Related Manuals for Instant POT DUO PLUS
Summary of Contents for Instant POT DUO PLUS
- Page 1 INSTANT POT PLUS ™ ® 112-0169-01_112-0169-01-0301_IB_DuoPlusV4_6QT_US_GSG_FINAL_05-24-22.indd 1 112-0169-01_112-0169-01-0301_IB_DuoPlusV4_6QT_US_GSG_FINAL_05-24-22.indd 1 5/24/22 2:47 PM 5/24/22 2:47 PM...
- Page 2 This Instant Pot Duo Plus multifunction cooker can help you cook healthy, delicious meals more easily and in less time. We hope you fall in love with Instant Pot cooking, and enjoy it in your kitchen for years to come! Get started with your Instant Pot! 112-0169-01_112-0169-01-0301_IB_DuoPlusV4_6QT_US_GSG_FINAL_05-24-22.indd 2...
-
Page 3: Table Of Contents
CONTENTS What’s in the box Using your Duo Plus Initial setup Using the lid Slow Cook Rice Steam Sauté Yogurt Sous Vide Cake Keep Warm Cleaning Learn more 112-0169-01_112-0169-01-0301_IB_DuoPlusV4_6QT_US_GSG_FINAL_05-24-22.indd 1 112-0169-01_112-0169-01-0301_IB_DuoPlusV4_6QT_US_GSG_FINAL_05-24-22.indd 1 5/24/22 2:47 PM 5/24/22 2:47 PM... -
Page 4: What's In The Box
WHAT’S IN THE BOX Steam release vents Whisper quiet lid cover Lid fins Handle Steam release switch Lid position marker Float valve Steam release valve and Anti-Block shield Sealing ring Sealing ring rack Stainless Steel Inner Cooking Pot Get started 112-0169-01_112-0169-01-0301_IB_DuoPlusV4_6QT_US_GSG_FINAL_05-24-22.indd 2 112-0169-01_112-0169-01-0301_IB_DuoPlusV4_6QT_US_GSG_FINAL_05-24-22.indd 2 5/24/22 2:47 PM... - Page 5 Cooker Base Condensation collector (rear) Cooker handles Condensation rim Stainless steel exterior Control panel Heating element (inside) Power cord (rear, 8-quart model has attached cord) Parts + Accessories Sealing ring (extra) 1 sealing ring comes installed Stainless steel steam rack with handles Illustrations are for reference only and may differ from the actual product.
-
Page 6: Using Your Duo Plus
USING YOUR DUO PLUS Control panel We’ve designed the control panel to be simple to use and easy to read. Smart Program Settings 7. Message Display • Cooking presets • Shows cooking instructions 2. Time 8. Cooking Programs • Cooking time •... - Page 7 Turning the sound On or Off Turn sound on When in Ready mode, press and hold Delay Start and Keep Warm for 5 seconds. The message display shows Sound Off. Turn sound off When in Ready mode, press and hold Delay Start and Keep Warm for 5 seconds.
- Page 8 Set a timer (without cooking) You can set a timer for a minimum of 1 minute or a maximum of 60 minutes. When the unit is on and the message display shows Ready, press Delay Start. When the minutes field flashes, turn the Control Dial to set the minutes (in 1 minute increments).
-
Page 9: Initial Setup
INITIAL SETUP Clean before use Wash the inner cooking pot with hot water and soap. Rinse and use a soft cloth to dry the outside. Or you can wash the inner cooking pot in the dishwasher. Wipe the heating element inside the cooker base with a soft cloth to ensure there are no stray packaging particles. - Page 10 Install the condensation collector • Align the grooves on the condensation collector with the tabs on the back of the cooker base and slide the condensation collector into place. Using the Sealing Ring When the lid is closed, the sealing ring installed on the underside of the lid creates an air-tight seal between the lid and the cooker base.
