SIHOO M82C Product Installation Manual page 2

User Manual
Assemble Introduction
(The size will be according to regular measurements)
1
Put the caster into the base by pressing
3
Armrest installation: Fix the armrest to
the seat cushion with6pcs (M8*20mm) screws
7
5
Put the mechanism into the gas lift.
Installation Precautions
1. Please read the installation instructions (picture) of all accessories carefully before installation, and master the installa-
tion steps and methods.
2. Check whether the accessories are complete and damaged.
3. To avoid injury during installation, it is recommended that you wear gloves.
4. Choose a spacious and clean site when installing. The paper is laid flat on the ground; so as to prevent the components
from colliding with the ground during installation.
1. Please note that when using it, place it on a flat ground. This product can only be used by one person
and only one person.
2. To avoid using the wrong screws, please fix all the screws before tightening them.
Precautions for use
3. Please don't let the child sit on the chair alone if he is under 5 year-old;
4. Please do not sit on the armrests, as it may cause damage and danger to the chair.
5. Please do not stand on the chair or use it as a ladder or step.
6.When installing, please tighten the screws connecting the backrest and the chassis, otherwise the chair
may have a clicking sound.
7.Do not hit the gas lift with a hammer,which will cause the seat height unable to be fixed
2
Insert the gas lift to the base.
4
Backrest installation: Fix the backrest to the seat
cushion with 3pcs M8*20mm screw+3pcs shim+3pcs
spring washer
6
Insert the headrest into the headrest hole
behind the backrest, then the chair is installed.
Functions
(The size will be according to regular measurements)
Armrest up and
down adjustable
Pull out to control the
up and down of the chair
Pull up to adjust the seat
to slide back and forth
Accessories list
(screws, shims and spring washers all have one extra for spare)
caster:5pcs Chair foot：1pcs
Mechanism: 1pc Backrest:1pc
M8*2mm Spring washer: 3+1pcs M8*2mm shim: 3+1pcs
0 1 2 3 4
Adjustable headrest
（The headrest can be manually adjusted
according to the height.Suitable for
different groups of people）
The armrest pad can
be rotated left and right.
Can slide back and forth
Pull out to adjust back titling
(2 gear position lock back tilting)
Gas lift:1pc
Armrest:1pair
hexagonal wrench: 1pc
Hex wrench:1pc M8*20mm screws: 10pcs
Notice: Before installation,
please classify the screw and
measuring screw length
to facilitate installation
Headrest: 1pcs
5 6 7 8 9 10 cm
