Summary of Contents for Euronics EW01
- Page 1 User Manual & Instruction EW01 Sensor Toilet Flusher...
- Page 2 INSTALLATION INSTRUCTIONS BEFORE INSTALLATION 1) Please read the instructions carefully 2) The sketch map is only for reference. Product appearance and accessories may differ from illustrations in manual. 3) Although the installation is simple, it should be done by a licensed plumber. 4) The following are needed for proper installations:wrench,screwdriver, sealing tape,pliers, etc.
- Page 3 PRODUCT SPECIFICATIONS Product Name Automatic Toliet Flush Power Supply AC220V Operation Consumption <60uA Dynamic Power Consumption <180mA Sensing Distance 55-90cm (adjustable) Water Pressure 0.1-0.7 Mpa Water Inlet Specification DN25 (G1") Water Flow 6-9L/flush time (0.3Mpa) Installation Way Concealled into the wall Embedded Box Size 110*160mm Faceplate size...
- Page 4 Inlet Block Outlet Center Line Power Connector AC 220V Input Wire for Solenoid Valve Power Connector All measurements are in mm.
- Page 5 MAINTAINENCE INSTRUCTION 1) Water-flow regulating Please use screwdriver to regulate water flow. Clockwise direction is to turn down water flow while counter-clockwise direction is to turn up water flow. 2) Filter net cleaning Please use screwdriver to back-out the filter net. Clean the filter net with clear water and then fix it back.
- Page 6 SERVICEPARTSPAGE Solenoid valve components exploded view Valve coil head Solenoid Valve Assy Valve cover Valve core Valve piston Rubber diaphragm AC Power unit Valve main body Sensor Assy Fixed plate Cover INSTALLATION SCHEME Wall Embedded Floor...
- Page 7 Wall Inlet/Out Seat Surface Pipe G1 Embedded Floor All measurements are in mm.
- Page 8 TROUBLE SHOOTING Problem Possible Reason Suggested Solution Indicator light Sensing distance is too short Adjust sensing distance Please make sure there’s doesn’t light up No power supply powr supply & no flush Please check power supply and Power adapter burn-up replace power adapter Replace sensor Sensor broken...
