- Page 1 LUMIA BOX User Manual Documentation Connect Ideas. Shape solutions.
-
Page 2: Table Of Contents
Table of contents Product Introduction ........................1 Product Overview ........................1 Product Specification ....................... 1 Application Planning ........................2 Transportation ......................... 2 Storage ............................. 2 Open and Inspection of Delivered Equipment ................. 2 Device Connection ........................3 Precautions before Device Connection ..................3 Instruction for Use ........................ -
Page 3: Product Introduction
Product Introduction Product Overview LUMIA BOX is an ultra low power fanless mini PC. It uses Intel® Celeron™ J1900 quad core processor, support Windows 7/8/10 & Linux OS etc., support 1*MSATA and 1*2.5 inch HDD. All aluminum fanless design, structure is simple, good dustproof, heat dissipation, anti-vibration and EMC function, high reliability and strong environmental applicability. -
Page 4: Application Planning
Application Planning Transportation Well packaged products can by any means of transport, to any place, in the long-distance transportation shall not be installed in the open cabin and carriages, midway transshipment shall not be stored in open-air warehouse, not allowed to be transported with inflammable, explosive, corrosive goods together. -
Page 5: Device Connection
● Verify that the shipment contains the complete equipment and accessories that you ordered separately. If there is any discrepancy or exist shipping damage, please contact customer service. Device Connection Precautions before Device Connection Warning Connected or built-in peripherals shall not be connected to devices of opposite polarity. Warning This device can only be operated on the grounding power network. -
Page 6: Instruction For Use
Instruction for Use Product Picture... -
Page 7: Product Size Drawing
Product Size Drawing... -
Page 8: I/O Ports
I/O Ports Front Plate Port Name A : Power switch B: 4 x USB 2.0 C-D: 2 x COM port RS232/RS485 E: Power supply DC 8 ~ 32V F: LAN Back Plate G: DC 12V H: USB 3.0 I : HDMI Q-R : 2 x COM RS32/RS485 L : VGA... -
Page 9: Lower Cover Of The Pc
Lower Cover of the PC The Lower Cover of the PC Status Indicator LED Name Description Description Not Light Power off POWER PC boot up Light Operating... -
Page 10: Install The Internal Parts
Install the Internal Parts Remove four M2.5*35 screws from the bottom plate (see below), remove the bottom plate，then please install the RAM, WIFI module, MSATA SSD or 2.5” HDD and other accessories. After finish installing the internal parts, then install the bottom plate，then install the four M2.5*35 screws. -
Page 11: Definition Of Pins
Definition of Pins Symbol Description Remark No jump cap by JCMOS1 Delete COMS default HDD_LED+ PWR_LED+ HDD_LED- PWR_LED- PW_ON RST_GND PWON_GND Empty JSATA SATA Power Supply +12V Warning The internal wiring of the PC has been installed, and the wire plug and screw have been fixed with glue. -
Page 12: Daily Maintenance
Daily Maintenance 1. When the PC is in normal use, please ensure that the PC is working in a non-vibration environment to avoid damaging the hard disk and internal accessories. 2. When using the PC, please pay attention that the environmental temperature should between -10℃... -
Page 13: Troubleshooting Methods For Common Hardware Failure
Troubleshooting Methods for Common Hardware Failure Fault Phenomenon Analysis of Causes Repair Method The power Suggest to plug tighten the power The PC doesn’t adapter is work cord or change the socket; boot up after or not Change the power adapter press the power Motherboard switch... - Page 14 Enter the OS with a bootable disc （Usual use WINPE OS）. Check The hard disk the hard disk system is damage or system file is not and reinstall the OS if corrupted necessary. Keep beeping No memory Open PC case to re-plug the RAM after PC turn on detected Warning...
- Page 15 Connect ideas. shape solutions. ESA S.p.A. | www.esa-automation.com |...
