POSIFLEX XT-7315 Quick Start Manual

XT-7315/XT-7515 JUMPER SETTING
‧ JP2 : BEEP SOUNDS SELECT
Pin 1-2 Short：Beep to Speaker
Pin 2-3 Short：Beep to Buzzer
‧ JP3 : COM1/COM2 PORT DC SUPPLY SELECT
Pin 1-3 Short：COM1 Pin1 connected as 12V DC
Pin 3-5 Short：COM1 Pin1 connected as DCD
Pin 2-4 Short：COM2 Pin1 connected as 12V DC
Pin 4-6 Short：COM2 Pin1 connected as DCD
JP4 : For CR open/close status port selection
‧
Pin 1-3、2-4 Short: For COM1
Pin 3-5、4-6 Short : For COM5
‧ JP5 : COM3/COM4 PORT DC SUPPLY SELECT
Pin 1-3 Short：COM3 Pin1 connected as 12V DC
Pin 3-5 Short：COM3 Pin1 connected as DCD
Pin 2-4 Short：COM4 Pin1 connected as 12V DC
Pin 4-6 Short：COM4 Pin1 connected as DCD
‧ JP6 : TOUCH SOUNDS SELECT
Pin 1-2 Short：Normal USB Used
Pin 2-3 Short：for Resistive touch sounds used
SW1 : Clear CMOS Setting
‧
DIP Switch select
OFF
1
ON
2 OFF
ON
COM1~COM3 : +5V through BIOS ; VGA +12V through BIOS
‧
Press ESC to access Advanced/OEM IO Configuration
VGA DSUB 12V : Enabled
COM1 DB9 5V : Disabled
COM2 DB9 5V : Disabled
COM3 DB9 5V : Disabled
Normal Operation
Clear CMOS
Enable security measures defined in the Flash Descriptor
Disable Flash Descriptor Security (override)
