IST Proline DELTA J-1900/E Owner's Manual

Buoyancy compensator devices
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
J-1900/E
Buoyancy Compensator Devices
Owner's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DELTA J-1900/E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IST Proline DELTA J-1900/E

Summary of Contents for IST Proline DELTA J-1900/E

  • Page 1 J-1900/E Buoyancy Compensator Devices Owner’s Guide...
  • Page 2 Thank you for choosing IST BCD Definitions of Warning, Cautions and Notes A warning indicates a situation that, if not void, will result in serious injury or death. A caution indicates a situation that, if not void, may result in serious injury or death. A Note indicates a situation that, if not avoid, may result in minor or moderate injury or damage to the BCD.

  • Page 3: Table Of Contents

    CONTENTS General Warning and Cautions------------------------------ Airway Attaching Low Pressure inflator hose---------------------- Threading the tank band and buckle----------------------- Attaching the BCD to tank------------------------------------ Donning the BCD Over pressure Relief Valves---------------------------------- Cummerbund Adjustment----------------------------------- Dumpable Weight pouch------------------------------------- Maintenance Limited Warranty and Disclaimer--------------------------- Service Record...

  • Page 4: General Warning And Cautions

    General Warning and Cautions Read owner’s guide and any labels affixed to the BCD thoroughly before using this product. If you do not completely understand these instructions, do not use this BCD. Do not use this BCD if you have not received proper training and certification in SCUBA diving.
  • Page 5 Repair and disassembly must only be performed by IST dealers. Unauthorized service will void the warranty and may cause this product to malfunction. The Maximum depth covered by certification is 50 meters. Limitation to use of compressed air in compliance with EN12021 Maximum recommended cylinder capacity is 20 liters (See Fig.

  • Page 6: Airway

    Airway Power inflator Inflator’s Working Pressures are 110 psi (7.58bars) Minimum, 160 psi (11.03bars) Maximum, and 140 psi (9.65bars) nominal. Inflator button, Press it to inflator BCD. (See Fig. 1) Manual button and Mouthpiece, press it to deflate BC or oral inflate BCD (See Fig. 2) Note: Oral inflation of your BCD under water is a skill that must be achieved...

  • Page 7: Attaching Low Pressure Inflator Hose

    Warning: Only attach the LP hose to the lower pressure (LP) port of regulator. Attach to the High Pressure (HP) port may cause the hose to burst and result in serious injury. Attaching Low Pressure inflator hose Fig. 4 Fig. 5 Fig.

  • Page 8: Attaching The Bcd To Tank

    Note: Wet the tank band first, the nylon webbing stretches a little while wet. Note: Make sure the metal loop of the tank band is as close to the rear of BCD as possible, this will provide a great range of adjustment. Loop the tank locator strap over the tank valve;...

  • Page 9: Donning The Bcd

    Donning the BCD Loosen each strap to its maximum length by lifting up on the bottom tabs of the buckle. (See Fig.17) Open the sternum strap buckle (See Fig.18) and waist strap buckle if equipped, and open the waistband (See Fig.19). Fig.

  • Page 10: Over Pressure Relief Valves

    Over Pressure Relief Valves Some BCD models have this feature. Fig. 25 Fig. 26 It automatically release air when the air pressure inside the bladder is nearly 2.4 psi (0.165bar) over ambient.(See Fig. 25) You can pull the ball to rapidly dump the air too.(See Fig. 26) The maximum outflow relief valve is the dump valve which assembly at the bottom or top of BC.

  • Page 11: Dumpable Weight Pouch

    Fig. 32 Fig. 33 Fig. 35 Fig. 34 Warning: You must practice the ditching of these Dumpable Weight Pouches prior to each dive.

  • Page 12: Maintenance

    Maintenance Note: Improper maintenance will void the warranty and cause this product to malfunction. During use, do not pull the BCD on the sand and stone.  Do not sit on BCD or set heavy/sharp objects on the BCD.  Do not put the BCD under sunshine unattended.
  • Page 13 IST warrants the original purchaser for a year from the date of purchase. The product will be free from defects in material and workmanship, provided it receives normal use and proper care. Limited Warranty The warranty must be made through the same IST dealer and a sale receipt must accompany the product to be returned.

  • Page 14: Service Record

    Service Record Purchase date: BCD Model: Serial no.: OEM customer: OEM customer phone no.: 1. Service person signature Date Notes: 2. Service person signature Date Notes: 3. Service person signature Date Notes:...
  • Page 15 4. Service person signature Date Notes: 5. Service person signature Date Notes: 6. Service person signature Date Notes: 7. Service person signature Date Notes:...
  • Page 16 IST Sports Corp. RoomA , 6th Floor , No.6 , Lane 345 , Yangkuang St. , Neihu , Taipei , Taiwan 1491 Tel: +886 2 26272516 Fax: +886 2 26599056 E-mail: diving@istsports.com CE marked have been approved to EN 1809:2014 +A1:2016 EC Type examination conducted by: EU declaration of conformity can accessed at...
