ALLIANCE A1
1.2M MACHINE
WIDTH:
123 cm / 48.5 in
HEIGHT:
Varies
DEPTH:
46 cm / 18 in
WEIGHT:
Varies
ALLIANCE A1
1.7M MACHINE
WIDTH:
171 cm / 67 in
HEIGHT:
Varies
DEPTH:
46 cm / 18 in
WEIGHT:
Varies
ALLIANCE A1
2.4M MACHINE
WIDTH:
240 cm / 95 in
HEIGHT:
Varies
DEPTH:
46 cm / 18 in
WEIGHT:
Varies
Alliance motors are ½ hp, single
phase, 115 volt, 60 Hz with FLA of
6.8 amps (782 Wa�s).
Motors are explosion-proof, rated for
Class 1, Division 1, Group D,
hazardous loca�ons.
The motor is controlled by an
intrinsically safe electronic �mer that
operates on 5 volts DC.
Both the motor and �mer are U.L and
CSA approved.
WWW.DEDOES.COM
Alliance A1 Mix Machine
Maintenance and Repair Guide
Maintenance and Repairs
Simple steps to correct common issues with the Alliance Machines
· Serial number loca�on
· How to easily access the drive belts without disassembly
· Belt installa�on
· Common replacement parts
· Lubrica�on
· Rou�ne maintenance
Dedoes U.S.
Headquarters
1060 W. West Maple Rd.
Walled Lake, MI 48390
Alliance A1 2.4M Machine
Support & Sales
248-624-7710
info@dedoes.com
www.dedoes.com
CSM15 - 2022
Advertisement
Summary of Contents for Dedoes Alliance A1 1.2M
- Page 1 The motor is controlled by an intrinsically safe electronic �mer that operates on 5 volts DC. Both the motor and �mer are U.L and CSA approved. Dedoes U.S. Support & Sales Headquarters 248-624-7710 WWW.DEDOES.COM 1060 W. West Maple Rd.
- Page 2 RESISTANCE AT 40° C AMBIENT; WITH INTRINSICALLY SAFE POWER SUPPLY BOARD ASSY 850-9522-032, (223450928), AS DESCRIBED IN FILE E481969 VOLUME 1, SECTION 2. Dedoes Safety Instruc�ons.vsd FM-110 Rev.1 It is recommended to have each Alliance A1 Mix Machine hard wired to its own electric circuit within its loca�on.
- Page 3 5097 5836R 5097 5836L Contact Dedoes to order parts, with ques�ons or anything more you may need. Dedoes U.S. Support & Sales Headquarters 248-624-7710 1060 W. West Maple Rd. info@dedoes.com Walled Lake, MI 48390 www.dedoes.com...
- Page 4 5996PLT - 13” GALLON SHAFT 5936W - QUART TUBE KIT 5281D - QUART GUARD 5937W - GALLON TUBE KIT 5282D - GALLON GUARD Contact Dedoes to order parts, with ques�ons or anything more you may need. Dedoes U.S. Support & Sales Headquarters 248-624-7710 1060 W.
- Page 5 It is located on a small aluminum plate that is bolted to the black metal pla�orm the motor and gear reducer are mounted to. The serial number and date can tell Dedoes if your machine is s�ll under warranty. How to remove the expanding bolt...
- Page 6 How to repair the Alliance machine without disassembling it If you need to access the interior of the mixing shelves to replace a belt or repair some components, it is possible to access any of the shelves without disassembling the en�re machine. To do so: 1.
- Page 7 How to replace a bushing or drive gear During the life of your Alliance machine it may be necessary to Upper Shaft replace a bushing or drive gear within the mixing shelf. To do so: 1. Turn off the power to your Alliance mixing machine. 2.
- Page 8 How to replace a belt During the life of your Alliance machine it may be necessary to replace the belt in one of your mixing shelves. The Alliance machine u�lizes only one belt per shelf and the same size belt for each shelf. The belt supplied with older units is a white cog belt.
- Page 9 If you are having trouble with your machine turning ON or OFF please contact the Dedoes Customer Service Department at 1-248-624-7710 and we will be happy to help you resolve your issue.
- Page 10 There are two solu�ons to resolve this problem. You can simply purchase and replace the �mer (Dedoes PN# SA0468) or you can try to rest the �mer by cu�ng the decal bu�on off.
- Page 11 How to replace an Alliance interface It may be necessary to replace an interface for your Alliance machine. The interface is the loca�on where your Alliance mixing lid will engage the drive system of your Alliance mixing machine. To remove an interface: 1.
- Page 12 2 - You can now push or pull the machine to the le� or the right to guide it back to square. 3 - Re-�ghten the four thumb screws. 4 - If need be �ghten or reposi�on the wall anchors for more stability. Wall Mount Brackets Level Surface www.dedoes.com...
