Owners Manual
Optibike Argon
This is the Owners Manual for the Optibike Argon
Electric Bicycle. The Manual provides basic
information required to ride the bike. It is
recommended that you always ride your electric bike
with a helmet and observe all traffic regulations.
The maintenance information in this manual requires
a basic understanding of using common tools. If you
do not have the experience required to perform these
operations, you should take your bike to a Certified
Bicycle Ship for Maintenance and repairs.
Failure to perform the repairs and maintenance
correctly can result in death or injury.
NOTE: We strongly urge you to read this Manual in
its entirety before your first ride.
Contact Optibike
optibike.com/contact
Phone 303.443.0932
Optibike Argon Owners Manual
V1.1
1
Advertisement
Table of Contents
Related Manuals for Optibike Argon
Summary of Contents for Optibike Argon
- Page 1 Owners Manual V1.1 Optibike Argon This is the Owners Manual for the Optibike Argon Electric Bicycle. The Manual provides basic information required to ride the bike. It is recommended that you always ride your electric bike with a helmet and observe all traffic regulations.
-
Page 2: Night Riding
You must use active lights when riding at night. This means a headlight and taillight. It is also recommended that you ride with a reflective coat or vest. Optibike Argon Owners Manual... - Page 3 E-Bike laws vary by state. The most popular and latest laws are the three Class classifications. By default the Optibike Argon is a Class 2 E-Bike with a max speed of 20MPH, and both Pedelec and Throttle control. The Argon can easily be changed to a Class 1 E-Bike with only Pedelec control, by disconnecting and removing the throttle from the bike.
-
Page 4: Riding Gear
It is highly recommended that you carry the following tools and spares: Spare inner tube Tire changing levers Basic tool kit Tire pump A water bottle for hydration is also a good idea. Use Sun Screen if riding in sunny areas. Optibike Argon Owners Manual... - Page 5 Over Center Clamp Caution! Do not extend seat post beyond maximum extension mark. If the seat post is still not high enough at maximum extension, a longer seat post is required. Optibike Argon Owners Manual...
-
Page 6: How To Read The Display
How to Read the Display The Argon LCD display mounted to the handlebar provides information to the rider. This is where you turn the bike on and off, check battery level and change power levels. Power Assist Level Speedometer Trip Odometer... - Page 7 To engage the motor, simply begin pedaling. To increase the power, pedal harder. The Argon has a speed limit of 20 MPH. The motor will no longer assist after 20 MPH. How to Change the Power Assist Level The Argon has 5 Power Assist Levels.
- Page 8 How to Turn the Headlight on and off The Argon comes with a headlight that is powered by the main battery, and is controlled from the display. To toggle the headlight, press and hold the UP arrow on the display.
- Page 9 CLEAN appears at top of screen. Step 3: Press the MENU button again and “CLEAN DATA” screen will appear with YES and NO. Step 4: Press MENU button to confirm YES. This will reset trip data to zero. Optibike Argon Owners Manual...
-
Page 10: Front Brake
How to Use the Brakes • Like regular bicycles the Argon has front and rear brakes. • The brakes are hydraulic disk brakes and offer great stopping ability. • The rear brake is on the right side and should always be used first. -
Page 11: How To Charge The Battery
The charger should be disconnected from the bike within 24 hours of finishing charging. Charging the battery when it is under 35F will damage the battery and void the warranty. Only use the Optibike supplied charger. Optibike Argon Owners Manual... - Page 12 Red indicates charging. • When the charging is complete, the LED will turn to Green. Argon Charge Times 37 volt 14 AH Battery Charger Type Charger 70% Charge 100% Charge Output Time Time...
-
Page 13: Battery Storage
It is OK to store your bike in an area that is cold. Colder storage temperature will prolong the life of the battery. Do not store below -4F or -20C Optibike Argon Owners Manual... -
Page 14: Front Wheel Removal
Front Wheel Removal The Argon front fork uses a Quick Release Front Axle with over center clamp. Step 1: Place the bike on a stand so the front wheel does not have weight on it. Alternatively, turn the bike upside down. -
Page 15: Front Wheel Installation
(See Picture) Over Center Clamp must be tight. If brake pads do not have a gap, use a clean screw driver to gently move them apart. Optibike Argon Owners Manual... -
Page 16: Rear Wheel Removal
This can take some effort. Step 4: Use a 19mm wrench and loosen the left and right axle nuts a few turns. The wheel may drop out at this point, so be ready and hold onto it. Optibike Argon Owners Manual... - Page 17 Rear Wheel Removal Step 5: Drop wheel Step 6: Slide the Belt off the rear sprocket Optibike Argon Owners Manual...
-
Page 18: Rear Wheel Installation
Step 4: Place bike on the ground and push down on frame to be sure axle is fully inserted in drop outs. Fully tighten the two axle bolts with 19mm wrench. Optibike Argon Owners Manual... - Page 19 Rear Wheel Installation Step 5: Install the axle nut rubber covers. Step 5: Connect the motor wire together. Be sure to align the arrows on connectors before pushing together. Step 6: Install tie wrap on motor wire. Optibike Argon Owners Manual...
-
Page 20: Adjusting Belt Tension
Adjusting Belt Tension The toothed belt on the Argon is mostly maintenance free. It does not require lubrication. From time to time it may need to have the tension adjusted. Step 1: If belt needs to be adjusted, loosen the two pinch bolts on either side of frame with a 4mm Allen wrench. -
Page 21: Maintenance Intervals
Monthl 1000 2000 3000 10,000 Ride miles miles miles miles Tire Pressure Tire Condition Battery Charge Check Brake Function Check Belt Tension Check nuts and bolts Inspect Brake Pads (change as needed) Tension Spokes (as needed) Optibike Argon Owners Manual... -
Page 22: Warranty Information
Optibike Warranty Items listed with Optibike Warranty are covered directly by Optibike. Other items are covered under the warranty of the company the makes the part. Warranty applies to original owner only. Warranty is valid for pleasure use only and does not cover racing or commercial use. - Page 23 Lithium batteries sold by Optibike can NEVER be taken on board a passenger aircraft. Frame warranty The Optibike frame is covered for the term listed in the table for the original owner from defects. Subject to terms and conditions. In the event a frame is found defective, domestic shipping, parts and labor to replace said frame is paid by Optibike for the first 12 months from the original date of manufacture.
- Page 24 In the event of a warranty claim requiring the electronics to be returned to Optibike, the customer is responsible for removal and shipment to Optibike. Optibike pays for parts, in house labor and domestic return shipping by FEDEX Ground. For international customers and customers living in Alaska or Hawaii, shipping is not included in the electronics warranty.
- Page 25 Contact Optibike Contact Optibike optibike.com/contact Phone 303.443.0932 Optibike Argon Owners Manual...
