MAINTENANCE MANUAL
POWER DISTRIBUTION PANEL
19C852636P1
TABLE OF CONTENTS
LBI-39158
Page
Advertisement
Table of Contents
Summary of Contents for Ericsson 19C852636P1
-
Page 1: Table Of Contents
LBI-39158 MAINTENANCE MANUAL POWER DISTRIBUTION PANEL 19C852636P1 TABLE OF CONTENTS Page SPECIFICATIONS ...........................2 INTRODUCTION.............................2 DESCRIPTION............................2 POWER DISTRIBUTION........................2 INPUT POWER...........................2 OUTPUT POWER ..........................2 REMOTE SENSE CONNECTIONS ....................3 MAINTENANCE ............................3 PARTS LISTS............................4 POWER DISTRIBUTION PANEL.......................4 P0WER DISTRIBUTION PANEL OPTIONS ..................5 ASSEMBLY DIAGRAM ..........................6 POWER DISTRIBUTION PANEL.......................6... -
Page 2: Specifications
PDPs via the main PDP. INTRODUCTION This manual documents maintenance information on POWER DISTRIBUTION the 19C852636P1 Power Distribution Panel (PDP). The panel was designed for use in any application using the 350A1441 series Power Supply System. INPUT POWER High Current (+5 Vdc) enters the PDP via the buss bar... -
Page 3: Remote Sense Connections
Pin 2 - -12/15 Vdc NOTE NOTE +5 Vdc Reference designations refer to Assembly Diagram Pin 3 - and Parts List 19C852636P1. Ground Pin 1 - +12/+15 Vdc 1. Clamp buss bars (Items Torque set screw to 8-10 NOTE 4, 5,& 6) to connector buss in. -
Page 4: Parts Lists
LBI-39158 PARTS LIST POWER DISTRIBUTION PANEL SYMBOL PART DESCRIPTION 19C852636P1 Sheet 1, Rev. 2 NUMBER SYMBOL PART DESCRIPTION NUMBER 19C852638P1 Stud Assembly, includes the following: (2 required per panel.) 19C852639P1 Front Panel. N18P25032B6 Hex cap screw, 3/8" x 2" (qty. 1 per Stud Assembly). -
Page 5: P0Wer Distribution Panel Options
PARTS LIST LBI-39158 POWER DISTRIBUTION PANEL OPTIONS 19C852649G1 - MULTIPLE POWER DISTRIBUTION PANEL KIT 19C852649G2 - SINGLE POWER SUPPLY BUSS BAR KIT 19C852649G3 - DUAL POWER SUPPLY BUSS BAR KIT PL19C852649 Rev. 0 SYMBOL PART DESCRIPTION NUMBER MULTIPLE POWER DISTRIBUTION PANEL KIT 19C852649G1 19C852641P1 Access Cover, Multi-panel. -
Page 6: Assembly Diagram
U SIN G # 8-3 2 x 1/4 " S CR E W (1 1) W IT H L O CK W AS H ER (12 ). SMALL PLUG ASM J9 AND J10 ACCESS COVER, SINGLE PNL M3 THREAD FORMING SCREW (2 PLCS) POWER DISTRIBUTION PANEL 19C852636P1 (19C852636, Sh. 2, Rev. 2A) -
Page 7: Power Distribution Panel Options
ASSEMBLY DIAGRAM L BI-39158 LOCAT ION FOR POWER CONFIGURATION LABEL STUD ASM SAMPLES: (1/4" HIGH LET T ERI NG) 19C852638 +5, +/-12 VDC +5, +/-15 VDC +24 VDC MULTI PANEL BUSS HARDWARE MAIN GND BUSS P/O STUD ASM 19C852638 FRONT PANEL 19C852639 INST ALL WASHERS AND THREAD NUT S ONT O STUDS HAND T IGHT... -
Page 8: Cables
LBI-39158 CABLE DIAGRAM A L L WI R E S 2 2 AWG # 8 S OL D E RL ES S T E RM I N A L CL O S E D / O P E N B A R RE L I NS UL A T E D / NO T I NS UL A T ED CON N ECTI ON D IAGRAM 6 "... -
Page 9: Schematic Diagram
SCHEMATIC DIAGRAM LBI-39158 (GND) GND Buss Bar (+) Buss Bar - - Item #4 Item #5 J2 thru J8 +12/+15 Vdc +12/+15 Vdc +5 Vdc +5 Vdc Output to Equipment From RPS Output and other PDPs. Connector J3 Ground Ground -12/15 Vdc -12/-15 Vdc Low Current... - Page 10 Ericsson Inc. Private Radio Systems Mountain View Road Lynchburg, Virginia 24502 1-800-528-7711 (Outside USA, 804-528-7711) Printed in U.S.A.
