- Page 1 HWT 570 MULTIFORCE Wheeled string trimmer OPERATOR’S MANUAL 02589.2022.06...
-
Page 2: Table Of Contents
HWT 570 MULTIFORCE Wheeled string trimmer / Translation of the original instructions TABLE OF CONTENTS Introduction ................3 20. Technical assistance service ..........18 20.1 Assistance ..............18 Description and intended use ..........3 20.2 Identification data ............18 20.3 Spare parts ..............18 Use and safety decals ............ -
Page 3: Introduction
INTRODUCTION Dear Customer, we thank you for the trust and preference you have placed in our Grillo HWT 570 MULTIFORCE and we are confi dent that the use of your new machine will fully meet your requirements. For optimal use and maintenance over time, please carefully read and follow the instructions in this booklet; this will enable you to obtain the best results and safeguard your purchase. -
Page 4: Use And Safety Decals
USE AND SAFETY DECALS Throttle Sound power level Serial number... - Page 5 Danger of rotating tool and Keep a safe Danger of fire danger of objects thrown distance Consult the manual before inspecting the cutting rotor Danger of objects thrown by the Protect yourself with PPE rotation of the attachment...
-
Page 6: General Safety Rules
GENERAL SAFETY RULES Danger of fire ccident prevention rules On the machine and in this manual there are warnings and indications accompanied by this symbol: Handle fuel with care as it is highly flammable; do not refuel while smoking, near open flames or sparks, when the engine is running. ersonAl protection equipment it indicates the presence of a potential hazard for which particular caution should be taken for your own safety and for the safety of others who may be within the operating range of the machine. -
Page 7: General Warnings To Keep In Mind
Always use genuine Grillo spare parts and accessories; that could damage the machine or that could be thrown from the • Grillo machines are designed for the use of genuine Grillo rotating attachment; accessories or accessories from authorised manufacturers. Do not •... -
Page 8: Identification Of Machine Controls And Functions
IDENTIFICATION OF MACHINE CONTROLS AND FUNCTIONS 1. THROTTLE 2. ADJUSTER ON PTO LEVER 3. SAFETY LOCK ON PTO LEVER 4. PTO LEVER 5. HANDLEBAR ROTATION LEVER 6. ADJUSTER ON HANDLEBAR ROTATION LEVER 7. ADJUSTER ON TILT DEVICE LEVER 8. TILT DEVICE LEVER 9. -
Page 9: Identification Of Machine Components
IDENTIFICATION OF MACHINE COMPONENTS 1. ENGINE OIL LEVEL CAP 2. RECOIL KNOB 3. FUEL TANK CAP 4. ENGINE AIR FILTER 5. ENGINE GUARD 6. UPPER PTO COVER 7. INSPECTION AND MAINTENANCE OPENINGS 8. LOCKING NUT AND GRUB SCREW ON LOWER PTO 9. -
Page 10: Technical Specifications
TECHNICAL SPECIFICATIONS MODEL: TRIMMER HWT 570 MULTIFORCE, wheeled string trimmer with tilting frame and dual PTO for attachment change. ENGINE: BRIGGS&STRATTON 575EX, 140 cm³, 2,2 kW (3 HP) at 3200 rpm, single-cylinder, petrol engine. FUEL TANK CAPACITY: 0,8 litres STARTER: breakaway with recoil starter, Ready Start. DRIVE SYSTEM: handlebar adjustable in height, tiltable to the right and left, foldable. -
Page 11: Operating Instructions
OPERATING INSTRUCTIONS to be carried out before starting the engine. Fig. 4 SETTING UP THE MACHINE FOR USE • Check the integrity of the machine to ensure that it has not been damaged during transport; • Remove the machine from its packaging, taking care not to damage the levers and cables. Use an appropriate hoist of suffi cient capacity for the weight of the trimmer;... -
Page 12: Tilt Device
TILT DEVICE The best way to clean the machine is with compressed air in the engine area and optionally water for the body parts and rotor area. In some situations, such as trimming edges or fi nishing near walls, it may be useful to cut close to the ground. To achieve this there is the TILT IMPORTANT: avoid wetting the engine linkages, cables and device: by operating the lever to the left of the handlebar (fi g. 6/C) it is handlebar levers with a strong jet of water. -
