Summary of Contents for innovAg DairyTest Lite
- Page 1 DairyTest Lite Dairy Vacuum & Pulsation Tester USER MANUAL Part No. DR51-0060-13 For software v2.4.1 © 2021 innovAg...
- Page 2 © 2021 innovAg...
-
Page 3: Table Of Contents
Contents What is DairyTest Lite? Safety Precautions Maintenance Calibration & Vacuum System Check The Basics The Button First start up Setting up Parlour Presets Pulsation alarm limits System Information Force Zero Starting a session Vacuum measurement Displaying vacuum measurement Vacuum Recorder... - Page 4 • EU Directive 2014/30/EU • 47 CFR Part 15B • FCC 15.109 • ANSI c63.4:2014 • China RoHS (See following page) Manufacturer’s Name: innovAg Pty. Ltd. Manufacturer’s Address: 37/328 Reserve Road, Cheltenham Victoria 3192, Australia Type of Equipment: P ulsation Tester/ Vacuum Gauge Brand Name:...
- Page 5 Enclosure Silicone tubing Metal fittings Front panel label Rating labels I, the undersigned, hereby declare that the equipment specified above conforms to the above Directives and Standards. Braham Basser Date: 18 March 2018 Director InnovAg Pty. Ltd © 2021 innovAg...
-
Page 6: What Is Dairytest Lite
2. Safety Precautions DairyTest Lite is intended to be used in the milking stall – always allow for the unpredictable nature of animals. During the measurements, sharp needles may be used – take care they do not hurt people or animals. -
Page 7: Calibration & Vacuum System Check
4. Calibration & Vacuum System Check DairyTest Lite automatically performs a zero calibration when turned on. Do not turn on your DairyTest Lite with vacuum connected. If the unit reads other than zero on start-up, make sure vacuum is disconnected and turn off and on again. -
Page 8: The Basics
5. The Basics The Button There is only one button on the DairyTest Lite and it has three functions. 1. Press to turn the unit on. 2. From the sessions screen press and hold to turn off. 3. Press to exit the current screen. -
Page 9: First Start Up
First start up When you first turn on the DairyTest Lite the ‘needs calibration’ icon may be shown indicating the date/time have not been set. Continue to the Setup section to set the clock. Setup © 2021 innovAg... -
Page 10: Setting Up
Backlight brightness Time to half brightness Time to sleep Time to auto power off Set date/format Parlour Presets * System information * Vacuum units (kPa or inHg) Pulsation units (% or ms) Language * refer to following section © 2021 innovAg... -
Page 11: Parlour Presets
There are 9 parlour/alarm presets. Each can be customised with pictures and pulsation alarm limits. To edit select one and press setup. Delete preset Edit preset Select appropriate icons related to the preset’s use. Memory number being edited Save and move to pulsation/ alarm limits screen © 2021 innovAg... -
Page 12: Pulsation Alarm Limits
Pulsation alarm limits Press each setting to edit. During measurement the value will be highlighted if it is outside these limits. minimum maximum on/off Alarm enabled Alarm disabled Save changes © 2021 innovAg... -
Page 13: System Information
System Information Software and hardware version information. Calibration date, setting values. Internal serial number. System log – debug use only. Enter Feature Code screen. Enter Factory Settings screen. Perform Leak Test Perform Response Test. Force Zero © 2021 innovAg... -
Page 14: Force Zero
Force Zero Will force the current reading on both ports to be the zero reference. Remove vacuum from both ports and press 2016/11/11 1:08pm 4 min 1 min _ _> 0 ?? © 2021 innovAg... -
Page 15: Starting A Session
A ‘session’ is a group of measurements taken on a farm on the same day. DairyTest Lite has 5 sessions automatically labelled with the session start date, parlour icon and number of stalls. DTL does not store the farm/farmer name with the session on the unit. - Page 16 Number of pulsators/stalls (maximum 200) Pulsation auto-advance after memory save setting - Return to number screen - Move to next minor increment - Move to next major increment Vacuum measurement Vacuum recorder Pulsation measurement Regulation Characteristics © 2021 innovAg...
-
Page 17: Vacuum Measurement
Vm - Milking units operating Vr - No milking units Vr - Milking units operating Vacuum at gauge Vacuum pump inlet Vacuum pump exhaust Filtered air line Vm with air inlet Vr with air inlet Vp with air inlet Spare © 2021 innovAg... -
Page 18: Displaying Vacuum Measurement
Displaying vacuum measurement Select a vacuum measurement point. DairyTest Lite can display the current reading in three formats: Data only, Graph and Date, or Graph only. Select the format using the button menu or tap on the data or graph screen areas. The display layout is saved and used for the next measurement. -
Page 19: Vacuum Recorder
Spare Flushing To protect the sensors from fluid ingress when dynamic testing Vacuum Recorder automatically flushes the tubing by opening the internal valves for 0.2s each 12s. Flushing is seen on the graph as short 0kPa drops: © 2021 innovAg... -
Page 20: Displaying Vacuum Recordings
Displaying vacuum recordings Select a vacuum recorder point. DairyTest Lite can display a vacuum recording in two formats: Graph, or Graph and Data. Select the format using the magnifying glass button. The display layout is saved and used for the next measurement. -
Page 21: Pulsation Measurement
There are 2 memories per pulsator/stall, 8 and 8*. Select stall. The state of each memory is shown by Memory saved. No alarms. Memory saved. Alarms. DairyTest Lite will display the current reading as data and graph. Readings outside alarm limits will be highlighted. © 2021 innovAg... - Page 22 DairyTest Lite calculates pulsation data to ISO standards. The ‘unstable’ icon is shown if values have not yet settled when changing between pulsators. The display layout is saved and used for the next measurement. The pulsation memory number (stall) can be selected in the table view.
