- Page 1 HCLH/SOP-YF-072-115 MT1100 Data Transceiver and & Power Monitoring Series Operation and Installation Manual...
- Page 2 A1-MT1100 [Manufacturer]: Wuhan Huchuang Union Technology Co., Ltd. [Production Address]: No.1 Workshop, 1F, Building B10, Wuhan Hi-Tech Medical Device Park, No. 818 Gaoxin Avenue, East Lake Hi-Tech Development Zone, Wuhan, Hubei, China [After-Sales Service Unit]: Wuhan Huchuang Union Technology Co., Ltd.
-
Page 3: Table Of Contents
A1-MT1100 Contents 1 Overview .................................3 1.1 Operation Instructions of Manual .........................3 1.2 Overview ..............................3 1.3 Environmental Requirements ........................3 1.4 Environmental Protection Instructions ......................4 2 Structure Features and Equipment Parameters ......................5 2.1 Structure Features ............................5 2.2 Equipment Parameters ..........................8 3 Basic Operation Instructions ............................9 3.1 Installation Method ............................9... -
Page 4: Overview
As a data transmitter and transmitter host monitored by the laboratory, MT1100 can receive local wireless data and transmit the data to the cloud server via 4G. In addition, MT1100 also has WIFI function, and can transmit the received wireless data to the local server through WIFI after being connected to the specified WIFI, and is suitable for local networking. -
Page 5: Environmental Protection Instructions
1.3.4 Power adapter (input: AC100V ~ 240V, 50/60Hz; output: 5V, 2.1A, 10.5W); 1.4 Environmental Protection Instructions 1.4.1 MT1100 device contains reusable materials, and its components can be recycled after being cleaned and sterilized. 1.4.2 During recycling and handling MT1100 device, it is recommended that the company's technical personnel dismantle it and recycle it according to different waste groups;... -
Page 6: Structure Features And Equipment Parameters
A1-MT1100 Structure Features and Equipment Parameters 2.1 Structure Features Data Display Screen: Displays the current states and the current received data of the device. b) Keys: Push-type buttons; set or modify the equipment parameters through button operations. - Page 7 A1-MT1100...
- Page 8 A1-MT1100 Upgrade Debugging Port: Micro USB interface; it has 2 functions: Firstly, it can be used for program upgrade: The special USB cable customized by the company is used for upgrading program; secondly, it is used to modify parameters: The special USB cable customized by the company shall be used for modifying parameters;...
-
Page 9: Equipment Parameters
A1-MT1100 433MHz antenna interface: Connected with 433 MHz external antenna. WIFI antenna interface: Connected with WIFI external antenna. 2.2 Equipment Parameters Table 2 MT1100 Parameters Item Parameter Overall dimensions 205mm*126mm*55.6mm Weight 820g Power supply mode DC5V/2A Battery specification Two 3.7V 18650 batteries in parallel, 5000mAh... -
Page 10: Basic Operation Instructions
3.1.2 Wall-Mounting Select a relatively open smooth wall, paste 4 pieces of MT1100 special magic tapes on the wall, and then paste another 4 pieces of MT1100 special magic tapes on the baseplate of MT1100, and then stick magic tapes together. -
Page 11: Power-On For Use
A1-MT1100 Power-On for Use Step 1: Turn the power toggle switch to "ON" position, at the moment, the equipment will start up automatically (with built-in chargeable lithium battery, the display screen will be on, and the buzzer will give a short beep; Step 2: Connect the device with the external 5V adapter. -
Page 12: System Information
A1-MT1100 indicates that the power supply of the adapter is abnormal, and there is an audible and optical alarm (sound: The buzzer beeps; light: the icon blinks); 4G network signal strength and connection status, strength of full grids (4 grids) signal; "OK" means that the device is normally connected to the cloud server;... -
Page 13: Parameter Setting
A1-MT1100 Display Instructions: "Model" in Row 1 Equipment model; "SN" in Row 2 Unique serial number of equipment; "APN" in Row 3 4G network connected APP of equipment; "MAC" in Row 4 MAC address of Ethernet for equipment; "WIFI" in Row 5 Local server address and port of WIFI connection;... -
Page 14: 1.Set Date Time
A1-MT1100 3.5.2 "1.SET DATE TIME" Note: This option is used for setting the current operating date and time of the equipment; Select "1.SET DATE TIME" on the setting menu, and then press the "OK" button (Key 3) to enter the setting interface. As shown in the following figure: Parameter Description: “YY/MM/DD”... -
Page 15: 3.Set Wifi
A1-MT1100 Parameter Description: "Defa" in Row 1 Default gateway of equipment; "Mask" in Row 2 Subnet mask of equipment; Local IP address of equipment; (if it is connected with MT500, the "IP" in Row 3 MT500 needs to point at the IP address) "Port"... -
Page 16: 4.Set Apn
A1-MT1100 Parameter Description: WIFI function enable/ disable: "ON" indicates that the WIFI function "WIFI" in Row 1 is enabled, and "OFF" indicates that the WIFI function is disabled; "IP" in Row 2 Local server IP address and port of WIFI connection;... -
Page 17: Precautions
Precautions The local wireless transmission distance of MT1100 is limited and should generally not exceed 3 rooms. If the walls of the rooms are made of metal materials, it is better to install one device in each room. -
Page 18: Fcc Statement
A1-MT1100 FCC Statement 15.19 Labeling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 19 A1-MT1100 Specific Absorption Rate (SAR) information: This product meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health.
- Page 20 A1-MT1100 Wuhan Huchuang United Technology Co., Ltd. Address: No.1 Workshop, 1F, Building B10, Wuhan Hi-Tech Medical Device Park, No. 818 Gaoxin Avenue, East Lake Hi-Tech Development Zone, Wuhan, Hubei, China...
