Light-Point DARK W1 User Instructions

Installation instructions
Lamp body: 1pcs Lamp head: 1pcs
Silicone pad Wall mount: 1pcs
FLAT gasket: 1pcs Spring washer: 1pcs
Plastic anchors: 4pcs Screw: 4pcs
1
Open the box and identify the various lamp accessories.
4
A.
Straighten the thread, insert it into the thread groove of
the slide block, and then attach the silicone pad.
B.
Then insert the slider into the wall mount.
Plastic cover: 1pcs
Sliding block: 1pcs
A
Screw: 1pcs
Spanner: 8mm, 5mm A.
& 2mm
B.
2
C.
D.
5
A.
B.
35 35
18 18
B C D
Fix the wall mount on the wall and mark the drilling
points for the screws.
Drill into the marked drilling points using a Ø6mm drill bit.
Fix the installation colloidal particles in the installation hole
Use a screw driver to fix the flat head cross tapping screws to
the wall.
Insert the lamp head into the lamp body
Connect the cable female and male connector.
3
Install the lamp body, plastic cover, wall mount, flat gasket, spring
washers, cylindrical head hexagon screws, with 5mm spanner to
lock them successively.
6
Plug in the power, touch the center of the lamp holder to light up,
long press to adjust brightness.
The lamp has a memory function, meaning it can remember your
last light intensity when turned off and on again
