- Page 1 User Manual APPC-27X...
-
Page 2: Table Of Contents
Content Declaration ............................3 Product Instruction ..........................3 Power on the Product ........................4 Insert SD Card ............................ 4 Insert USB Devices ..........................4 Home Screen ............................5 System Bar ............................8 Applications ............................. 10 Language ............................11 Date & Time ............................12 Volume ............................. -
Page 3: Declaration
Declaration Please read the instructions carefully before equipment installation and using the device. Do not put the product in high temperature, humid or dusty environment. Do not drop, crash or break down this product. Do not power off the device when itʼs formatting or upgrading, otherwise it will cause ... -
Page 4: Product Instruction
10. Headset + Microphone Jack 11. 10/100Mbps RJ45 Ethernet Port: support Ethernet connection 12. AC/DC In Jack: powered by 12V/3A AC/DC input 13. Power Switch: switch power ON/OFF 14. IR Receiver & LED Indicator IR Receiver: support remote control LED Indicator: Power supply ON Red then turn Green after kernel boot up. -
Page 5: Insert Usb Devices
Insert USB Devices This product supports USB and Micro-USB to deal with your files. Product Instruction Plug your USB memory into the USB port (#6 in ) on the bottom of Browse this product, and then you can do the file operations via the File Browser. (See in Files Micro-USB Product Instruction... -
Page 6: Home Screen
Home Screen In the home screen, you can long-press the blank space to change the wallpaper or drag widgets to desktop. Change Wallpaper: 1. Click “WALLPAPER”. - Page 7 2. Select one picture from system presets or your own pictures. 3. Click “Set wallpaper” on the upper-left corner of the screen to apply the wallpaper. Add Widgets: 1. Click “WIDGETS”.
- Page 8 2. Long-press a widget and drag it to desktop. 3. If you want to remove an icon, long-press the widget and drag it onto “×Remove” at the top of the screen and drop it until it turns red.
-
Page 9: System Bar
System Bar Navigation Buttons 1. Power key: Power off or reboot devices. 2. Volume-: Decrease the system volume. 3. Back: Return to the previous page. 4. Home: Return to the home screen. 5. Recents: Switch between recently used apps. - Page 10 To remove the application from the list, press the middle icon to remove the entire list. Either swipe left or right or click "x" at the top right of the application item to remove it. 6. Volume+: Increase the system volume. Status Notifications...
-
Page 11: Applications
Status bar at top of the screen displays system status, such as time, Wi-Fi, SD card and USB connection etc. Pull down from any position above the machine to open the status window and shortcut window, including brightness adjustment, wi-fi, automatic rotation, airplane mode and position switch, system Settings entry. -
Page 12: Language
home screen. Language In the App list, click “Settings” to open the system setting app, and select the option “Language & input”. -
Page 13: Date & Time
Click the first option “Language” under “Language & input”, and then you can change the system language according to your preference. Date & Time In the App list, click “Settings” to open the system setting app, and select the option “Date &... - Page 14 If you enabled the option “Automatic date & time” under “Date & time”, system date and time will be synchronized automatically with network time when you connected a Wi-Fi network. If you want to set the time manually, you need to disable “Automatic date & time” and “Automatic time zone”.
-
Page 15: Volume
In this option, you can also set time zone, time notation and date format. Volume On the system bar, click the Volume- icon to decrease the system volume, and click the Volume+ icon to increase the system volume. Product Instruction Or you can press the function keys (#7 in ) at the lower-right corner on the back of the product to adjust the volume. -
Page 16: Brightness
Brightness Drop down anywhere on the top of the screen, open a shortcut window, and click “brightness”. Slide the brightness button to adjust the brightness of the screen, or turn on Auto switch to automatically adjust the display's brightness to the appropriate level for the current ambient light. -
Page 17: Scheduled Power On/Off
Scheduled Power On/Off This function is used to power the device on and off automatically at the set time. In the App list, click “Settings” to open the system setting app, and select the option “Scheduled”. Click the single option “Set Scheduled Sleep On/Off Clocks”. - Page 18 The third row is for sleep on clocks, and the following row is for sleep off clocks. Click the third row to enter the settings of sleep on clocks. Click the option “Time” to set the power on time of this device. Click the option “Repeat”...
