Summary of Contents for BOREA Rayplicker Cobra
- Page 1 USER GUIDE Rayplicker Cobra Version 1.0 - 11.2022 Ref. UG.RPC.EN.1.0...
- Page 2 Ref. UG.RPC.EN.1.0 / Date 11.2022 Compatible with Rayplicker Cobra spectrophotometer © Copyright, BOREA SAS. This document is the property of BOREA SAS and may not be used, reproduced or communicated to third parties without its written authorization. The most recent version is always available on the site:...
-
Page 3: Table Of Contents
6.2. Automatic shutdown of the Rayplicker Cobra 6.3. Turning off the device COLOR TAKING WITH RAYPLICKER COBRA 7.1. Make a shade-taking 7.2. Automatic calibration 7.3. Error messages ACHIEVING A GOOD SHADE TAKING 8.1. Good practices for using the Rayplicker Cobra... - Page 4 User guide Rayplicker Cobra CLEANING AND DISINFECTION 9.1. General recommendations 9.2. Disinfection and sterilization procedures TECHNICAL SPECIFICATIONS 10.1 Identification 10.2 AC adapter 10.3 Handpiece 10.4 Battery 10.5 Environmental characteristics 10.6 Regulation and standardization 10.7 APPENDICES 11.1 Glossary 11.3 Patents 11.4...
-
Page 5: About This User Guide
CIE L*a*b* values. Precise and ergonomic, the Rayplicker Cobra solution is also equipped with a software allowing the processing and recording of data as well as the creation of an order form with ease. The «Pics App Solution»... -
Page 6: Choice Of Terms
• Never use a damaged battery pack. • Do not drop the charger or battery pack or subject them to shocks. • Do not charge the device using a charger not approved by BOREA. Protect the device and charger against damage Environmental conditions •... - Page 7 • Please only use the rechargeable battery packs supplied with the device. The use of other power sources is prohibited and may damage the device. • Please only use the mains charger supplied with the device by BOREA (5V, 2.4A). Using generic chargers can shorten the life of your device or cause it to malfunction.
-
Page 8: Symbols Description
The C-UL-US Mark confirms that representative samples of the product have been tested and comply with applicable standards for mechanical, fire, and electric shock hazards for the United States. The Rayplicker Cobra device is a Class I medical device. bears marking accordance... -
Page 9: Rayplicker Solution Description
Rayplicker Cobra RAYPLICKER SOLUTION DESCRIPTION The Rayplicker Cobra is a device intended for the determination of dental color and translucency. It is a multipoint spectral measurement device built around a two-dimensional optical sensor and a spectrometer allowing the acquisition of spectral data at any point of the tooth and the automatic production of a complete and precise cartography of the shade variations of this tooth. -
Page 10: Pack Content
Wireless battery pack EA0207 Docking station SF0210 Dongle RA0201 Main charger 5V 2.4A EA0211 Documentation: • Quick Start Guide • Disinfection and Sterilization Procedures CA0207 • Best practices for using Rayplicker Cobra • Safety instructions Cleaning wipe Calibration tips x6 (Autoclavable) RA0209... -
Page 11: Spare Parts And Accessories
User guide Rayplicker Cobra 3.2. Spare parts and accessories The following spare parts and accessories are available from BOREA SAS or your distributor. ACCESSORIES 6 Calibration tips (Autoclavable) Ref : RA0209 SPARE PARTS Main charger 5V 2.4A Ref : CA0204... -
Page 12: First Start-Up
The condition of the tip attests to the quality of the calibration and guarantees the quality of the data collected by the Rayplicker Cobra. We invite you to check the condition of your tips, for this, please refer to the protocol for use of the Rayplicker Cobra present on the BOREA website. -
Page 13: Turning On The Device
DEVICE INTERFACES User interface navigation The Rayplicker Cobra device is equipped with an OLED touch screen. To navigate between the different interfaces, follow the instructions below A click on the screen enable you to enter the selected menu. -
Page 14: Note On Device Illustrations
