Summary of Contents for ALT M19
- Page 1 AUTOCLAVE LOGGER THING Wireless Autoclave Data Recorder Model: M19 & M22 & M42 User and Setup Manual Works With...
- Page 2 This warranty does not cover physical damage to the unit, modification or negligence. Nothing else is covered either written or implied. aLT, LLC shall not be held accountable for damages beyond the cost of if the original value of the unit.
-
Page 3: Table Of Contents
Table of Contents Autoclave Logger Thing Overview ....................5 Security, Design and Operation ......................6 Installation ............................8 M19 ..............................8 M22 ..............................10 Setup ..............................12 Connecting to your network ....................13 DHCP Setup ..........................14 Static IP Setup..........................15 Time Setup .......................... - Page 4 SD Card ............................20 Log Indicators............................ 21 Battery Replacement ........................22 Tips and Troubleshooting ........................24 FCC Warning ............................25...
- Page 5 What You Need Before You Start Tools o Philips Screwdriver (#2) Info o Autoclave Logger Thing Serial # __________________________________ o Wi-Fi Network Name (SSID) __________________________________ o Wi-Fi Network Password __________________________________ o Dropbox Email __________________________________ o Dropbox Password __________________________________ o Autoclave Name (Your Choice) __________________________________...
-
Page 6: Autoclave Logger Thing Overview
Autoclave Logger Thing Overview Reset Input Connect SD Slot Card IGURE... -
Page 7: Security, Design And Operation
Only 2 secure outgoing connections occur over secure HTTPS connection protocols. For Security the aLT requires a password to connect to it. The password is the device serial number. The network configuration page is only available upon initial startup or after a hard reset. - Page 8 DHCP and static protocols. The only function of the aLT is to mechanically record the data from the autoclave, save it and upload it to the cloud. All proper loading, handling, storing and Biological testing should be performed in accordance with the autoclave manufacturer.
-
Page 9: Installation
The printer connector may vary in location based on the age and version of • mainboard. NOTE: The printer connector may have a cable plugged it to it. Remove this cable and discard. It will not be needed for use with the aLT. - Page 10 Note: Do not place items that may damage it or block the Wi-Fi signal on the aLT. Especially hot and/or metallic items such as trays or instruments. 11. Plug-in autoclave power cord. 12. When “Autoclave Logger Thing” appears on the aLT screen you can proceed to Setup. If not see troubleshooting section. •...
-
Page 11: M22
Cover Plate Printer Connector 1. Unplug autoclave power cord. 2. Remove right side panel. Remove 2 top screws. • Remove 1 rear lower screw. • Pull panel top out and push down to release. • 3. Remove cover plate 4. Insert cable with the larger, 8 pin connector through Figure 3 The square hole under the cover plate. - Page 12 Especially hot and/or metallic items such as trays or instruments 9. Connect cable to aLT. 10. Plug-in autoclave power cord. 11. When “Autoclave Logger Thing” appears on the aLT screen you can proceed to Setup. If not see troubleshooting section. •...
-
Page 13: Setup
Important: for security set up must be completed within 5 minutes of power up, after which your device will disable all connections. This is designed as a security measure. If necessary, unplug the aLT for 5 seconds then reconnect and run setup again. -
Page 14: Connecting To Your Network
From any wireless device navigate to network connections. You will See a new network called “Autoclave Logger Thing”. Connect to this network. You will be prompted for network password. The password is the aLT serial number on the bottom of the unit. -
Page 15: Dhcp Setup
Depending on your device the configuration portal may be blocked or unable to be opened. If the portal does not open. Go to your web browser and in the search bar enter 192.168.4.1. DHCP Setup Select which type of network you will be connecting to. -
Page 16: Static Ip Setup
Static IP Setup If you have a static network, it is best to let your IT department Help walk you through this step as they will have to assign you an IP on your network. Static IP setup requires a few more steps. You will need a few more pieces of information. -
Page 17: Time Setup
Once your device is connected you will be redirected back to you network page. Make sure you are connected to the same wireless network as your aLT. open your web browser, in the search bar enter the number that appears on the Autoclave Logger Thing screen (This is the IP address). -
Page 18: Drop Box Setup
You will be redirected to Dropbox. If you are not logged in, you will be required to login Once you authorize your aLT to access your Dropbox you will be given an Authorization Code. Make sure you copy the entire key then navigate back To the “Dropbox Setup”... - Page 19 It the network is slow or congested it may take a few tries. If the aLT resets or it has not completed after 1 minute. Simply click “Get Dropbox Code”. You should already be logged in to Dropbox. Just copy and paste the code then resubmit.
-
Page 20: File Storage & Dropbox
File Storage & Dropbox Dropbox Your files are stored in Dropbox under the autoclave name that was chosen during setup. Each cycle name is the date and time the file was created. To keep the files in chronological order The file name is Year-Month-Day time (24hr) Dropbox creates the files in the following: Dropbox \ Apps \ Autoclave Logger Thing \ ”Your Chosen Name”... -
Page 21: Sd Card
The slot on the front of the aLT provides SD Card Access. This is a push in push out latch. Do not force it or try to pull the card out. Damage to the card or the card reader may occur. -
Page 22: Log Indicators
Log Indicators. To help identify the status of a file, each file will have an indicator at the end if the name. Indicates an error occurred during the cycle, items should not be considered sterile. Indicates a complete cycle and the autoclave did not detect any errors during the cycle. -
Page 23: Battery Replacement
Battery Replacement The battery should last approximately 5 years, it is recommended that it be changed at the 5- year mark. The battery retains the clock data in the event of a power failure or if an error occurs that temporally disables the autoclave. If the battery is failing, the clock may default to an undetermined date or time. - Page 24 3. Adjust the + or – until the correct time is displayed. (see Time Setup) Note: For Security the Web Browser is only available for 5 minutes after the aLT is plugged in. To regain access, unplug the aLT for 5 seconds.
-
Page 25: Tips And Troubleshooting
Tips and Troubleshooting For current FAQ’s and Troubleshooting please visit www.AutoclaveLoggerThing.com. If you have any additional questions, concerns or recommendations, please send them info@AutoclaveLoggerThing.com... -
Page 26: Fcc Warning
FCC Warning Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 28 Supplier's Declaration of Conformity 47 CFR § 2.1077 Compliance Information Unique Identifier: Autoclave Logger Thing, Models: M19, M22. Responsible Party: aLT LLC www.AutoclaveLoggerThing.com This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:...
- Page 29 LLC...
