- Page 1 USER'S MANUAL KITCHEN FAN IN SOUND INSULATED CASING VRPK SERIES...
-
Page 2: Table Of Contents
CONTENTS 1. Purpose đ. 3 2. Delivery Set đ. 3 3. Main Technical Specifications đ. 3 4. Designation key đ. 3 5. Safety Requirements đ. 5 6. Installation and Operation Instructions đ. 5 7. Fan Structure đ. 6 8. Fan Installation đ. -
Page 3: Purpose
PURPOSE VRPK is a centrifugal fan in a sound insulated casing with a swing-out motor-impeller block and the motor positioned outside the air str eam. VRPK fans are intended for exhaust ventilation of premises with the temperatures up to 100° C and are used for household and restaurant exhaust systems;... - Page 4 Fig. 1 Dimensions, mm Fan Type VRPK 150 4E / VRPK 150 4D VRPK 160 4E / VRPK 160 4D 485 365 625 600 570 515 235 VRPK 200 4E / VRPK 200 4D VRPK 250 4E / VRPK 250 4D 575 435 700 675 645 620 285...
-
Page 5: Safety Requirements
SAFETY REQUIREMENTS Disconnect the product from the power mains prior to all operations specific to connection, setup, maintenance and repair. Fan maintenance and installation shall only be performed by professional electricians qualified for unassisted operations with electrical installations up to 1000 V after careful study of the present manual. All the fans are not designed for out-of-the-box operation and require connection to the air ducts. -
Page 6: Fan Installation
FAN DESIGN The fan casing is made of galvanized steel soundproofed on the inside with 50 mm thick mineral wool. The pivot design of the swing-out motor-impeller unit ensures easy access to the fan internals for quick and efficient cleaning. The inlet and outlet fitting diameters match the standard duct sizes. - Page 7 Fig. 3...
- Page 8 ELECTRICAL MAINS CONNECTION Disconnect the fa n from the power supply prior to any work on the unit. All the electrical connections of the fan must be made by a qualified electrician. The nominal values of electrical para meters are given on the fan manufacturer's label.
- Page 9 Automatic switch rated current (recommended) and conductor section Recommended cable, n x S, Automatic switch where n is the number of wires Fan Type rated current, A and S is the section in mm . VRPK 150 4Å 2 õ 1,5 VRPK 150 4D 3 õ...
-
Page 10: Storage Regulations
Fig. 6 TROUBLESHOOTING MALFUNCTION PROBABLE REASON ELIMINATION METHOD Check the power switch. No power Check electrical connections Fan doesn't work against the wiring diagram. Noisy operation Fan impeller out of balance Clean the impeller. STORAGE REGULATIONS The fan should be stored in the original packing in a ventilated area at temperatures from +5°C to +40°C and relative air humidity not more than 80% (at Ň=20°C). -
Page 11: Manufacturer's Warranty
MANUFACTURER'S WARRANTY We hereby declare that the following product complies with the essential protection requirements of Electromagnetic Council Directive 2004/108/EC, 89/336/E EC and Low Voltage Directive 2006/95/EC, 73/23/EEC and CE-marking Directive 93/68/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibili This certificate is issued following test carried out on samples of the product referred to above. -
Page 12: Acceptance Certificate
ACCEPTANCE CERTIFICATE The fan is recognized as serviceable. Model VRPK ______________ (tick the proper model) Date of production Stamp of the acceptance inspector Sold by name of the vendor, stamp of the shop Date of sale WARRANTY CARD...