- Page 11 Install the Sealing Ring Place the sealing ring over the sealing ring rack and press it into place. Press down firmly to ensure there is no puckering. The sealing ring should be snug and should not fall out when the lid is turned over.
- Page 12 The 8QT model has an electrical cord that is always connected to the unit. Test run Setting up your new Instant Pot Duo Plus for a test run is a great way to familiarize yourself with how the unit works before you actually cook a meal.
-
Page 13: Using The Lid
USING THE LID You’ll use the pressure cooking lid for most cooking programs, and especially for pressure cooking. Always use the pressure cooking lid that came with this Instant Pot Plus cooker base. ™ ® How to close and lock the lid For pressure cooking, the lid must be securely locked into place to prevent steam from escaping. - Page 14 END and OK to Open Lid. How to release steam Instant Pot Plus can release steam naturally or quickly. Use the ™ ® one that best fits the type of food you’re cooking.
- Page 15 When pressure is released the steam icon on the display disappears and the message display shows OK to Open Lid, remove the lid. Quick steam release Quickly releases steam after you move the steam release switch to the Vent position. Use for: Foods that tend to overcook, like vegetables and seafood.
- Page 16 Pressure Cook Pressure cooking uses pressurized steam to cook foods quickly and evenly. Each specific Smart Program is designed to pressure cook a specific type of food. You can adjust the settings as your recipe directs. Choose from these Smart Programs: Program Default Cook Min Cook...
- Page 17 How to pressure cook Prep Cut, chop, season or marinate your ingredients according to your recipe. Preheat Add ingredients to the inner cooking pot and place the inner cooking pot into the cooker base. Place the lid on top of the cooker base and lock the lid. Press Pressure Cook on the Control Panel.
- Page 18 Choose the steam release method that works for your recipe. See ‘How to release steam’ above for full details. Using liquid to create steam Pressure cooking requires liquid in the inner cooking pot to produce the steam needed. Depending on the size of your Instant Pot Plus, ™ ®...
-
Page 19: Slow Cook
SLOW COOK Slow cooking lets you make your favorite simmering and stewing recipes — just like grandma used to make. This program does not use pressure to cook food. Choose from these Smart Programs: Program Default Cook Min Cook Max Cook Default Time Time... - Page 20 How to slow cook Prep Cut, chop, season or marinate your ingredients according to your recipe. Cook Add ingredients to the inner cooking pot and place the inner cooking pot into the cooker base. Place the lid on top of the cooker base and lock the lid. Press Slow Cook.
-
Page 21: Rice
RICE The Rice program uses pressurized steam to cook rice quickly and evenly. You can adjust the settings as your recipe directs. Choose from these Smart Programs: Program Default Cook Min Cook Max Cook Default Time Time Time Pressure Level Custom 12 minutes 0 minute... - Page 22 Keep Warm setting is ON by default. Press Keep Warm to turn it off. Press Start. The message display shows Preheating and the unit builds pressure. It can take 10-15 minutes to reach the pressure setting for cooking. Cook When the pressure is ready, the message display shows Do Not Open Lid.
-
Page 23: Steam
STEAM The Steam program cooks food using steam but no pressure; it’s especially useful for vegetables like broccoli, zucchini, carrots, and others. You can adjust the settings as your recipe directs or to your taste. Program Default Cook Min Cook Max Cook Default Time... -
Page 24: Sauté
SAUTÉ Use Sauté in place of a frying or saucepan. Sautéing can deepen the flavors of your food, or can simmer, thicken or reduce sauces. Choose from these Smart Programs: Program Cook Temperature Default Cook Min Cook Max Cook (Fixed) Time Time Time... - Page 25 The default cooking time flashes. To select it, press the Control Dial. Or to change it, turn the Control Dial to change it, then press the dial to select it. The default cooking temperature flashes. To select it, press the Control Dial.
