Summary of Contents for Blake Water Solutions MOD-EMU-BWS
- Page 1 EQUIPMENT MODULES Operation & Installation Instructions...
-
Page 2: Table Of Contents
Table of Contents Emulator Module ..........1 Remote Alarm Module ........2 4-20 mA Module..........3 Solonoid Module ..........4 Water Quality Monitor Module ......8... -
Page 3: Emulator Module
EMULATOR MODULE MODEL # MOD-EMU-BWS The Emulator module comes with a male IEP connection (Infinite Expandability Port). Prior to start-up, first ensure all the toggle switches for the “Module Alarms” Emulation Module and “Lamp Alarm” are in the OFF (toggle up) position. -
Page 4: Remote Alarm Module
REMOTE ALARM MODULE MODEL # MOD-RAM-BWS BWS5/BWS6 BWS5-C/6-C Sensor IEP Series controllers Installation Series controllers connection connection connection The Remote Alarm module comes with both a male and female IEP connection (Infinite Expandability Port). To initiate the module simply plug the male plug into the IEP on the Standard or High Output controller, or into any other BLAKE module that contains an IEP (sensor, 4-20 mA module, solenoid module, etc.) and then restart the system. -
Page 5: 4-20 Ma Module
4-20 mA MODULE MODEL # MOD-420-BWS BWS5/BWS6 BWS5-C/6-C Sensor IEP Series controllers Installation Series controllers connection connection connection The 4-20 mA module comes with both a male and female IEP connection (Infinite Expandability Port). To initiate the module simply plug the male plug into the IEP on the controller, or into any other BLAKE module that contains an IEP (sensor, remote alarm, solenoid module, etc.) Connect “LOOP”... -
Page 6: Solonoid Module
SOLENOID MODULE MODEL # MOD-SOL1-BWS Solenoid module MOD-SOL1-BWS The Solenoid Module is designed to connect a NORMALLY CLOSED line voltage solenoid valve to the controller. It is possible to us a 12V or 24V normally closed solenoid by replacing the AC power cord. Note that the maximum contact rating is 240VAC (50-60Hz) / 30VDC / 2A. - Page 7 Step 2) Plug the solenoid valve into the applicable electrical outlet. At this stage, the functionality of the solenoid valve can be tested by pressing the solenoid test button located on the upper left of the circuit board. Manually depressing (and holding) this button will complete the electrical circuit and will open the normally closed solenoid valve.
- Page 8 Step 2) The controller will only notify you when there is a failure mode whereby the solenoid module (and connected solenoid valve) will be activated. On the BWS5 system, the solenoid module will be activated (shutting off the flow of water) upon LAMP FAILURE (see Fig.
- Page 9 Figure 8 Solenoid Bypass Button Once this button has been pressed, the system will remain in this override mode regardless of whether or not the condition causing the solenoid activation has been remedied or not. To reset the system, the power to the controller must be shut off and restarted. While in this override mode the controller will intermittently display a red “SOLENOID OVERRIDE”...
-
Page 10: Water Quality Monitor Module
WATER QUALITY MONITOR MODULE MODEL # MOD-SHERPA-BWS Water Quality Monitor 50m/164ft Good Comm (Note 2) Active Caution Alarm Transmitter Remote Display The module comes with a Transmitter and a Remote Display. The Transmitter connects to a standard output and high output controller and transmits the controller’s status wirelessly to the Remote Display. - Page 11 Operation Remote Display Good No Active Alarms. (Green) Caution Active Minor Alarm, check system for details. Status LED’s (Yellow) Alarm Active Major Alarm, check system for details. (Red) Communication is working. Communication is NOT working. Flashing Remote Display is Out-of-Range , Transmitter is disconnected Comm.
- Page 12 Blake Equipment 4 New Park Rd East Windsor CT 06088 1-800-353-1100 Email: bwsinfo@blakeequip.com www.blakeequip.com PN#910406 Version Date: 06-2021...
