Summary of Contents for Wulian ZigBee WL-DWS-DP
- Page 2 When using, if the practical situation of the product is different from that in the manual, or if you want to get more information, or you have any questions or ideas, please contact us as below: Service telephone: +86-25-5226 9091 Service website: http://www.wulian.cc/english/...
- Page 3 Wireless Drawer Lock User Manual Ⅰ. Product Introduction WL-DWS-DP Wireless Drawer Lock is a dedicated lock for drawer, which is based on ZigBee standard design. Its main body and affiliate part are installed on the drawer and desk respectively. Once the drawer is opened illegally, it can send out alarm signal to your mobile phone.
- Page 4 Wireless Drawer Lock User Manual Ⅲ. Function illustration Main body Base of the main body Main body of the magnetic part Base of the magnetic part...
- Page 5 Wireless Drawer Lock User Manual Ⅳ.Installation Steps 1. Separate the【Base of the main body】and【Base of the magnetic part】 from the corresponding main body part as the picture showing; 2. Open the side battery cover of the 【main body】 , load one CR14250 3V security battery, then close it;...
- Page 6 Wireless Drawer Lock User Manual 3. Fix the【Base of the main body】at a proper position of the drawer; Bottom Edge 【Base of the magnetic part】at a proper position of 4. Same as above, fix the the desk; Bottom Edge (Please ensure bottom edge is on the same level)
- Page 7 Wireless Drawer Lock User Manual 5. Aim the【 Main body】and【 Main body of the magnetic part】to their corresponding groove of the base and fold them; Main body Magnetic part...
- Page 8 Wireless Drawer Lock User Manual 6. Installation complete. Main body of the magnetic part Main body Desk body Drawer...
- Page 9 Wireless Drawer Lock User Manual Ⅴ.Application Method 1. Network Connection Setup (1) The product should match up with WL-GW-A Wireless Gateway; (2) Quick click【Multi-function key】four times(Interval time of each time should be within 1 second) to join ZigBee network; After joining the network, green LED light will be constant on 2 seconds, then goes out...
- Page 10 Wireless Drawer Lock User Manual (3) After succeed in joining ZigBee network, device sends ENROLL request to CIE settings in network; Enroll success, red LED indicator light flickers 3 times quickly (Note: The function is optional) (4) Long pressing【Multi-function button】10 seconds to restore to the factory settings.
- Page 11 Android users can search “wulian” or “smart home” in “Google Play Store”, select “smart home” software and download it; b) iPad, iPhone users can search “wulian” or “smart home” in “APP Store”, select “smart home” software and download it;...
- Page 12 Wireless Drawer Lock User Manual Ⅵ.Notes About installation When using the product for the first time, please read user manual of the product before installation. About cleaning The product should be installed at a dry and clean place to avoid components inside getting wet or other sundries.
- Page 13 Wireless Drawer Lock User Manual Ⅶ. Product Specification Weight Net weight Multiple colors available Color Ⅷ. Products in Package Component Main body of the drawer lock Main body of the magnetic part User manual Expansion screw Ⅸ. Ordering Information WLPN1112191 Art.
