Piston Tank Control
with (optionally available)
Static Depth Controller
Installation & Operation
Please read the following instructions and safety warnings carefully BEFORE you commence with
the assembly of this unit and installation of the dive system. For further safety instructions please
refer to the instructions supplied with Piston Tanks.
Only operate Piston Tanks when switch unit is completely connected. Otherwise
Piston Tanks will inevitably be damaged, resulting in total failure of the system.
During the charging period all batteries must be removed from the hull. NEVER charge
batteries inside the hull as almost all battery types gas while being charged. Insufficient
air circulation during the charging period may lead to a serious EXPLOSION!
Engel Dive Systems have been primarily designed for use in Engel model submarines.
Therefore, we cannot guarantee satisfactory installation and/or operation in self-made
models or kits of other brands.
We are not liable for any personal injury or damage of any kind incurred during the assembly and/or
use of our products as we are neither able to delegate nor verify the assembly and/or use of these
items. Please adhere to your country's safety guidelines during construction and operation of this
item. This product is not suitable for persons under 16 years of age. Technical specifications are
subject to change without notice.
Copyright ©2008 ALEXANDER ENGEL KG 1584-TMX_v11-08_E All rights reserved.
www.modelsubmarines.com
Item No. 1584-TMX/S
Proportional
Version 2
TAES
V2
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for ALEXANDER ENGEL TMAX V2
- Page 1 Please adhere to your country’s safety guidelines during construction and operation of this item. This product is not suitable for persons under 16 years of age. Technical specifications are subject to change without notice. Copyright ©2008 ALEXANDER ENGEL KG 1584-TMX_v11-08_E All rights reserved. www.modelsubmarines.com...
- Page 2 T max Item No. 1584-TMX The Tmax offers a maximum of features for controlling Piston Tanks. Tmax version 2 (V2) is equipped with a regulated power supply for the processor, by which susceptibility to radio interference is minimized. As the functions of this system are quite extensive, it is absolutely necessary to study the following instructions and diagrams carefully before commencing with the setup of the system.
- Page 3 All motor housings of the model (including main drive motors) should be connected to "ground" (negative pole of main drive battery). This will further decrease probability of radio interference. DO NOT operate the piston tanks if switch unit is not completely connected! Otherwise you risk damage of the Piston Tank mechanism. Copyright ©2008 ALEXANDER ENGEL KG...
-
Page 4: Connecting Pressure Switch
T max Item No. 1584-TMX CONNECTING PRESSURE SWITCH The electric connection between pressure switch and Tmax is made of the two-core lead supplied. Pins 1 and 3 of the pressure switch are connected to the corresponding ports on the switch unit as illustrated. The allocation of pins on Tmax connecting to the pressure switch is not of any relevance. - Page 5 Nevertheless, a slight positive buoyancy of approx. 5-7 grams should remain. Copyright ©2008 ALEXANDER ENGEL KG...
- Page 6 T max Item No. 1584-TMX STATIC DEPTH CONTROLLER TAES (optional) The Static Depth Controller supports the trim of the submerged, static (zero velocity) model. This separate unit measures the pressure differentials during submerging and resurfacing which are then equalized by water being sucked in and pressed out of the Piston Tank cylinders.
-
Page 7: Further Connections
The second green LED [LED6] serves as monitor-LED for optical evaluation of remaining main battery voltage. Furthermore, LED6 faci- litates adjustment of threshold voltage via the potentiometer of the battery monitor. The darker LED6, the lower main battery voltage (relative to threshold value). Copyright ©2008 ALEXANDER ENGEL KG... -
Page 8: Maintenance
T max Item No. 1584-TMX FUSE The Tmax is fitted with a 10 A fuse (slow-blow) for protection of its operational circuit due to overload - but NOT against reverse polari- ty! An overload may be caused by a blocked motor (i. e. by incorrect polarity) or a blocked cog wheel. The latter is unlikely but after years in service not impossible (see "Maintenance"... - Page 9 Installation of charging sockets in either the hull or pressure proof compartment will result in the GUARANTEE being NULL and VOID! If you have any questions please do not hesitate to contact us by phone at int.+49-7043-93520 [Mon.-Fr. 9am - 5pm CET*] email: info@engel-modellbau.de Happy Sailings! ALEXANDER ENGEL KG *CET-Central European Time Copyright ©2008 ALEXANDER ENGEL KG...
- Page 10 T max Item No. 1584-TMX Problems, possible causes and solutions Problem Description Cause Solution When switching to FILL Piston might block if moved to far over Wrong polarity of motor. Change direction of motor piston rod spins INWARDS, its ultimate end position. rotation by exchanging the switching to EMPTY piston wires soldered directly to the...