- Page 19 After setting, click “Done” at the upper-right corner of the screen to save them. You will see the sleep on option checked after saving the settings.
- Page 20 For sleep off clocks, you can set them as same as sleep on clocks. For shutdown and reboot clocks, you can set them to be the same as clock sleep.
-
Page 21: Wi-Fi
After the settings, the device will be powered off at set time, and powered on again when achieves the appointed time. Wi-Fi In the App list, click “Settings” to open the system setting app, and select the option “Wi-Fi”. -
Page 22: Ethernet
Switch the Wi-Fi button to ON. The product will scan available wireless networks automatically. Select a network under Wi-Fi networks and input the password to connect. Ethernet In the App list, click “Settings” to open the system setting app, select the option “More”, and then select “Ethernet”. -
Page 23: Bluetooth
Instruction). If Wi-Fi is on, please turn off Wi-Fi to allow Ethernet working. If you are Static IP user, please set the configurations manually. Bluetooth In the App list, click “Settings” to open the system setting app, and select the option “Bluetooth”. - Page 24 Switch the Bluetooth button to ON. The product will scan ambient available Bluetooth devices automatically. If you want to pair another Bluetooth device, select it from the “Available Devices” list, and then click “Pair” in the pop-up window. At the same time, click “Pair” in the pop-up window of the Bluetooth device to be paired.
- Page 25 After pairing, the paired device will be moved to the “Paired Devices” list. Click on the top right to change the bluetooth name in the menu.
-
Page 26: Virtual Keyboard
Virtual Keyboard The device provides a virtual keyboard for typing. You can use it as a real one. When you click in a text input box, the virtual keyboard will appear at the bottom of the screen. To collapse the virtual keyboard, you can click the icon in the system bar. -
Page 27: Take Photos & Shots
Take Photos & Shots Front 5M pixels camera is an optional accessory. In the App list, open “Camera” Click the capture button to take a photo. Click the button on the upper right to change the camera Settings. Click to turn on the reference function. Click to open the countdown function;... - Page 28 Slide the interface to the right click under the capture button to switch take photos or videos. Click the capture button for shooting a video.
-
Page 29: Surf Online
Click the capture button to stop the shot. Surf Online In the App list, open “Browser” When connecting the device to a network, you can visit websites, play online media or download files via the browser. In a browser window, enter in a URL in the address bar and click “->” in the virtual keyboard to go. -
Page 30: Browse Files
Browse Files In the App list, open “Explorer” to view local files. Long-press a file or folder to do file operations, such as copy, delete, move (cut), paste, rename, send (share) and create shortcut. -
Page 31: Play Media
If you want to select several files/folders at once, click “Multi” in the menu, and then select files/folders. The selected files/folders will be highlighted in blue. Click “Editor” in the menu to operate the selected files/folders. Play Media With the provided apps, you can play your media files on your storage, such as pictures, music and videos. - Page 32 downloaded app to the device from your computer. Then you can open “ApkInstaller” in the App list to install the downloaded app. Click “Install” button. Choose the installation fileʼs location. The apk files will be automatically scanned in the right side list.
- Page 33 Click the apk you want to install. Click “Install” or “Next” until it turns to “Install”, and then waiting for installation finished.
- Page 34 You can also download an android app market, and install the apps via the market. If “Install blocked” is prompted when installing an app, please open “Settings” and select the option “Security”, allow “Unknown sources” and then back to reinstall the app.
-
Page 35: Uninstall Apps
Uninstall Apps To uninstall an app, please open “Settings” in the App list and select the option “Apps”. In this option, you will see the installed apps list. Click the app you want to remove to enter the detail page. -
Page 36: Reset To Factory Default
Click the “Uninstall” button and select “OK”, and then waiting for uninstallation finished. Reset to Factory Default Please make sure to back up the important data before resetting the device. In the App list, click “Settings” to open the system setting app, and select the option “Backup &... - Page 37 Click “Factory data reset”. Click “Reset tablet” button.
- Page 38 Click “Erase everything” button, and then waiting system reboots and resets to factory default.
