ALED BSW CMY 400

USER MANUAL

KEEP THIS USER MANUAL FOR FUTURE NEEDS

Table of Contents

Need help?

Do you have a question about the ALED BSW CMY 400 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aolait ALED BSW CMY 400

Page 1 ALED BSW CMY 400 USER MANUAL KEEP THIS USER MANUAL FOR FUTURE NEEDS...
Page 2: General Guidelines
Thank you for your patronage! We are confident that our excellent products and service can satisfy you. For your own safety, please read this user manual carefully before installing the device. In order to install, operate, and maintain the lighting safety correctly. We suggest that the installation and operation should be done by the verified technician and follow the instruction strictly.
Page 3: Safety Instructions
Operate the device only after having familiarized with its functions. Do not permit operation by persons not qualified for operating the device. Most damages are the result of unprofessional operation. Please use the original packaging if the device is to be transported. For safety reasons, please be aware that all modifications on the device are forbidden.
Page 4: Cleaning And Maintenance
CAUTION! Never touch the device during operation! The housing may heat up! CAUTION! Never look directly into the light source, As sensitive persons may suffer an epileptic shock. Please be aware that damages caused by manual modifications to be the device are not subject to warranty.
Page 5: Technical Parameters
TECHNICAL PARAMETERS POWER SUPPLY Input voltage: AC110V-240V/50-60HZ Power consumption: 430W LIGHT SOURCE Light source specification: Imported new LED Module engine 350W Light source life: 50000 hours Lumen illuminance: 5 meters 100,000 lm Color temperature: 8000K CRI>85 OPTICS Dimming system: 0-100% linear adjustment Focusing system: linear adjustment from 4 meters to 50 meters Frost: 1 independent frost filter, soft and natural light spot Spot zoom angle: 4-35 degrees...
Page 6: Color Wheel
DRAWING COLOR WHEEL FIXED GOBO WHEEL...
Page 7: Rotating Gobos
ROTATING GOBOS CMY FILTER CHANNEL LIST 26CH 22CH FUNCTION VALUE DESCRIPTION 0-255 0-540 Degree PAN FINE 0-255 0-2 Degree TILT 0-255 0-270 Degree TILT FINE 0-255 0-1 Degree P/T SPEED 0-255 From fast to slow DIMMER 0-255 0-100% Dimmer Close 4-103 Pulse strobe from slow to fast 104-107...
Page 8 110-119 Color 2+Color 3 120-129 Color 3+Color 4 130-139 Color 4+Color 5 140-149 Color 5+Color 6 150-159 Color 6+Color 7 160-169 Color 7+Color 8 170-179 Color 8+Color 9 180-215 Fast to slow positive rainbow 216-220 Stop 221-255 Slow to fast negative rainbow 0-255 0-100% CH10...
Page 9 10-19 Gobo 1 20-29 Gobo 2 30-39 Gobo 3 40-49 Gobo 4 50-59 Gobo 5 60-69 Gobo 6 70-79 Gobo 7 80-89 Gobo 1 shaking slow to fast 90-99 Gobo 2 shaking slow to fast 100-109 Gobo 3 shaking slow to fast 110-119 Gobo 4 shaking slow to fast 120-129...
Page 10: Cable Connection（Dmx
Cable connection（DMX） Use a cableconforming to specifications EIA RS-485: 2-poletwisted, shielded, 120Ohm characteristic impedance, 22-24AWG,low capacity. Do not use microphone cable or other cable withcharacteristics differing from those specified. The end connections must be made using XLR type 3 or 5-pin male/female connectors. A terminating plugmust be inserted intothelastprojector witha resistance of 120Ohm (minimum 1/4W)between terminals 2 and3.
Page 11: Operation
Figure 2 Installation Brief The light panel diagram show as Figure 3, Left area is TFT Displayer, support touch, and right area is KEY, both of touch and KEY can operate light and setting. Display & operation just like ‘Android operation system’, touch the item will set or modify setting. Note: Prevent damage the touch or TFT displayer, Can not use sharp objects chick displayer.
Page 12 function,, the KEYr can been choose to set the parameter. 2.2.2 Parameter value setting When the selected item is value need to been modified, the dialog shown in Figure 4 will popup. Figure 4 Dialog of value setting Modify value： Can quickly modify value via pull the slider to the desired position, or click ...
Page 13: Operation And Parameter Instruction
Figure 6 Parameter menu Operation and parameter instruction Via following operation, enter sub menu(parameter menu) shown in Figure 6 In main menu, chick 1/6 function button into corresponding parameter menu.  In sub menu(page), chick main item on the left side of displayer, can shift to corresponding ...
Page 14 Figure 8 page of work mode DMX Ctrl: Choose to set DMX Mode, ◆ Auto Run: Choose to set Auto Mode, ◆ Sound Ctrl: Choose to set Sound Mode, ◆ Available just in ‘AUTO RUN’ or ‘SOUND Ctrl’ mode. M/S Choose: ◆...
Page 15 180° turning display. OFF--> Touch enable：Disable or enable touch function,. ◆ nable touch function. (Default) ON--> E able touch function. OFF--> Dos Touch adjust：Adjust touch function. Normally, not enter this item. ◆ 2.3.4 TEST--> TestMode Enter the page as shown in Figure 10, Light will into test mode, in this mode, the light does not receive the data for DMX controller.: Figure 10 page of Test PAN:...
Page 16 OFF--> Tilt Normal move.(Default) ON--> Reverse Tilt move. P/T Rectify: Disable or enable position rectify function. ◆ OFF--> Disable P/T rectify ON--> Enable P/T rectify -(Default) Pan Offset: Set PAN original position. Default: 10 ◆ Tilt Offset: Set TILT original position. Default: 10 ◆...
Page 17: Precautions For Use
1. The bulb does not light up (except LED light source) Possible cause: The bulb is not completely cooled, or the bulb has reached the end of its life, the treatment is as follows： Due to abnormal operation, the bulb is not completely cooled down, so let the lamp body ...
Page 18 product, and the leakage protector, overcurrent protector, etc. meet the requirements of the load； Do not use power cords with damaged insulation, and do not overlap power cords with  other wires； The lamp adopts strong air cooling, which is easy to accumulate dust. It must be cleaned ...
Page 19 REMARK The product has perfect performance and intergrity packing. All users should be strictly comply with the warning and operating instructions as stated. Or we aren’t in charge of any result by misusing. Any damage resulting by misuse is not within the Company’s warranty. Any fault or problem caused by neglecting the manual is also not in the charge of dealers.