-
Page 26: Yogurt
YOGURT You can use your Instant Pot Plus to easily make delicious, ™ ® fermented dairy and non-dairy yogurt. Choose from these settings in the Yogurt Smart Program: Process Default Default Custom Cook Time Temperature Time Range Pasteurize 3 minutes... - Page 27 End. A longer fermentation period will produce tangier yogurt. Allow yogurt to cool. Place in the fridge for 12–24 hours to develop flavors. How much to make? Instant Pot Size Minimum Milk Volume Maximum Milk Volume ® 4 Cups 4 Quarts 6 Quarts / 5.7 Liters...
-
Page 28: Sous Vide
SOUS VIDE Sous Vide cooks food underwater in an air-tight, food-safe bag, for a long period of time. Food cooks in its own juices and comes out delicious and very tender. This program does not use pressure to cook food. You should use the pressure cooking lid to maintain an accurate temperature. - Page 29 How to sous vide Prep Cut, chop, season or marinate your ingredients according to your recipe. Add the ingredients to the cooking bag or pouch and seal tightly. Preheat Place the empty inner cooking pot into the cooker base and close and lock the lid.
-
Page 30: Cake
CAKE The Cake Smart Program uses pressurized steam to bake cakes quickly and evenly, especially cheesecakes. You can adjust the settings as your recipe directs. Program Default Cook Min Cook Max Cook Default Time Time Time Pressure Level Custom 30 minutes 0 minutes 4 hours High... - Page 31 Keep Warm setting is ON by default. Press Keep Warm to turn it off. Press Start. The display shows Preheating and the Instant Pot Duo Plus is building pressure It can take 10–15 minutes to reach the pressure setting for cooking.
-
Page 32: Keep Warm
KEEP WARM You can choose to allow Keep Warm to turn on automatically after cooking on many Smart Programs, and you can also use Keep Warm separately to reheat food. Keep warm after cooking When cooking is finished, automatic warming begins. The timer shows the time passed, up to 10 hours. -
Page 33: Cleaning
CLEANING Clean your Instant Pot Duo Plus after each use. Always unplug the unit and let all parts cool to room temperature before cleaning. Before use or storing, make sure all surfaces are dry. Part Cleaning instructions Accessories • Wash after each use •... -
Page 34: Learn More
LEARN MORE There’s a whole world of Instant Instant Pot information and help just waiting for you. Here are some of the most helpful resources. Get the User Manual (includes Troubleshooting and more) Instanthome.com Register your product Instanthome.com/register Contact Consumer Care In the Instant Brand Connect app Instanthome.com/customer-care-center... - Page 35 Product specifications Model Volume Wattage Power Weight Dimensions DPPC604 6 Quarts 1000 W 120V/ 12.3 lb in: 13.43 L x 13.35 W x 12.76 H 5.7 Litres 60Hz 5.58 kg cm: 34.1 L x 33.9 W x 32.4 H DPPC804 8 Quarts 1200 W 120V/ 15.90 lb...
- Page 36 Distributed by Instant Brands LLC 3025 Highland Parkway, Suite 700 Downers Grove, IL 60515 U.S. instanthome.com © 2022 Instant Brands LLC 112-0169-01-0301 INSTANT and INSTANT POT are registered trademarks of Instant Brands Holdings Inc. 112-0169-01_112-0169-01-0301_IB_DuoPlusV4_6QT_US_GSG_FINAL_05-24-22.indd 34 112-0169-01_112-0169-01-0301_IB_DuoPlusV4_6QT_US_GSG_FINAL_05-24-22.indd 34 5/24/22 2:47 PM...
Need help?
Do you have a question about the POT DUO PLUS and is the answer not in the manual?
Questions and answers
Steam releases during preheating even when the seal is on. Steam is not being released from the side of of the lid but from the seal button itself.
Steam may be releasing from the seal button on the Instant Pot Duo Plus during preheating because the lid is not fully locked. If the lid is not closed and locked properly, the unit will not start pressurizing, and the display will show "Turn to Lock Lid." Ensure the lid is securely locked to prevent steam from escaping.
