Summary of Contents for Foxfury Lighting Solutions TACSWAN EXOLANDER 700-XDS-M3
- Page 1 EXOLANDER © SYSTEMS FOR DJI MAVIC 3 700-XDS-M3 | 700-XLS-M3 PRODUCT MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS EXOLANDER © Systems EXOLANDER © Landing System Reference Guide Physical Characteristics Installation D3060 Drone Spotlight Reference Guide Physical Characteristics Battery Operational Modes 11-12 Installation CARE/CLEANING WARNINGS/WARRANTY 14-15 CONTACT FOXFURY... -
Page 3: Exolander © Systems
EXOLANDER SYSTEMS © D3060 Saddle Landing EXOLANDER © Drone Mount © Skids Spotlight EXOLANDER© D3060-TC Light System for DJI Mavic 3 P/N 700-XDS-M3 EXOLANDER© Landing System - - - for DJI Mavic 3 P/N 700-XLS-M3 ITEMS INCLUDED (additional to those listed above) USB-C 12”... -
Page 4: Exolander © Landing System
EXOLANDER © LANDING SYSTEM REFERENCE GUIDE MAVIC SADDLE MOUNT © EXOLANDER © HALF Alignment Slot Alignment Pin (2 ea) Threaded Locking Nut Insert Locking Knob Snap Lock (5 ea) & Screw Front Tab (2 ea) Rear Tab (2 ea) EXOLANDER ©... -
Page 5: Physical Characteristics
PHYSICAL CHARACTERISTICS DIMENSIONS WEIGHT DJI Mavic 3 Saddle 3.77 x 3.19 x 3.08 in 1.29 oz (36.5 g) Mount (95.8 x 81 x 78.3 mm) EXOLANDER 6.8 x 6.5 x 4.8 in © 4.05 oz (114.7 g) assembled (173.2 x 163.8 x 123 mm) 8.67 x 0.97 x 0.6 in 0.45 oz (12.8 g) Landing Skid, each... -
Page 6: Installation
EXOLANDER © LANDING SYSTEM INSTALLATION ❶ Install Saddle Mount © on the DJI. Slide the Saddle Mount © on the DJI and make sure that the two front tabs fit behind the front arms of the DJI and press down. Insure that the front and rear tabs of the Saddle Mount conform ©... - Page 7 Install the other EXOLANDER © Half in the open Saddle Snap Lock locations. Bring the units together and align the Pin into the Hole on each side. Align Locking Knob & Screw and Thread Locking Nut Insert on each side. Tighten each screw until the units are mated.
- Page 8 The EXOLANDER © installation is now complete. To install the Landing Skid, align each Tab on Landing Skid with each Slot on the EXOLANDER © Landing Foot. Press and snap Landing Skid WARNING: Landing System by wiggling it and making Manually test the EXOLANDER ©...
-
Page 9: D3060 Drone Spotlight
D3060 DRONE SPOTLIGHT © REFERENCE GUIDE D3060 CHARGING PORT POWER/MODE SWITCH FOR FRONT LIGHT DORSAL LIGHT FRONT LIGHT POWER/MODE SWITCH FOR DORSAL LIGHT CHARGING PORT 360° SWIVEL... -
Page 10: Physical Characteristics
OVERVIEW The D3060 is a multi-function utility light. It is able to mount to most drones by FoxFury saddle mounts. Its 30° and 60° dual LEDs can operate with a high, low, or strobe mode to provide omni-directional lighting. This rechargeable and waterproof light is durable and compact for a variety of uses where light is needed in a tight space and where weight is a concern. -
Page 11: Battery
BATTERY CHARGING THE BATTERY Connect the USB C Cable to the Charging Port and to a USB port. While charging, a red light will be on. Once charged, it will turn to green. Charge time should be approximately 1.5 hours. WARNINGS: Unplug the light once charged to avoid impacting battery life. - Page 12 OPERATIONAL MODES OPERATIONAL MODES (CONT’D) Press the Dorsal Light Power/Mode Switch once to turn the Dorsal Light on to HIGH. Press the Dorsal Light Power/Mode Switch again to turn the Dorsal Light to LOW. Press the Dorsal Light Power/Mode Switch again to turn the Dorsal Light to STROBE.
-
Page 13: Installation
INSTALLATION MOUNTING D3060 TO SADDLE Align the 360° swivel with snap lock location on the desired mount location of the saddle, and snap D3060 light in place. Spin the light and tug to make sure it is properly atatched. (Images below show D3060 attachment and then assembled to drone at various attachment locations of the saddle - top and side). -
Page 14: Care/Cleaning
WARRANTY AND OTHER INFORMATION PRODUCT DURABILITY Any FoxFury product should be operated at speeds safe enough to maneuver around surrounding obstacles. Do not use under the influence of IPX6 drugs or alcohol. CARE/CLEANING ONE YEAR WARRANTY Your FoxFury product is a professional FoxFury, LLC (“FoxFury”) warrants tool. -
Page 15: Contact Foxfury
THIS IS THE ONLY WARRANTY, EXPRESSED OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES ARE EXPRESSLY DISCLAIMED EXCEPT WHERE SUCH LIMITATION IS PROHIBITED BY LAW. You may have other specific legal rights which vary by jurisdiction. - Page 16 FOXFURY.COM 09/2022...
