- Page 1 DUAL PARAMETER WATER QUALITY MONITOR USER MANUAL Model: WT500PR EMPU22071340...
-
Page 2: Table Of Contents
TABLE OF CONTENT ..IMPORTANT SAFETY INSTRUCTION 1.1 Use and safety tips 1.1.1 Electric safety 1.1.2 Operating safety ..PRODUCT INTRODUCTION ..INSTALL AND WIRING 3.1 Controller install 3.2 Electric install 3.2.1 Electricity connection 3.2.2 Probe install ..PH AND ORP SETTING 4.1 Functional setting 4.1.1 Power up 4.2 Select ORP/ pH operating mode... -
Page 3: Important Safety Instruction
1. IMPORTANT SAFETY INSTRUCTION IMPORTANT: The instruction manual you are holding includes essential information on the safety measures to be implemented for installation and start-up of this appliance. Therefore, the installer as well as the user must read the instructions before beginning installation and start-up. Keep this manual for future reference. -
Page 4: Product Introduction
2. PRODUCT INTRODUCTION Emaux The controller, left side of control panel is ORP and right side is pH. The controller should be installed by wall mount with probe wires in 5m. If probe wires need to be extended, the wire should not be longer than 15m and pool technician should test the measurement accuracy is within specification. -
Page 5: Electric Install
Emaux should be paired to use with the controller. Probes should be used pair with Emaux probe holder. Probe holder can be install in; 1) main pipe (main line), or 2) sampling pipe (bypass line) (recommended method). Fix the probe holder on the pipe, place the probe into the holder sealing cap. -
Page 6: Ph And Orp Setting
3.2.2.1 Probe use and maintenance Probe must be always place in water vertically • Keep your probes electrode moist. Probes for new or long term storage should be placed in protection cap with protective solution (which cover the glass electro). You should not remove the cap before use. -
Page 7: Select Orp/ Ph Operating Mode
4.2 Select ORP/ pH operating mode: Press ORP/ pH to select operating mode: “OFF”, “MANUAL” and “Automatic”. When mode is selected, relative function LED will light. 4.3 Operating mode 4.3.1 Power up During power up: ORP in “OFF”mode, ORP LED OFF. SANITIZER feed relay is“open”. SANTITIZER dosing pump is stop. - Page 8 4.3.2.1.5 Setup High ORP or pH alarm setpoint Press“ALARM HIGH” digit display shows“- - - - -” ， ； Press“ORP”or“pH” digital display shows ALARM HIGH setpoint ， ； Press”∧”,“∨”,adjust the expected ALARM HIGH setpoint ； Press“ALARM HIGH”to save the setting and return. Without any key press for more than 8 seconds, system will return automatically without save the setting 4.3.2.2 Automatic mode control...
-
Page 9: Zero Point Calibration
pH Alarm pH≤Low pH ALARM setpoint or, pH≥High pH ALARM setpoint, pH“ALARM”LED light up， otherwise LED off. Important note: High pH setpoint must be higher than Low pH setpoint, otherwise, Acid dosing pump and Alk dosing pump may run at the same time. 4.3.2.3 Manual mod ORP manual mode ORP manual LED light up... -
Page 10: Ph Probe Calibration
BNC (ORP/ pH) contact 5.2 pH probe calibration Selecting high-quality pH value adjusting reagent to prepare standard solution; Before pH probe calibration, run the procedure pH zero point calibration. Turn the unit off and connect the probe to the controller, then power it up. Put the cleaned pH electrode in the standard liquid and stir it a few times, etc., which shows that the instrument is stable.；... -
Page 11: Reset To Default (Factory Setting)
： Range of parameter ORP Parameter Low ORP setpoint 200～995mV ORP hyseresis(D) 50～500mV Low ORP Alarm setpoint ～995mV High ORP Alarm setpoint Low ORP Alarm setpoint 0mV～High ORP Alarm setpoint pH Parameter High pH setpoint (Low pH setpoint+pH0.5)～pH10.0 Low pH setpoint pH1.0～(High pH setpoint -pH0.5) pH hyseresis(D) pH0.3～pH2.0... - Page 12 9.2 Trouble shooting Problem Corrective Action Check power line connection and make sure the power source Cannot power up connection is correct. Digit display shows nothing or Check fuse or Digit display out of function doesn’t fully display Check probe connections; Incorrect ORP/ pH reading Run zero and probe calibration;...
- Page 13 EMAUX WATER TECHNOLOGY CO., LTD YOUR PREMIER SUPPLIER www.emauxgroup.com...
