PRODUCT USE AND CARE INSTRUCTIONS

SQUIGGLE BIKE

ITEM NO.: LME-BB1

Before riding, please read this Product Manual carefully and abide by

all Security Warnings and Precautions. It is important to understand

the use of this product and maintain LME-BB1 in accordance with this

manual.

Table of Contents

Need help?

Do you have a question about the LME-BB1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Squiggle LME-BB1

Page 1 PRODUCT USE AND CARE INSTRUCTIONS SQUIGGLE BIKE ITEM NO.: LME-BB1 Before riding, please read this Product Manual carefully and abide by all Security Warnings and Precautions. It is important to understand the use of this product and maintain LME-BB1 in accordance with this manual.
Page 2: Table Of Contents
1 rider.  Only use the battery specified by the manufacturer  The Squiggle Electric bike should be used with caution since skill is required to avoid falls or collisions causing injury to the user or third parties Content 1.
Page 3: Before Using
1. BEFORE USING 1.1 Riding Risk Squiggle electric balance bikes are a personal electric vehicle toy, our technology and production processes have strict testing for every electric balance bike. Riding without attention to contents of this manual may cause injury.
Page 4: Product Specification
1.2.2 Product specification Net weight 10kgs Size 980*510*568mm Running time 6~15km E-balance bike Operating temperature range 0℃-40℃ Max climbing angle 6~9° Max weight capacity 50KG Capacity 4.0Ah Types 18650 high rate discharge battery Battery Charging duration 3~6 hours Charging times 300 times Type Brush motor...
Page 5: Description Of Parts
1.2.3 Description of parts Estimated Assembly and Set-Up Time The product should be assembled by an adult. Allow up to 10 minutes for assembly, not including initial charge time. Allow up to 4 hours for charge (see charging information page). WARNING: ONLY USE THE PARTS SUPPLIED WITH YOUR ELECTRIC BALANCE BIKE.
Page 6 1.2.4 How to assemble the LME-BB1 STEP 1: Assemble the handle bars A: Size: M5X20 Socket head bolt B: Upper block C: Handle bar D: Down block 1. Put(C)in to location(D), then cover(B) 2. Put(A)into(B), then use the tools screw to(D)
Page 7 STEP 2: Assemble the front wheel Loosen the screws and nuts. Put the front wheel into the front fork and ensure it is locked. Tighten the screws and nuts (as seen in left photo). Make sure the front wheel is in the middle of the front fork.
Page 8 STEP 3: Install the battery battery handle female plug male plug A. Install the battery： Take the battery out and you will see the female plug in the battery and the male plug in the bike. Match the female plug to the male plug, then press the battery case until the two plugs are completely locked.
Page 9 Step 5: Check the battery capacity Battery capacity display After installing all the above steps, press the red button to check the battery capacity. 1). Full battery capacity： Green，Yellow and Red light on 2). Half battery capacity： Yellow and Red light on; Green light off 3).
Page 10: Safe-Using Of Electric Balance Bike
If there is any abnormal situation, please contact the local Squiggle reseller for servicing and repair. 2. Please carefully read the "Product Manual", this will help to get a lot of important safety information such as speed limited, vibration alert and safety shutdown, etc.
Page 11: Speed Limited
3. USAGE OF BATTERY This section mainly describes the charging method of the Squiggle electric balance bike, how to maintain the battery, some security issues, and battery specifications. For users' safety, maximum extent of prolonging the battery life, and improve battery performance, please follow the instructions.
Page 12: Charging Process
3.2 Charging process WARNING: ONLY with recommended charger. Batteries are only to be charged under adult supervision. The charger is not a toy. Always disconnect the charger before wiping down and/or cleaning the electric scooter with a damp cloth. The charger supplied with the electric bike should be regularly examined for damage to the cord, plug, enclosure and other parts.
Page 13: Description Of Battery
3.3 Description of battery Contents Parameters Battery Lithium battery Charging time 2~3h Voltage Initial Capacity Working Temperature -15℃~50℃ Charging Temperature 10℃~40℃ Storage Time(-20℃~ 35℃) 12 months(Charge every 2~3 months) Storage Humidity ~65% 3.4 Shipping Notes Lithium battery contains dangerous articles. Ship lithium only according to local law. 4.
Page 14: Maintenance
5. MAINTENANCE Electric balance bike requires the user to do routine maintenance. This chapter describes maintenance steps and important operating tips. Before you perform the following operations, ensure the power and charging cable are disconnected. If the battery is charging, the operation is not allowed. Turn power “OFF”...
Page 15: Charger
Correct Disposal of this product This marking indicates that this product should not be disposed of with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased.
Page 16: Troubleshooting
6. TROUBLESHOOTING Problem Possible Cause Solution Charge the battery until the charger indicator light turns from red to green. Battery needs a charge Check all connectors. Make sure the charger connector is securely plugged into the charging port, and that the Bike does not run charger is plugged into the wall outlet.
Page 17: Service
7. SERVICE & WARRANTY Thank you again for your purchasing Electric balance bike Squiggle BB1. We would like to provide you with good after-sale services by offering a 12 month Warranty on your bike, and 6 months on your battery.
