RTP SC3015 Technical Manual

32-channel digital input cards
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Technical Manual
SC3015
32-Channel
Digital Input Cards

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC3015 and is the answer not in the manual?

Questions and answers

Related Manuals for RTP SC3015

Summary of Contents for RTP SC3015

  • Page 1 Technical Manual SC3015 32-Channel Digital Input Cards...
  • Page 2 RTP Corp. confidential. This intellectual property is made available solely for the direct use of potential or licensed RTP Corp. customers in their application of RTP Corp. products, and any other use or distribution is expressly prohibited. If you have received this publication in error, immediately delete, discard or return all copies to RTP Corp.

  • Page 3: Table Of Contents

    SC3015 – Thirty-Two-Channel Single Ended Digital Input Card ..... 4 Specifications – SC3015/00 ..............5 Figure 1: User Interface Connections for the SC3015/00 Card....6 Specifications – SC3015/02 ..............7 Figure 2: User Interface Connections for the SC3015/02 Card....8 NETARRAYS CONFIGURATION ..............

  • Page 4: Introduction

    The SC3015/ Thirty-Two Channel Single Ended Digital Input Card provides two sinking voltage options. The SC3015/00 is used with 120 VDC digital inputs. The SC3015/02 card is used with 48 VDC digital inputs. Immunity to noise is enhanced with a single pole low pass filter.

  • Page 5: Specifications - Sc3015/00

    NetArrays IOC screen and cannot be enabled, this indicates an error in the cards calibration data. Note: The SC3015 cards are designed to function with user supplied field termination and user supplied field wiring/cabling. Therefore it does not support Cable Detect Error reporting.
  • Page 6 Channel 19 + Channel 17 + Channel 15 + Channel 13 + Channel 11 + Channel 9 + Channel 7 + Channel 5 + Channel 3 + Channel 1 + Not Used Figure 1: User Interface Connections for the SC3015/00 Card.

  • Page 7: Specifications - Sc3015/02

    Specifications – SC3015/02 Number of channels: Card Address: Determined by the slot of the controller backplane Isolation: 500 VDC Channel to RTP Bus Maximum permanent allowed voltage (no damage): ±58 VDC Common Points between Channels: All channels share a single common return.
  • Page 8 Channel 19 + Channel 17 + Channel 15 + Channel 13 + Channel 11 + Channel 9 + Channel 7 + Channel 5 + Channel 3 + Channel 1 + Not Used Figure 2: User Interface Connections for the SC3015/02 Card.

  • Page 9: Netarrays Configuration

    NetArrays Configuration Card Properties Mode The only mode available for this card is DC Sinking. Proof Testing This option must be Disabled! Float Cal High 00 The Cal High 00 is a floating-point voltage equal to 9.0 volts (±0.09V). It is derived from a fixed calibration voltage source on the card.

  • Page 10: Float Cal High 01

    Float Cal High 01 The Cal High 01 is a floating-point voltage equal to 9.0 volts (±0.09V). It is derived from a fixed calibration voltage source on the card. This input can be used to test the card’s calibration and performance.

  • Page 11: Integer Channel Error Status 00

    Integer Channel Error Status 01 The channel Error Status 01 is an Int Variable that returns fault indications for channels 16 through 31. For the SC3015 this register is always zero. Integer Line Short Status 00 The Line Short Status 00 returns the results of the input line short tests on channels 0 through 15.

  • Page 12: Integer Soe 01

    Integer SOE 01 Input channels 31 through 16 on the SOE card are represented in this Int Variable as shown below. This input value is accessed by the Int Variable object with the same Tag. Reconfigure the Tag as required to match the Module Form Int Value object that is used to monitor the card's SOE input in RTP3000S, RTP3000D, RTP3000T and RTP3000Q SIS.

  • Page 13: I/O Channel Properties

    I/O Channel Properties Channel Each input channel can be enabled (Bool), or disabled (Disabled). You can disable any unused channel to avoid scanning unconnected inputs and to free up the assigned Tag. I/O Tag Each input point value is accessed by the Bool Variable object. NetArrays assigns a Tag to each input channel when the card is added to the I/O configuration.

  • Page 14: Compliance With Ce Mark

    Compliance with CE Mark This section describes how to install and operate RTP equipment for use in the European Union (EU) to comply with the requirements of the CE Mark and its referenced standards. The procedures in this section apply also to other environments where provisions of the EU’s EMC and Low Voltage Directives are either required or desirable.
  • Page 15 10. The disposal of any electronic products must be in accordance with local regulations (e.g. Directive 2002/96/EC of the European Parliament and of the Council on waste electrical and electronic equipment). Some RTP Corporation products contain materials that may be detrimental to the environment. These materials may include, but are not limited to lead (in solder) and lithium (in batteries).

  • Page 16: Environmental Conditions

    The modules are rated for the following environmental conditions: Specification Type Recommended Range Test Specification IEC 60068-2-30, Db Operating Temperature -20 ºC to 60 ºC RTP Type Testing Operating Temperature Change 10 ºC/minute IEC 60068-2-14 Test Nb Operating Humidity 10% to 95% non-condensing IEC 60068-2-30, Db...

  • Page 17: Referenced Companies

    Referenced Companies Corcom Inc.; Libertyville, Illinois, USA; 708-680-7400 Hoffman; Anoka, Minnesota, USA; 763-422-2178 Definitions OPERATOR is any personnel other than SERVICE PERSONNEL. Requirements assume that the OPERATOR is oblivious to electrical hazards, but does not act intentionally in creating a hazard. SERVICE PERSONNEL are assumed reasonably careful in dealing with obvious hazards.
