Summary of Contents for BENIFERRO BENISOL
- Page 1 Automated Three Way Valve BENISOL...
-
Page 2: Table Of Contents
3. Setting the delta-temperature and maximum water temperature ........6 4. Connecting the automatic valve with the Harmosol ............7 5. Connecting the Benisol to a filter pump................8 6. Connection scheme of the Benisol ..................8 What to do in case of power outage ..................9... -
Page 3: Introduction
This manual explains the working of the Benisol with the automated three way valve. The components are made in Belgium by Beniferro BV and are of the highest quality. The control- unit measures pool and EPDM temperature with 2 sensors and activates accordingly the three- way-valve. -
Page 4: Assembly
(see 4. Connecting the automatic valve with the Benisol) Warm water left... -
Page 5: Temperature Sensors Of The Harmosol
T-piece and a 1/2 inch teflon insert in the filter outlet. When first installing the Benisol, the probes will not be attached and should be attached by yourself. Please connect the probes as in figure 3. -
Page 6: Setting The Delta-Temperature And Maximum Water Temperature
3. Setting the delta-temperature and maximum water temperature On delivery, your Benisol is pré-installed. The maximum pool temperature can be installed, this will be pré-set on 32 °C. Also the delta temperature can be set. This is the difference in temperature between the pool and the EPDM panels and is pré-set on 4°C. -
Page 7: Connecting The Automatic Valve With The Harmosol
The little black connecting cap is not used. The big grey cable connected to the Benisol contains 4 small cables : a grey one, black, brown and yellow-green. Please connect them as shown in figure 5. -
Page 8: Connecting The Benisol To A Filter Pump
5. Connecting the Benisol to a filter pump. It is possible to control the flow through the solar heating system via a separate circulation system with pump, rather than via an automated valve. In this case, the black and the grey cables are to be connected to the circulation pump. The remaining brown wire, needs to be isolated as it can be loaded with 240V. -
Page 9: What To Do In Case Of Power Outage
What to do in case of power outage The automatic 3-way valve can also be used to manually, for example during a power outage. This can be done by placing the levers on the side on MANUAL instead of AUTOMATIC. AUTO = automatic operation MAN = manual operation AUTOMATIC.