Transfer in Acquisition Error during Software Update Update progress validated Acquisition version failed done Selected Locked Download profile screen 5.3. Rayplicker Cobra interfaces tree SHADE INFO WIFI TAKING SERIAL SOFTWARE DEVICE BATTERY PASSWORD NUMBER VERSION CONNECTED NAME PROFILE CHOICE... -
Page 15: Wifi Menu
User guide Rayplicker Cobra 5.4. Wifi menu To use the Rayplicker Cobra, you must have the Rayplicker Vision software installed computer. software free download from www.borea-dental.com. When the software is installed please follow the on-screen digital quick start guide. In step 5, you must enter the Cobra password indicated in the wifi settings. -
Page 16: Information Menu
User guide Rayplicker Cobra 5.5. Information menu Here is displayed the battery level of your device. <20% 100% Here is displayed your device serial number. Here is displayed your device software version. -
Page 17: Locking And Shutting Down The Device
Cobra locks. If this symbol is displayed, press the trigger to access the device functions again. 6.2. Automatic shutdown of the Rayplicker Cobra 2nd step : The system automatically shuts down after one minute and 30 seconds of inactivity. -
Page 18: Color Taking With Rayplicker Cobra
User guide Rayplicker Cobra COLOR TAKING WITH RAYPLICKER COBRA 7.1. Make a shade-taking Open or create the patient file of your choice on the Rayplicker vision software. Make sure your device is connected and synced. Launch shade taking mode by briefly pressing the trigger, or by pressing the «shade taking»... -
Page 19: Automatic Calibration
7.2. Automatic calibration The Rayplicker Cobra device performs a self-calibration at each acquisition. This is done using the sterilizable tip which has a gray pattern. It is necessary to ensure the cleanliness and condition of this calibration tip. It must also be protected from the sun’s rays and any other type of external aggression. -
Page 20: Error Messages
User guide Rayplicker Cobra 7.3. Error messages The device is connected but not synchronized with a user profile on the Rayplicker Vision. Another Rayplicker Vision software within your structure may be synchronized with the device. To sync to Cobra, go to your device’s network settings, then select the profile you want. -
Page 21: Achieving A Good Shade Taking
Good practices for using the Rayplicker Cobra The specific design of the Rayplicker Cobra measuring head is the result of an ergonomic study which gives it accessibility right up to the pre-molars as well as trouble-free handling thanks to its wireless technology. -
Page 22: Cleaning And Disinfection
9.1. General recommendations Rayplicker Cobra device: In order to clean the Rayplicker Cobra, it is recommended to use cleaning and disinfecting wipes for medical devices. Type FD 350 from Durr Dental. Calibration tips: The calibration tips (which clip onto the measuring head) are delivered in packs of 6. These must be decontaminated/disinfected and sterilized before use. -
Page 23: Disinfection And Sterilization Procedures
User guide Rayplicker Cobra 9.2. Disinfection and sterilization procedures Please follow the steps below: STEPS CALIBRATION TIPS RAYPLICKER DEVICE AUTHORIZED WIPES - 1 - DISINFECTION INT / EXT RINSE THOROUGHLY WITH WATER - 2 - RINSING INT / EXT AUTOCLAVE STERILIZATION - 3 - 134˚C... -
Page 24: Technical Specifications
User guide Rayplicker Cobra TECHNICAL SPECIFICATIONS 10.1 Identification Manufacturer BOREA SAS Medical device name Rayplicker Cobra 10.2 AC adapter Manufacturer HN Electronic Components Gmbh & Co. KG Model HNP12-MicroUSBL6 Supply voltage 100-240V AC Power frequency 50/60 Hz Output voltage 5.0V DC Output current 2.4 A... -
Page 25: Environmental Characteristics
500 hPa à 1060 hPa 10.6 Regulation and standardization The Rayplicker Cobra device is a Class I medical device. It bears the CE marking in accordance with European Regulation (EU) 2017/745 relating to medical devices. Date of first CE marking: 2022. -
Page 26: Appendices
Characteristic of a material that allows light rays to pass and undergoes scattering. You can see through translucent material but you cannot distinguish shapes. 11.3 Patents The Rayplicker Cobra is protected by the following patents: France: 1556140; 1556141; 1651452 14837,449 11.4...
