Blue Mesh Product Line User Guide - Sensors

BLUE MESH SENSOR

USER GUIDE

Specifications subject to change without notice. Non-contractual document.

1/28

www.elainnovation.com

BLUE MESH SENSORS User Guide 04A EN

Table of Contents

Need help?

Do you have a question about the BLUE MESH Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ELA BLUE MESH Series

Page 1 Blue Mesh Product Line User Guide - Sensors BLUE MESH SENSOR USER GUIDE Specifications subject to change without notice. Non-contractual document. 1/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 2: Table Of Contents
IEWING TOOLS ..........................20 ARDWARE SPECIFICATIONS ............................. 21 ALES REFERENCES ........................22 TANDARDS AND CERTIFICATIONS ................................. 23 NNEX Specifications subject to change without notice. Non-contractual document. 2/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 3: General Information On Mesh Networks
Information about Wirepas Mesh technology is available here: www.wirepas.com Specifications subject to change without notice. Non-contractual document. 3/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 4: Products : Blue Sensor Mesh Beacons
MOV MESH PUCK PIR MESH Blue Blue Blue PUCK AI MESH PUCK DI MESH PUCK DO MESH Specifications subject to change without notice. Non-contractual document. 4/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 5: Products: Blue Mesh Gateway
Raspberry Pi Gateway and Wirepas Wireless Dongle (2.4 GHz) Raspberry Pi3 B+ or Pi4 Wirepas Mesh 2.4 GHz wireless dongle SolidRun Gateway SolidSense N6 Specifications subject to change without notice. Non-contractual document. 5/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 6: Blue Mesh Sensor Operation
MQTT broker. The received data is then processed by an application to display and/or further process sensor data. Specifications subject to change without notice. Non-contractual document. 6/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 7: Operating Mode
Data is sent by the gateway to a specific MQTT broker the server. The list of topics corresponding to the various sensors in the BLUE MESH product line are provided in the following table. Specifications subject to change without notice. Non-contractual document. 7/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 8 BLUE PUCK MOV MESH Y: FF 58  -168 milliG ANG format Z: 04 8E  1166 milliG Specifications subject to change without notice. Non-contractual document. 8/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 9 NOK: 01 BUZZ ON Time BUZZ_ON 10 OK: 00 * “Time” in seconds *10 seconds NOK: 01 Specifications subject to change without notice. Non-contractual document. 9/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 10 DIGITAL Output OFF DIGI_OFF table See “previous page” DIGITAL Output ON Time DIGI_ON 10 table * “Time” in seconds Specifications subject to change without notice. Non-contractual document. 10/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 11: Configuration Via Nfc
Blue Mesh Product Line User Guide - Sensors 5 CONFIGURATION VIA NFC 1. Connect NFC reader to PC (ELA reference: NFC R/W 01 - ref. ACIOM177) 2. Start the Device Manager application (installed prior to use). The application can be downloaded from the elainnovation.com website, in Support  Downloads 3.
Page 12 Write configuration operation locked. Display configuration data. Activate / deactivate tag. 3. Configuration: example of read parameters Specifications subject to change without notice. Non-contractual document. 12/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 13 Network Channel Wirepas Network Channel (8 bits) 0x02 Tag Class Tag group management (8 bits) [0xF9-0xFF] 0xF9 Specifications subject to change without notice. Non-contractual document. 13/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 14 Used by ID+ location function and by MOV sensor function. Level 4 level used only for PIR Sensor, Sensibility of presence detection. 0 (Less sensitive) Specifications subject to change without notice. Non-contractual document. 14/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 15 Bluetooth period Advertising period in seconds [1 to 10] Bluetooth power Power [ -8, -4, 0, 4] Specifications subject to change without notice. Non-contractual document. 15/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 16: Configuration Over The Network: Application Configuration Data
* If “Length” is greater than 1, the value must be written with the least significant byte first. Specifications subject to change without notice. Non-contractual document. 16/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 17 [0x01 – 0x04] -8, -4, 0, +4 dBm Deactivate tag 0xF9 0x91 0x08 0x2112FA00 0x01000000 Reactivate only via NFC Specifications subject to change without notice. Non-contractual document. 17/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 18 Commands described here correspond to version v2.0.0. Commands for versions previous are provided in the Annex of this document. Specifications subject to change without notice. Non-contractual document. 18/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 19: Viewing Tools
“instance”. Example: wss://yourcompanywpewnt.extwirepas.com:8813 Enter your provided login name and password and then click on Log in. Specifications subject to change without notice. Non-contractual document. 19/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 20: Hardware Specifications
WP-UG-421 - Wirepas Network Tool - Client User Guide 8 HARDWARE SPECIFICATIONS PUCK COIN LITE SLIM Specifications subject to change without notice. Non-contractual document. 20/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 21: Sales References
T PROBE MESH IDF25450 Temperature sensor with external probe Blue PUCK PIR MESH IDF25649 Detection presence sensor Specifications subject to change without notice. Non-contractual document. 21/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 22: Standards And Certifications
10 STANDARDS AND CERTIFICATIONS CE logo • FCC mark • • IC Mark RoHS certified • Wirepas Mesh • Specifications subject to change without notice. Non-contractual document. 22/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS User Guide 04A EN...
Page 23: Annex
Location function 0x42: Non-router with Autorole mode Anchor: 01 Mobile tag: 02 * hexadecimal value Sensor function Specifications subject to change without notice. Non-contractual document. 23/28 www.elainnovation.com Copyright © 2021 ELA Innovation – BLUE MESH SENSORS User Guide 04A EN...
Page 24 This parameter must be set to “False” for a sensor network that does not use the Location function. Specifications subject to change without notice. Non-contractual document. 24/28 www.elainnovation.com Copyright © 2021 ELA Innovation – BLUE MESH SENSORS User Guide 04A EN...
Page 25 Threshold Not used BLE beacon tag name BLUETAGID ELAWP BLE tag name: 15 characters BLE beacon name Specifications subject to change without notice. Non-contractual document. 25/28 www.elainnovation.com Copyright © 2021 ELA Innovation – BLUE MESH SENSORS User Guide 04A EN...
Page 26 BLE advertising period in seconds, range 1 to 10 BLE power BLE Beacon tag power: BLE transmission power: [-8, -4, 0, 4] Specifications subject to change without notice. Non-contractual document. 26/28 www.elainnovation.com Copyright © 2021 ELA Innovation – BLUE MESH SENSORS User Guide 04A EN...
Page 27 BLE Beacon advertising period 1000 (milliseconds) BLE advertising period in milliseconds, range 100 to 10000 Transmission interval Specifications subject to change without notice. Non-contractual document. 27/28 www.elainnovation.com Copyright © 2021 ELA Innovation – BLUE MESH SENSORS User Guide 04A EN...
Page 28 0xF9 0xE4 0x08 0x01FA151200000000 300 seconds: 0x012C0100 *Little endian LED & BUZZER 0xF9 0xE5 0x08 0x01FA151200000000 Specifications subject to change without notice. Non-contractual document. 28/28 Copyright © 2021 ELA Innovation – www.elainnovation.com BLUE MESH SENSORS – User Guide 04A EN...
