Installation Height
CO2 is a heavy gas that accumulates in the
lowest areas filling an area from the floor and
up. Therefore it is our recommendation to mount
the CO2 sensor at 12 inches /30 centimetres
from the floor. This way the awareness of a leak
is made as early as possible insuring time to deal
with the leak as well as avoiding unnecessary
loss of CO2. This also harmonizes with existing
European legislation.
CO2 detection distance
The CO2 Alert must be mounted within a 5 meter/
15 feet radius of the CO2 distribution point.
15 Feet
5 Meters
CO2 ALERT Mk X
Quick Guide
15 Feet
5 Meters
12 Inches
30 cm
15 Feet
5 Meters

Advertisement

loading
Need help?

Need help?

Do you have a question about the CO2 ALERT Mk X and is the answer not in the manual?

Questions and answers

Summary of Contents for DUOTEC CO2 ALERT Mk X

  • Page 1 CO2 ALERT Mk X Quick Guide Installation Height CO2 is a heavy gas that accumulates in the lowest areas filling an area from the floor and up. Therefore it is our recommendation to mount the CO2 sensor at 12 inches /30 centimetres from the floor.
  • Page 2 CO2 detection distance It is very important to be aware that a CO2 Sensor can only monitor the CO2 concentration in the proximity of the sensor. Therefore it is essential to place the sensor correctly within 5 metres / 15 feet from the distribution point were a CO2 leak is possible.
  • Page 3 12 Inches 30 cm 15 Feet 5 Meters Kiosk installations Since the CO2 Alert must be mounted within a 5 meters/ 15 feet radius of the CO2 distribution point the CO2 Alert will cover most kiosk applications. OBSERVE! that the CO2 Alert must not be covered by objects that block it from a clear view.
  • Page 4 Stand Alone Schematics: CO2 ALERT Mark 10 Power Supply Connectors Installation with Remote Horn/Strobe schematics: Remote Horn/Strobe Connectors CO2 ALERT Mark 10 Connectors Advanced Installation Schematics: Remote Horn/Strobe Connectors CO2 ALERT Mark 10 Remote Central Unit MK IX Connectors LogiCO2 International SARL. / LogiCO2 Online SARL. · B.P. 172 7502 Mersch · LUXEMBOURG Telephone +352-320 872 ·...
