Riverbed Cascade Profiler Fibre Channel SAN Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Cascade
®
Attached Storage Installation
Introduction
A Fibre Channel Host Bus Adapter (FC HBA) installed on a Riverbed Cascade® Profiler appliance enables
access to a Storage Area Network (SAN) device as if it were a local SCSI disk. The software components,
driver and command line tools are pre-installed on the Profiler appliance. However, they have to be
configured after the FC HBA card is installed and the SAN device is attached.
If you are installing FC HBA cards in an Enterprise Profiler appliance, complete the hardware installation
described below for the Analysis Module and any Expansion Modules that are present. Then complete
the software installation procedure, which begins with the "Preparing to configure the software" section
on page 11, on each module, one at a time.
Hardware installation
To install the SAN card in a model xx60 Profiler appliance,
1. Remove the top cover of the chassis. The cover is secured by a screw on the side and two
knurled nobs on the back.
Riverbed Technology, Inc.
199 Fremont Street
San Francisco, CA 94105
Phone 415.247.8800
Profiler Fibre Channel SAN
Fax 415.247.8801
www.riverbed.com/cascade
Tech Note #066
1
© 2012 Riverbed Technology, Inc.
Product: xx60 Profiler
Version: 9.5
Date:
11/02/12

Advertisement

loading
Need help?

Need help?

Do you have a question about the Cascade Profiler Fibre Channel SAN and is the answer not in the manual?

Questions and answers

Related Manuals for Riverbed Cascade Profiler Fibre Channel SAN

Summary of Contents for Riverbed Cascade Profiler Fibre Channel SAN

  • Page 1 Attached Storage Installation Introduction A Fibre Channel Host Bus Adapter (FC HBA) installed on a Riverbed Cascade® Profiler appliance enables access to a Storage Area Network (SAN) device as if it were a local SCSI disk. The software components, driver and command line tools are pre-installed on the Profiler appliance. However, they have to be configured after the FC HBA card is installed and the SAN device is attached.
  • Page 2 2. Remove the riser card assembly from the chassis. The assembly is secured by a knurled knob on the rear of the chassis and a screw on the top. © 2012 Riverbed Technology, Inc.
  • Page 3 6. Reinstall the top cover of the chassis. Secure it with the two knurled knobs on the rear of the chassis and the screw on the side near the front of the chassis. © 2012 Riverbed Technology, Inc.

