ASSEMBLY AND OPERATION INSTRUCTIONS
Item
Qty
1.
2
Grooved top cap
2.
2
Height adjustment slider
3.
2
Tension bolt
4.
2
Upright assembly
5.
2
Base connection bolt
6.
2
Base weight unit
7.
4
Wheel
8.
4
Nut and bolt
9.
2
Bottom protective plug
Visit
www.scsport.com.au
& M
AINTENANCE
BMINF Badminton Posts
Description
for your local dealer
International Badminton Posts
M
ANUALS
Revision 2.0 – 10.5.16
Advertisement
Table of Contents
Summary of Contents for Southern Cross BMINF
- Page 1 International Badminton Posts & M PERATION AINTENANCE ANUALS BMINF Badminton Posts ASSEMBLY AND OPERATION INSTRUCTIONS Item Description Grooved top cap Height adjustment slider Tension bolt Upright assembly Base connection bolt Base weight unit Wheel Nut and bolt Bottom protective plug Visit www.scsport.com.au...
- Page 2 International Badminton Posts Assembly: 1. Insert the grooved net cable cap (1) into the slider section (2) . 2. Insert the slider sect ion (2) int o the upright assembly (4) and insert the tension bolt (3) and tighten as required. 3.
