for devices, cameras, alarm inputs, and alarm outputs. y A speed chart of the selected device is displayed below the search results window. You can capture the movement path of your device or run a map trek.
Page 20 You can zoom in and out of the map. You can also use the mouse wheel to zoom in and out of the map. Displays a list of events that occurred during vehicle operation. 20 ┃ Wisenet TMS Console User Manual...
Page 21: Speed Chart
Speed Chart The speed chart is displayed in 1 day (24 hours). When you move the position control bar to the left or right, the position of the vehicle at that point appears on the map. When you start playback, the route of the vehicle is played back, and you can search for the route while controlling the playback speed.
Page 22 You can also use the mouse wheel to change the time display unit of the speed chart. The speed limit line set on the speed chart is displayed. As you move the time slider, the vehicle location at that point is displayed above the map. 22 ┃ Wisenet TMS Console User Manual...
Page 23: Using Map Tracking
Using Map Tracking You can search the route around the vehicle. Click the button. The vehicle is centered on the map screen, and you can trace the route as the map moves around the vehicle. y If you have searched for multiple devices, select the desired device from the list of discovered devices and start tracking the map.
Page 24: Checking Events
Terminology. Displays the event occurrence time based on the system time of the Occurred (Device) device. Note By ltering the search results list by item, you can quickly search for the desired list. 24 ┃ Wisenet TMS Console User Manual...
Page 25: Using Instant Viewer
Using Instant Viewer If there is a recorded image in the search result list, you can check the image of the event. Click in the search results list. Instant viewer runs, and the image at the time of the event and the GPS information of the vehicle are shown together.
Page 26: Speci C Area Search
The Geofence function lets you search the route and event of a vehicle within a speci ed area. Select a device to search. Select the date and time to search. Click the Advanced option button. Click the checkbox of the Set area, followed by 26 ┃ Wisenet TMS Console User Manual...
Page 27 Drag the area you want to search on the map. Click the SEARCH button. You can check the route and the event within the area set by the advanced option. ┃ 27 Route Search...
Page 28: Capturing A Route
Navigate to the location you want to capture and click the button. Click the OK button. The image is saved in the speci ed path. Note To change the save path of the captured image, see Con guring TMS Console Preferences. 28 ┃ Wisenet TMS Console User Manual...
Page 29: Export Gps Data
Export GPS data You can export to a le the latitude, longitude, and speed information for a device that is searching for a route. Note GPS information is exported in CSV le format. Search the route of the vehicle with the desired search conditions. Click the button.
Page 30: Video Search
You can search and play back the recorded images stored in TMS Server and mobile NVR. You can search recorded images by date and time or event. Opening the Menu Page Launch TMS Console. For more information, refer to Running the Program.
Page 31 In case of normal login, the following initial screen appears: Note The TMS Console screen may be con gured di erently depending on the menu selected by the user. If you cannot check the Video search tab at the start of the program, click the [+] button on the upper left, and then select Video search in the Add tab dialog box.
Page 32: Recorded Video Search
Videos stored in the mobile NVR can only be retrieved or played back when connected to Wi-Fi. When the mobile NVR is connected to Wi-Fi, the device will display Select the date and time to search. 32 ┃ Wisenet TMS Console User Manual...
Page 33 Click the SEARCH button. Recorded images, vehicle location information, and events appear on the search results window. y The search results list displays events for devices, cameras, alarm inputs, and alarm outputs. y By ltering the search results list by item, you can quickly search for the desired list. y The time line of the camera selected on the image screen is displayed below the search result window.
Page 34: About Timeline
• Play speed can be set to -1x, -2x, -4x, -8x, -16x, -64x. Video play can be stopped. You can fast-forward the video • Play speed can be set to 1x, 2x, 4x, 8x, 16x, 64x. Displays the play speed. 34 ┃ Wisenet TMS Console User Manual...
Page 35 Screen Number Detailed Feature Explanation Con guration If there is a recorded image, the interval bar is displayed in the time line. The interval bar of the time line is displayed in color according to the event type of the recorded image. For more information, refer to Event Video Search.
