Linksys WUSB54GS Quick Installation

®
A Division of Cisco Systems, Inc.
Package Contents
• Wireless-G USB Network Adapter
with SpeedBooster
• USB Cable
• Setup CD-ROM with User Guide
• Quick Installation
• Registration Card
2.4
GHz
Wireless-G
802.11g
USB Network Adapter
with SpeedBooster
Wireless Quick Installation
for Windows 2000 and XP
WUSB54GS
Model No.
1
Set up the Wireless-G USB Network
Adapter with SpeedBooster
IMPORTANT: Do not connect the Adapter to Your PC
until instructed to do so or the setup will not work.
A
Insert the Setup Wizard CD-
ROM into your CD-ROM drive.
The Setup Wizard should run
automatically, and the
Welcome screen should
appear. If it does not, click the
Start button and choose Run.
In the field that appears, enter
D:\setup.exe (if "D" is the letter
of your CD-ROM drive).
B
B
To install the Adapter, click the
Install button on the Welcome
screen.
C
After reading the License
Agreement, click Next.
D
Choose a wireless network
mode. Click the Infrastructure
Mode radio button if you want
your wireless computers to
network with computers on C
your wired network using a
wireless access point. Click the
Ad-Hoc Mode radio button if
you want multiple wireless
computers to network directly
with each other.
In the SSID field, enter the SSID
or name for your wireless
network. The SSID must be
identical for all devices in the
D
network. Click Next.
E
If you chose Infrastructure
Mode, go to Step F now.
If you chose Ad-Hoc Mode,
select the channel that your
network uses. For the Network
Mode, select Mixed Mode to
allow both Wireless-G and
Wireless-B computers on the
network, or select G-Only
E
Mode to allow only Wireless-G
computers. Then click Next.
F
If your network doesn't use any
security method, select
Disabled and click Next.
Proceed to Step H.
If you want security, select the
security method you want to
use: WEP , PSK, PSK + RADIUS, or
RADIUS. (WEP stands for Wired
Equivalent Privacy, and PSK F
stands for Pre-Shared Key.
RADIUS stands for Remote
Authentication Dial-In User
Service.) Then click Next and
proceed to Step G.
G
Proceed to the appropriate
instructions for your security
method.
1 WEP
a Select 64-bit or 128-bit from
the drop-down menu.
b Enter your Passphrase in the
Passphrase field, and the WEP
key will be automatically
generated.
WEP
To manually enter the WEP key,
leave the Passphrase field
blank and enter the WEP key in
the WEP Key field.
c Click Next, and go to Step H.
2 PSK
a Select the encryption method
you want to use, TKIP or AES,
from the drop-down menu.
b Enter your Passphrase or Pre-
Shared Key in the Passphrase
field.
PSK
c Then click Next and proceed
to Step H.
