- Page 1 48001 Panel Mount 48004 Surface Mount LEA 109 TO BE READ IN CONJUNCTION WITH THE FULL INSTRUCTION MANUAL...
- Page 2 introduction compatibility • The HS Panel Mount reader operates with KMS Sharktooth HS dual and HS Mifare Tokens. • It connects to the KMS Simplekey 4 and Simplekey 3 systems and also operates with other manufacturers’ access control systems. Cabling •...
- Page 3 wiring guide KMS Reader Wiring Function +12v (Fused output from Reader Interface) Black Blue Signal Data Yellow Brown Connect to LED to enable sounder LED Function Reader LED Behaviour Static Red Door Locked Red Flashing Low Voltage Momentary Green Token Detected/Access Denied Green for timed period Access Authorised Yellow...
- Page 4 YOU MAY NOT EVEN PARTIALLY REPRODUCE THIS DOCUMENT CAME RESERVES THE RIGHT TO MAKE ANY CHANGES TO THIS DOCUMENT AT ANY TIME THE DATA AND INFORMATION SHOWN IN THIS CATALOGUE ARE SUBJECT TO CHANGE WITHOUT OBLIGATION TO GIVE PRIOR NOTICE BY CAME S.P.A, E&OE CAME S.p.A.