Page 13: Ordinary Adjustments
ORDINARY ADJUSTMENTS 11.2 CUTTING HEIGHT ADJUSTMENT It is possible to fit the string holder plate in two configurations (fig. 10/A and 10/B). 11.1 HANDLEBAR SETTING • Configuration A allows fitting the strings in positions 1 and 2. Position 1 is the lowest and allows a grazing cut to the ground. Before starting work, it is recommended to position the handlebar in the •... -
Page 14: Extraordinary Adjustments
EXTRAORDINARY ADJUSTMENTS ORDINARY MAINTENANCE CAUTION: the adjustment procedures described below require CAUTION: if lifting the machine or any part of it, always use technical skills and expertise. It is advisable to contact an authorised suitable tools such as supports or safety catches. Grillo centre to carry them out. • Always wear suitable clothing and work gloves before starting any cleaning, maintenance or repair work; 12.1 ADJUSTMENT OF THE PTO, TILT DEVICE AND • Do not leave the machine during maintenance without safety devices or lifted, in places accessible to inexperienced people, HANDLEBAR ROTATION LEVER REGISTERS especially children; Keeping the levers at the correct tension ensures proper operation of the •... -
Page 15: Lubrication Of The Pto
13.3 REPLACEMENT OF THE STRINGS ON THE ngine oil CUTTING ROTOR IMPORTANT: it is essential to change the oil after the break-in For an optimal cut, check the length of the strings often: they must not be period (fi rst 5 hours). Then change the oil every 50 hours or once a damaged and must be fi tted correctly. year. • We recommend inserting the single string using all four holes (fi g. To check the oil level use the oil dipstick (fi g. 15) when the engine is cold. 17) so that it does not accidentally slip out during cutting;... -
Page 16: Extraordinary Maintenance
Fig. 20 It is advisable to contact an authorised Grillo centre. 14.1 REPLACEMENT OF THE BELT IMPORTANT: use only genuine Grillo belts. To replace the belt: 1. Remove, as shown in fi g. 18: the grass guard (A), the cover under the machine (B), the covers on the sides of the frame (C) and the front cover (D). This will allow access and greater visibility of the inside of the machine during maintenance;... -
Page 17: Troubleshooting Guide
TROUBLESHOOTING GUIDE HWT 570 MULTIFORCE - TROUBLESHOOTING GUIDE PROBLEM CAUSE SOLUTION Out of fuel - Check the fuel level - Clean or replace the air filter The engine does not start Combustion issues - Check that the carburettor jets are clean - Check that the spark plug gives a spark Throttle is set to “0”... -
Page 18: Storage And Prolonged Inactivity
This manual provides instructions for the use of the machine and for its It is possible to identify the part number by consulting the Grillo website: routine maintenance. the spare parts tables of the machine will be available by entering the For extraordinary maintenance, for all operations requiring technical serial number. -
Page 19: Eu Declaration Of Conformity
/ in qualità di legale rappresentante della ditta: / en qualité de représentant légal de la: / als rechtlicher Vertreter der Firma: / GRILLO SPA – Via Cervese, 1701 – 47521 CESENA (FC) – ITALY en calidad de legal representante de la: Hereby certifies that the underwritten machinery: / Dichiaro che la macchina sotto indicata: / Certifie que la machine indiquée ci-dessous: /... - Page 20 Tel: (+ 44) 01889569149 Website: www.grillospa.it Website: www.grilloagrigarden.co.uk E-mail: grillo@grillospa.it E-mail: info@grilloagrigarden.co.uk Grillo Australasia Pty Ltd Grillo Deutschland GmbH 14 REBECCA COURT - VIC 3943 SORRENTO - AUSTRALIA GUNTERSRIETHER STR.14 - 91224 HARTMANNSHOF - DEUTSCHLAND Tel: (+ 61) 0428206225 Tel: (+ 49) 09154949216 Website: www.grilloaustralia.com.au...
