Aristo VCL4500 Series Manual

Aristo Archive Information
Aristo VCL4500 Series
Dual Lamp Cold Light Head
General Information
◊ Complete variable contrast control
from grade 0 to grade 5 with 50 settings
over entire range without using filters
◊ Low power consumption
◊ Fast consistent exposures
◊ Maybe used with most any timer
Light Head
( )
2 lamps High Intensity
◊ Size: 7 11/16" L x 7 11/16" W x 4 5/16" H
◊ Weight: 3.3 lbs.
◊ Secondary Cable: 6'
◊ Heater: adjustable thermostat controller
◊ Power supply: 120 VAC, 60 Hz, 195 Watts
◊ Fuse: AGC 3 amp
◊ Size: 8" L x 8" W x 3.75" H
◊ Weight: 10.2 lbs.
◊ Primary cord: 6' long, 3-prong grounded
◊ Relay: Built-in with 6' 2-line cord for timer connection
VCL4500-C-Dual-Dim-110V Model Shown
2 pc set with separate power pack.
Blue lamp is dimmable on standard models.
Blue and green lamps are dimmable on Dual models
1. LED intensity control
2. Red LED Display 0.0 up to 5.o in tenths.
3. Variable contrast control from grade
0 through grade 5 with 50 settings. Maybe
used to adjust speed on graded paper
4. Color selection 3 way rocker switch
5. Main power on/off lighted rocker switch
with red lens
6. Normal/split printing mode switch
7. Zero adjustment for different variable
contrast papers
