OUTDOOR DECORATIVE GAS FIREPLACE
P/N 506009-24 REV. A 01/2016
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certified kit is used.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
INSTALLATEUR: Laissez cette notice avec l'appareil.
CONSOMMATEUR: Conservez cette notice pour consula-
tion ultérieure.
WARNING: DO NOT store or use gasoline or other
flammable vapors or liquids in the vacinity of this or
any other appliance.
DANGER
WARNING: For
Outdoor Use Only.
DANGER
IF YOU SMELL GAS:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appli-
ance and immediately call your gas supplier
or your fire department.
C
US
CARBON
MONOXIDE
HAZARD
•
This appliance can pro-
duce carbon monoxide
which has no odor.
•
Using it in an enclosed
space can kill you.
•
Never use this appli-
ance in an enclosed
space such as a camp-
er, tent, car or home.
PFS Report No. 14-020
INSTALLATION INSTRUCTIONS
OUTDOOR DECORATIVE GAS FIREPLACE
MODELS
VRE4336ZEN
VRE4336ZEP
A French manual is available upon request. Order Form Number
506009-25.
Ce manuel d'installation est disponible en francais, simplement en
faire la demande. Numéro de la pièce 506009-25.
WARNING: Improper installation, adjustment, alteration, service
or maintenance can cause injury or property damage. Read the in-
stallation, operating and maintenance instructions thoroughly before
installing or servicing this equipment.
DANGER
Avertissement:
Pour utilisation à
l'exérieur seule-
ment.
DANGER
SI VOUS UNE ODEUR DE GAZ:
1. Coupez l'admission de gaz de l'appariel.
2. Éteindre toute flamme nue.
3. Si l'odeur persiste, éloignez-vous de
l'appareil et appelez immédiatement votre
fournisseur de gaz ou le service d'incendie.
P506009-24
VRE4342ZEN
VRE4342ZEP
MONOXYDE
DE CARBONE
•
Cet appareil peut
produire du monoxyde
de carbone, un gaz
inodore.
•
Son utilisation dans un
espace clos peut vous
tuer.
•
Ne jamais utiliser cet
appareil dans un es-
pace clos, tel qu'une
caravane, tente, voiture
ou à la maison.