- Page 23 In data mode selecting a specific measurement will display it in large digits. Pressing again will return to the data mode screen. In graph mode, DairyTest Lite will automatically set the time to 1.6 sec or 3.2 sec as required to show an entire pulsation cycle.
-
Page 24: Regulation Characteristics
Regulation Characteristics There are 4 preset regulation characteristics measurements and two memories per measurement. Fall-off: Single cluster Fall-off: Two clusters Attachment: Single teat cup Attachment: Two teat cups © 2021 innovAg... - Page 25 1. With vacuum connected tap ‘start recording’. 2. Wait between 5s and 15s then open the cluster or cups. 3. Wait between 5s and 15s then close the cluster or cups. 4. Wait between 5s and 15s then press ‘stop recording’. © 2021 innovAg...
-
Page 26: Displaying Regulation Characteristics
Undershoot Overshoot Vacuum drop If any Undershoot, Vacuum drop or Overshoot value is larger than 2kPa the minimum and maximum vacuum points will be marked on the graph with dark blue (minimum) and light blue (maximum) triangles. © 2021 innovAg... -
Page 27: Generating A Report
6. Generating a report DairyTest Lite behaves like a USB drive when connected to a PC. Open the DairyTest Lite drive and select index.html. The file is best viewed using the Chrome browser. The opening screen shows the five sessions available. -
Page 28: Generating A Logimat File (French Version Only)
Some screen items such as pop-ups may not be saved. When DairyTest Lite is plugged into a PC the file will be visible in the format ‘dtl-xxxxx.bmp’. 9. Leak Test The Leak Test checks if there is a leak in the internal tubing. -
Page 29: Response Test
The Response Test checks each port is responding quickly to changes. Test one port at a time by producing >45kPa. Quickly pull the tubing off the port and the vacuum response will be automatically calculated. Each port should have >5000kPa/s response time. © 2021 innovAg... -
Page 30: Factory Settings
11. Factory Settings The Factory Settings screen contains various functions for testing and resetting DairyTest Lite. The battery voltage and remaining capacity are displayed in the top left corner. Reformat the SD card and delete data. Settings are retained Flush Port 1 (open valve) Flush Port 2 (open valve) See Calibration &... -
Page 31: Feature Codes
12. Feature Codes This screen is used to add/delete codes that enable special features. Codes are individual for each DairyTest Lite. At the bottom of the report index screen click the “Contact InnovAg” link. This will open an email with the unique electronic serial number of the DairyTest Lite in the title. -
Page 32: Replacing The Batteries
14. Replacing the batteries When DairyTest Lite’s batteries need replacing the battery symbol will flash. We recommend the batteries be replaced as soon as possible once the low battery indicator flashes to prevent unreliable readings or operation. Batteries should not be left in the unit for extended periods in case of leakage. -
Page 33: External Filters
• DairyTest Lite reads vacuum with no vacuum connected – perform a Force Zero. A damaged DairyTest Lite should be returned for repair. There are no user serviceable parts inside the case, and opening it may void your warranty. If you have a question or problem you cannot solve, contact innovAg or your local distributor. -
Page 34: Specifications
• Ratio accuracy: ± 0.5% of calculated value. • Time (ms) accuracy: ± 0.3%. Vacuum: • Range: +10 to -80 kPa (at 1 atmosphere barometric pressure). • Accuracy: ± 0.5 kPa • Repeatability: ± 0.3 kPa • Resolution: 0.1 kPa © 2021 innovAg... - Page 35 – % and ms. • Pulsation measurements conform to ISO standards with stability indication. • Auto power off and low battery indication • Automatic vacuum zero (with manual zero if required). * Specifications are subject to change without notice. © 2021 innovAg...
-
Page 36: Warranty
The term of this Warranty is two (2) years from the date of purchase. WHAT IS NOT COVERED This Warranty does not cover any failures of equipment not supplied by innovAg, nor does it cover any failures of or damage to the product due to: (i) improper handling, misuse, neglect, accident, improper installation, non-compliance with the directions for use. - Page 37 Purchaser, where permitted, is limited to the undertakings as stated in the clause headed ‘WHAT WE WILL DO’. Subject to the above, in no event shall innovAg be liable (whether before or after discharge of the contract for supply of the product or otherwise)
- Page 38 37/328 Reserve Road Cheltenham Victoria 3192, Australia FreeCall (within Australia) 1800 061 167 +61 3 9583 2832 sales@innovag.com www.innovag.com A.C.N. 073 191 376 © 2018 innovAg © 2021 innovAg...
