Installation - KOLINK PSU Series Manual

• Modular units, such as the Modular Power, Enclave, and Continuum series
allow users to remove cables. This makes installation much easier and allows
the customer to use only the cables they need, which reduces clutter within
the chassis.

INSTALLATION

Caution: Please read „Safety instructions" before you begin the installation.
Note: You will need a screwdriver to fit the power supply in your PC. Only use the
screws provided. If applicable, first remove your old power supply.
Removing your existing power supply:
• Carefully disconnect your PC from any power sources.
• Disconnect all plugs from the motherboard and all other components and
then pull out the power supply carefully.
• Follow the directions in your computer chassis manual and uninstall your
existing power supply unit.
Fitting your new Kolink power supply:
• Make sure the power supply's AC power cable is not connected. If it is,
disconnect it completely.
• Follow the directions as per your computer chassis manual, and install the
power supply with the screws provided.
• Connect the main 20+4-pin power cable. The main 20+4-pin power cable
has a detachable 4-pin mechanism in order to support either a 24-pin or a
20-pin socket on the motherboard.
If your motherboard has a 24-pin socket, you may connect the 20+4-pin
main power cable from the power supply directly to your motherboard.
If your motherboard has a 20-pin socket, you must detach the four-pin
cable from the 20+4-pin connector, and then plug the 20-pin cable onto
your motherboard without connecting the four-pin connector.
• Connect the peripheral cables, SATA cables, and PCI-Express cables.
• Connect the peripheral cables to your hard drive and CD/DVD/Blu-ray
drives (if present)
• Connect the SATA cables to your SATA SSD, fan controller, miscellaneous
SATA device or hard drive power sockets.
• Connect the PCI-Express cables to the power connectors of your PCI-Ex
press video cards if required.
• Connect the peripheral cables to any other peripherals requiring a small
4-pin connector.
• Make sure all the cables are tightly connected (usually there is an audible
