Summary of Contents for Blocklychain MS-104
- Page 1 Multi Sensor MS-104...
- Page 2 HELLO Thank you for purchasing Multi Sensor. We are excited to bring convenience, security, and peace of mind into your home. Remote Access Control and monitor your home devices from Internet. Wi-Fi Connectivity Multi Sensor connects to the Internet via Wi-Fi.
- Page 3 How to Install Download Blocklychain App Product Installation Guide Create a New Account: Click on Create Account Type your e-mail address Type your password Re-type your password Click on Create Account Check your e-mail to verify your account , then click on I'm Already Verified...
- Page 4 Sign In: Click on Sign In Type your e-mail address Type your password Click on Sign In...
- Page 5 To install a new device in Android, make sure the mobile Bluetooth is turned on and allowing the app to "access device's location / Bluetooth"...
- Page 6 How to Mount Multi Sensor To mount the Multi Sensor, stick the big part on the frame of the door or window. Then, place the small part on the surface opposite the big part. Maximum recommended gap between the big and the small parts is 2 cm.
- Page 7 How to Install Device Click on Add Device Choose device type Turn on your bluetooth, then click on Next...
- Page 8 Find your device from the list, then click on Connect Click on Search Wi-Fi Searching for available Wi-Fi networks Choose your Wi-Fi SSID Type your Wi-Fi password Click on Set Device Wi-Fi...
- Page 9 If the device installation process finishes successfully, the message be displayed. Otherwise, the message will be displayed. It indicates that something went wrong and you will need to redo the installation process again.
- Page 10 How to Monitor Your Device Back to home in app. Then, go to the BKC control Panel. Click on BKC Control Panel icon Click on Devices This is Device Card...
- Page 11 Name of the device Door Status Motion Detector Status Temperature and humidity data Device dashboard Device connection indicator...
-
Page 12: Update Device
Update device Click on the button on your device. Go to BKC Control Panel. Go to Devices page. On the device card, click on the device dashboard button. Go to the Config tab. Click on Update Now. Reset Factory On your Multi Sensor Click and release the button, then press and hold it for 10 seconds. -
Page 13: Device Dashboard
Device Dashboard Clicking on the gear icon on the Multi Sensor card, a pop-up window opens with 3 tabs. Monitor In Monitor tab, there are data about device functions. Data Graph In Data Graph tab, a bar chart represent power consumption during time. - Page 14 Config In Config tab, you can update firmware, rename device, and remove your device from BKC Control Panel.
-
Page 15: Led's Status
LED's Status Status Indicator Description Working Modes 4 seconds 4 seconds Problem connecting to server 2 seconds 2 seconds Ready to install 0.2 second 0.2 second Connecting to Wi-Fi 0.1 second 0.1 second App connected to device Solid Orange Connecting to server Fading Orange Connected to server Reset Factory... - Page 16 Caution 1. Do not disassemble the product. 2. This device may contain small parts that may be a choking hazard to children. Keep the device out of the reach of small children. 3. Radio-frequency emissions and magnetic fields from electronic equipment can negatively affect the operation of other electronic equipment, causing them to malfunction.
-
Page 17: Specification
Specification Device Product Name Multi Sensor Model MS-104 Size (big part) 7x2x2.5 cm Size (small part) 5x1x1 cm Weight (big part) 22 g Weight (small part) Material Communication Wi-Fi 802.11 b/g/n 2.4GHz Power USB Type-C / 12V DC 500mA Features... -
Page 18: Package Content
1x Multi Sensor 1x Big Part 1x Small Part For further help or inquiries: 1) Email support@blocklychain-iot.com, or 2) Login to your account on BKC Control Panel , click , and submit a ticket. All right reserved. Copyright © 2022 Blocklychain...