Page 36: Audio On/O
Clicking it once again will mute the audio. Changing the Video Screen Pattern You can change the split of the video screen. Click the button to select the desired screen pattern. 36 ┃ Wisenet TMS Console User Manual...
Page 37: Osd Show/Hide
You can show or hide the OSD information on the image. Click the button to set the desired state. Note The information displayed on the picture di ers depending on the OSD setting. For OSD setting, refer to Con guring TMS Console Preferences. ┃ 37 Video Search...
Page 38: Event Video Search
Click the Apply button. The recorded video of the selected event is displayed on the timeline. Note Event video can be played back only when there is video recorded at the time of event occurrence. For Event Terminology, see Event Terminology. 38 ┃ Wisenet TMS Console User Manual...
Page 39: Video Screen Control
Click the OK button. The image is saved in the speci ed path. y If Open details is enabled in the TMS Console settings, the Capture dialog box appears. You can set the display path and the information displayed in the image and save the captured image as jpg or bmp.
Page 40: Zoom In / Out The Recorded Image
The mini-map shows the location of the enlarged area in the original image. y To change the location of the mini-map on the video screen, click the mini-map and drag it to the desired location. y Press the button again to release the digital zoom. 40 ┃ Wisenet TMS Console User Manual...
Page 41 Zoom in and out an image You can enlarge a speci c area of the image by dragging it. You can also zoom in or out using the mouse wheel. Move the position of the enlarged image Clicking a speci c area of the image moves the position of the image. Likewise, clicking inside the square border of the mini map and dragging it to the desired position will move the position of the image.
Page 42: About Shortcut Menu
You can view the camera properties of the selected screen. In the Camera Camera properties Properties dialog box, you can check the camera name, device model, video resolution, video and audio codec, and camera functions. 42 ┃ Wisenet TMS Console User Manual...
Page 43: Recorded Video Export
Recorded Video Export The recorded images stored in TMS Server or mobile NVR can be exported to a le. Note y In the following cases, a new le will be created if you export the recorded video in AVI le format: –...
Page 44 Note When playing back the exported le in Backup Viewer, you must enter the password to play it. Remember your password. Click the Export button. Click the Cancel button to cancel the export. 44 ┃ Wisenet TMS Console User Manual...
Page 45: View Report
You can search the event log for GPS information, devices, and systems or export a list of detected events to a le. Opening the Menu Page Launch TMS Console. For more information, refer to Running the Program. When the Login dialog box appears, enter your ID and password and click the Login button.
Page 46 Note The TMS Console screen may be con gured di erently depending on the menu selected by the user. If you cannot see the Report tab at the start of the program, click the [+] button on the upper left and select the Report from the Add tab dialog.
Page 47: Event Log Search
Event Log Search GPS Event Search You can search the event log generated from the GPS information base when you drive. You can summarize the events that occurred or view them in detail by event item. In the Report menu page, click the GPS tab. Click the desired item.
Page 48 The number of events that occurred during the search period is counted. Click detail to view the details of the event. y You can set the event items to be displayed in the event list by clicking the button above the event list. 48 ┃ Wisenet TMS Console User Manual...
Page 49 View Event Log Details You can view the details of the events that occurred during the search period. y You can set the items to be displayed in the detailed list by clicking the button above the event list. y By ltering the event list by item, you can quickly search for the desired list.
Page 50: Device Event Search
Summary: You can see the number of events generated by each event item. y Video loss, Disk error, Fan error: You can search the log of the event. Note For Event Terminology, see Event Terminology. Set the search start time and end time. 50 ┃ Wisenet TMS Console User Manual...
Page 51 Click the SEARCH button. The search results then appear in the event list. View Event Log Summary The number of events that occurred during the search period is counted. Click detail to view the details of the event. y You can set the event items to be displayed in the event list by clicking the button above the event list.
Page 52: System Event Search
Server Log Check In the Report menu page, click the System tab. Click Server log. In Event lter, click the event item you want to search. Note For Event Terminology, see Event Terminology. 52 ┃ Wisenet TMS Console User Manual...
Page 53 Set the search start time and end time. Click the SEARCH button. You can view the details of the events that occurred during the search period. y You can set the items to be displayed in the detailed list by clicking the button above the event list.