  • Page 4: Software Installation

    The simplest configuration is for Port 0 of the FC HBA to be connected directly to Port 0 of the SAN device. FC HBA SAN Device … The port status shows the first port being online and the second port being down. © 2012 Riverbed Technology, Inc.
  • Page 5 (e.g., magnetic disk) OS LUN Name : /dev/sda;/dev/sg0; WWULN 60-06-01-60-E3-87-1E-00-D8-D8-A4-36-F5-0E-E1-11 ------------------------------------------------------------ [root@profiler ~]# qaucli -fc -l 1 Using config file: /opt/QLogic_Corporation/QConvergeConsoleCLI/qaucli.cfg Installation directory: /opt/QLogic_Corporation/QConvergeConsoleCLI Working dir: /root No fabric attached devices on HBA (Instance 1)! © 2012 Riverbed Technology, Inc.
  • Page 6 The port status shows both ports being online. [root@profiler ~]# qaucli -fc -g Using config file: /opt/QLogic_Corporation/QConvergeConsoleCLI/qaucli.cfg Installation directory: /opt/QLogic_Corporation/QConvergeConsoleCLI Working dir: /root -------------------------------------------------------------------------------- Host Name : profiler OS Type : Linux i686 OS Version : 2.6.32-131.12.1.el6.rvbd.4.i686 © 2012 Riverbed Technology, Inc.
  • Page 7 Product Vendor : DGC Product ID : RAID 5 Product Revision : 0220 Size : 100.00 GB Type : SBC-2 Direct access block device (e.g., magnetic disk) OS LUN Name : /dev/sdo;/dev/sg15; WWULN 60-06-01-60-E3-87-1E-00-D8-D8-A4-36-F5-0E-E1-11 ------------------------------------------------------------ © 2012 Riverbed Technology, Inc.
  • Page 8 (e.g., magnetic disk) OS LUN Name : /dev/sda;/dev/sg0; WWULN 60-06-01-60-E3-87-1E-00-D8-D8-A4-36-F5-0E-E1-11 ------------------------------------------------------------ Target WWPN 50-06-01-61-3A-20-22-B2 PortID 01-01-00 ------------------------------------------------------------ Product Vendor : DGC Product ID : RAID 5 Please consult with your SAN administrator for configuring the FC switch. © 2012 Riverbed Technology, Inc.
  • Page 9 If the active path loses its connectivity (at the FC HBA or SAN device side), it will automatically failover to another path. (It will not revert to the original path when its connectivity is reestablished.) © 2012 Riverbed Technology, Inc.
  • Page 10 : 100.00 GB Type : SBC-2 Direct access block device (e.g., magnetic disk) OS LUN Name : /dev/sdb;/dev/sg1; WWULN 60-06-01-60-E3-87-1E-00-D8-D8-A4-36-F5-0E-E1-11 ------------------------------------------------------------ [root@profiler ~]# qaucli -fc -l 1 Using config file: /opt/QLogic_Corporation/QConvergeConsoleCLI/qaucli.cfg Installation directory: /opt/QLogic_Corporation/QConvergeConsoleCLI Working dir: /root © 2012 Riverbed Technology, Inc.
  • Page 11 (dual ports connection) of the Profiler FC HBA ports, allocate a Logical Unit Number (LUN) for the Profiler appliance to use on the SAN device. The port status can be checked by running the following command as root on the Profiler appliance. © 2012 Riverbed Technology, Inc.
  • Page 12 The Profiler appliance utilizes only one LUN for storing logs. Any additional LUNs assigned are ignored for the normal operation of the appliance. Although it is possible to utilize additional disk space for other purposes such as backup, that is beyond the scope of this document. Please consult with Riverbed Professional Services for guidance.
  • Page 13 (The others are in standby.) Therefore, having two ports connected to the SAN device does NOT increase the data rate. The failover mode increases the reliability by automatically switching to an alternate path if the active path goes down. © 2012 Riverbed Technology, Inc.
  • Page 14 WARNING: Please restart it if the result is satisfactory. Attaching '/dev/mapper/mpathap1' ... DANGER: --no-copy NOT specified. DANGER: Existing data on a partition (/dev/mapper/mpathap1) will be destroyed! You have 10 seconds to interrupt mazu-storage... proceeding Successfully attached '/dev/mapper/mpathap1'. Logs copied over OK. Complete! © 2012 Riverbed Technology, Inc.

  • Page 15: Verifying The Installation

    (uevent) multipathd: dm-0: devmap already registered multipathd: sdb: remove path (uevent) multipathd: mpatha: load table [0 209715200 multipath 1 queue_if_no_path 1 emc 1 1 round-robin 0 2 1 8:224 1000 8:240 1000] © 2012 Riverbed Technology, Inc.
  • Page 16 (uevent) multipathd: dm-0: devmap already registered multipathd: dm-1: add map (uevent) multipathd: dm-0: add map (uevent) multipathd: dm-0: devmap already registered multipathd: dm-1: add map (uevent) © 2012 Riverbed Technology, Inc.
  • Page 17 (uevent) kernel: sd 9:0:1:0: emc: at SP A Port 1 (owned, default SP A) kernel: sd 8:0:1:0: emc: at SP A Port 1 (owned, default SP A) multipathd: dm-1: add map (uevent) © 2012 Riverbed Technology, Inc.

  • Page 18: For Additional Information

    Phone – United States and Canada: 1 888 782 3822 Phone – outside U.S. and Canada: +1 415 247 7381 Email: support@riverbed.com Web: https://support.riverbed.com When contacting Riverbed Support for any SAN related issue, please collect the following information along with files. (This command must be executed as root.) /var/log/messags* qaucli -fc -z -o qaucli-z.txt...