Page 54 In the Report menu page, click the System tab. Click Archive status. The last archive log for each device registered with TMS Server then appears. Click the button to update the log list with the latest information. 54 ┃ Wisenet TMS Console User Manual...
Page 55: Event Log Export
Event Log Export You can export the retrieved event results to a le. In the Report menu page, search for the desired event log. For more information about event log search, see Event Log Search. Click the button above the event list. When the Export event log dialog box appears, set the path to save the log le.
Page 56: Event Terminology
An event occurs when video archiving is stopped or ended. Video archive failed An event occurs when video archiving fails. System power error An event occurs when the Mobile NVR system is not powered on. 56 ┃ Wisenet TMS Console User Manual...
Page 57 Device Input Event Name Description An event occurs when motion is detected in an area of interest set Motion detection for the camera. An event occurs when the Mobile NVR fails to receive a camera Video loss video. IVA (Intelligent Video An event occurs when an IVA is detected.
Page 58: Exporting External Storage Data
NVR, and export the event image to a le. Before Getting Started Connecting to an External Device After disconnecting the disk from the mobile NVR, connect the disk to the PC with TMS Server or TMS Console using the USB SATA adapter. TMS Console Mobile NVR Disk Security Cabinet 58 ┃...
Page 59: Installing Paragon Software
The software allows a hard disk that uses Linux le system to be read on Windows. y TMS Appliance includes the installation of Paragon software and license activation. Aside from TMS Appliance, also install TMS Console in a separate PC, and use the Paragon software only when using this function.
Page 60: Opening The Menu Page
Opening the Menu Page Launch TMS Console. For more information, refer to Running the Program. When the Login dialog box appears, enter your ID and password and click the Login button. 60 ┃ Wisenet TMS Console User Manual...
Page 61 In case of normal login, the following initial screen appears: Note The TMS Console screen may be con gured di erently depending on the menu selected by the user. If you cannot check the External storage tab at the start of the program, click the [+] button on the upper left, and then select the External storage in the Add tab dialog box.
Page 62 After selecting the disk to search, click the button. The tag window displays the name of the disk. Select the date and time to search. In Event lter, select the event you want to search for. 62 ┃ Wisenet TMS Console User Manual...
Page 63: Event Search And Export
Click the SEARCH button. The search results then appear in the list. Click the button to export the search list to a le. Files exported from an external storage device are saved in SEC le format. y Only the checked ( ) list to the left of the search list will be exported.
Page 64 Con guring TMS Console Preferences You can set the usage environment of TMS Console. Opening the Menu Page Launch TMS Console. When the Login dialog box appears, enter your ID and password and click the Login button. Click the button on the upper right.
Page 65: Con Guring Tms Console Preferences
Con guring General Settings You can set the general usage environment of TMS Console such as language, date and time, and capture path settings. Open the Setup menu page. Click the General tab on the upper left. You can set the following general items:...
Page 66 • Log out: For security purposes, you can automatically log out of TMS Console when there is no keyboard or mouse movement for a Screen lock / speci ed amount of time.
Page 67: Screen Setting
The camera name set in TMS Server is displayed by default. To use the camera name set in the mobile NVR, select the Name set by the device. • Show IP: The IP information of the mobile NVR can be displayed. ┃ 67 Con guring TMS Console Preferences...
Page 68 • Anti-aliasing: You can improve the aliasing phenomenon wherein the pixels look like a stairway when playing video in TMS Console. Using anti-aliasing will improve the quality of the image, but it can cause streaming to stop.
Page 69: Appendix
16 GB or above Windows 7/8/8.1/10 (64-bit) Windows 10 (64-bit) * Only 64-bit operating systems are * Only 64-bit operating systems are supported. supported. After installing the operating system and TMS Console, 20 GB of free space is required. ┃ 69 Appendix...
Page 70: Tms Console
Korean, English, Croatian, Czech, Danish, Dutch, Finnish, French, German, Greek, Languages Hungarian, Italian, Norwegian, Polish, Portuguese, Romanian, Russian, Serbian, Spanish, Supported Swedish, Taiwanese, Thai, Turkish Service Port Refer to the list of ports used in Wisenet TMS. Name Port Protocol TCP for Web Service (9999) System Manager...
